Casio 2413 Getting Aquainted

Module No. 2413
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to carefully read this manual and keep it on hand for later reference
when necessary.
Precautions
This watch is intended for use up to skin diving and snorkeling. It is not designed for
use during scuba diving.
Never operate the buttons of the watch while underwater or while floating on the
water's surface.
Before Skin Diving/Snorkeling
Before beginning skin diving or snorkeling, check to make sure that neither of
the following is on the display.
ERROR message (indicating sensor malfunction)
BATT message (indicating low battery power)
Make sure that the watch is set to the correct time of day.
Check the glass, case and band for cracks or chips.
Make sure that the band is fastened securely around your wrist.
While Skin Diving/Snorkeling
The indicator ERROR on the display may indicate bad data.
To avoid scratching the watch, take care when skin diving/snorkeling near
rocks or coral.
Press C to change from mode to mode.
In any mode (except for the Stopwatch Mode), press B to illuminate the display.
Timekeeping Mode
Sensor
Press C.
TIMEKEEPING
Use the Timekeeping Mode to set and view the current time and date.
You can display either of two screen formats in the Timekeeping Mode: a Time and
Date screen or a Time and Pressure Graph screen. Press D in the Timekeeping
Mode to toggle between the two screens.
Time and Date Screen
Month – Day
Day of
the week
PM indicator Seconds
Hour : Minutes
To reset the seconds count to zero
1. While the Time and Date screen is on the display in the Timekeeping Mode, hold
down A until the second's digits start to flash, which indicates the setting screen.
2. Press D to reset the seconds count to
Pressing D while the seconds count is in the range of 30 to 59 resets the
seconds to and adds 1 to the minutes. In the range of 00 to 29, the minutes
00
count is unchanged.
3. Press A to exit the setting screen.
To set the time and date
1. While the Time and Date screen is on the display in the
Timekeeping Mode, hold down A until the second's
digits start to flash, which indicates the setting screen.
2. Press C to move the flashing around the display in the sequence shown below to
select other settings.
Seconds
Day of the week
3. While a setting is flashing, press D (+) to change it.
While any setting is flashing on the display, press B to toggle between 12-hour
timekeeping and 24-hour timekeeping.
4. Press A to exit the setting screen.
Barometer Mode
Time and Pressure
Graph Screen
Press D.
00 .
Hour Minutes
Day Month
GETTING ACQUAINTED
After Skin Diving/Snorkeling
To avoid corrosion, rinse your watch thoroughly with fresh water to remove
salt water, dirt, etc. (When possible, soak the watch in fresh water overnight to
make sure that all salt is removed.)
When using a metal band, occasionally clean inside the gaps in the band
using a soft toothbrush and soapy water. Failure to do so can result in
corrosion of the watch, soiling of clothing, or irritation to sensitive skin.
About This Manual
GENERAL GUIDE
Altimeter Mode
Note
The watch does not make any allowance for leap years. Be sure to make the
necessary changes to the date setting to allow for February 29 during a leap year.
This watch uses a pressure sensor to measure air pressure (barometric pressure).
There are two types of measurements: regular barometric pressure readings and
Barometer Mode barometric pressure readings , which are described below.
You can calibrate the pressure sensor if you suspect the barometric pressure
reading is incorrect.
Important!
The pressure sensor built into this watch measures changes in air pressure, which
you can then apply to your own weather predictions. It is not intended for use as a
precision instrument in official weather prediction or reporting applications.
Regular Barometric Pressure Readings
The watch takes regular barometric pressure readings every three hours starting from
midnight each day. The data produced by these readings is used for the graphic
display and barometric pressure graph in the Timekeeping Mode.
Measurements are taken nine, six, and three seconds before each of the regular
measurement times.
The watch calculates the average of the three readings, and displays the result.
Regular barometric pressure readings are different from the readings taken in the
Barometer Mode. Regular barometric pressure readings are used as the data for the
barometric pressure graph and graphic indicator on the Time and Pressure Graph
Screen in the Timekeeping Mode.
To display regular barometric pressure reading graphics
In the Timekeeping Mode, press D to display the Time and Pressure Graph Screen
for the regular barometric pressure readings.
The barometric pressure graph shows the relative changes between readings for the
past 18 hours. The flashing marker on the right indicates the latest reading.
Graphic indicator
Button operations are indicated using the letters shown
in the illustration.
Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "REFERENCE" section.
Depth Gauge Mode
Stopwatch Mode
BAROMETER
Example: 10:58pm
3:00am – 6:00am – 9:00am – Noon – 3:00pm – 6:00pm – 9:00pm
Up
No change
Down
Barometric Pressure Graph
2413-1
Alarm Mode
