U
G
SER
UIDE
USB 2.0 F
E
A
C
AST
THERNET
DAPTER
ABLE
Model: 81672
1

Advertisement

Table of Contents
loading

Summary of Contents for C2G 81672

  • Page 1 UIDE USB 2.0 F THERNET DAPTER ABLE Model: 81672...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Introduction..............................2 Features................................3 System Requirements............................4 Package Contents............................5 Software/Device installation-Win 2000, XP, Vista, Win 7................6 Software/Device Installation-Win 98 and ME....................8 Verify Installation..............................9 Explanation of LEDs............................10 Un-installation..............................11 Troubleshooting............................12 Technical Specifications..........................13 C2G One Year Warranty.........................14 Important Safety Information..........................15...

  • Page 3: Introduction

    NTRODUCTION Thank you for purchasing the USB 2.0 Fast Ethernet Adapter Cable from C2G. With its 480 Mbps of available bandwidth, you get true 10/100 network access. The plug-and-play design makes this adapter the most convenient and efficient way to connect a laptop or desktop computer to a fast ethernet network. With our fast ethernet adapter, you can experience the full speed of your fast ethernet network without the need for opening your PC and adding internal network adapters.

  • Page 4: Features

    EATURES  IEEE 802.3u 100 BASE-T, TX compatible  Supports full duplex or half duplex mode  Supports suspended mode and remote wakeup  Compliant with the standard specification of USB 1.1 and 2.0...

  • Page 5: System Requirements

    YSTEM EQUIREMENTS  A USB-enabled PC  USB 2.0 host controller ®  Windows 98/98SE/ME/2000/XP/Vista/Windows 7...

  • Page 6: Package Contents

    ACKAGE ONTENTS  (1) USB 2.0 Fast Ethernet Adapter Cable  Installation CD  User Guide...

  • Page 7: Software/Device Installation-Win 2000, Xp, Vista, Win 7

    ISTA Step 1 Insert the CD into your CD-ROM. A menu should appear. Click the “81672-USB 2.0 Fast Ethernet” button and then on the next menu, click the button that represents your current operating system. This will begin the AX88772 Windows Driver Setup Program.
  • Page 8 2000, XP, V OFTWARE EVICE NSTALLATION ISTA Step 3 Plug the USB 2.0 Fast Ethernet Adapter into a USB port. Windows will recognize the adapter and you are now ready to use it by plugging in your network cable to the RJ45 female port. The adapter will be labeled as a Local Area Connection (or something similar) in your Network Connections folder.

  • Page 9: Software/Device Installation-Win 98 And Me

    OFTWARE EVICE NSTALLATION Step 1 Plug in the USB 2.0 Fast Ethernet Adapter into a USB port on your PC. Step 2 Windows 98/ME users will be asked to select a driver location. Check ONLY specify a location, and then type (or browse to) the following.

  • Page 10: Verify Installation

    ERIFY NSTALLATION 98SE/ME ERIFY UCCESSFUL NSTALLATION IN INDOWS 1. From the main desktop, double-click My Computer; double-click Control Panel, System, and then Device Manager. 2. You should see a category called Network Adapters, and a device called Asix AX88772 USB to Fast Ethernet Adapter (or something similar).

  • Page 11: Explanation Of Leds

    XPLANATION OF The top of the USB 2.0 Fast Ethernet Adapter has a series of LED’s to provide you with at-a-glance diagnostic and status information. LINK/ACT – This is a yellow LED that when lit, tells you that you have a good connection to your network. If it is not lit, check your Ethernet cable.

  • Page 12: Un-Installation

    INSTALLATION Users can uninstall the AX88772 driver package from the following “Add or Remove Programs” dialog if necessary.

  • Page 13: Troubleshooting

    Ethernet network. C2G can only assist with questions or issues related to installing the adapter itself or the adapter drivers. For assistance with other issues, please consult the following list: - For questions about using your computer on the network, please utilize the Windows help files and wizards.

  • Page 14: Technical Specifications

    ECHNICAL PECIFICATIONS Product No. 81672 Complies USB Rev. 1.1 and 2.0 USB A Male Connectors RJ45 Female Housing Plastic 70mm x 38.7mm x Product Dimension 24.2mm Product Weight 0.20 lbs USB Cable Length 7.5 in.

  • Page 15: C2G One Year Warranty

    ARRANTY At C2G, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device.

  • Page 16: Important Safety Information

    ©2012 C2G. Microsoft and Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. This product is not endorsed or manufactured by Microsoft Corporation.
  • Page 18 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.c2g.com . R1.04.20.12...
