Vandersteen Audio SEVEN Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Thank you for choosing the Vandersteen Model Seven Reference Loudspeaker System. While the
grilles are removable, we recommend that you leave them on the speakers at all times. The Model
Sevens were engineered and measured with their grilles in place. Removing the grilles compro-
mises the performance of the speakers and exposes the drivers to possible damage from probing
fingers. For a complete understanding of the Model Seven's innovative technology and unique fea-
tures we recommend that you review this entire manual before connecting or using your new
speakers.
The Model Seven combines the superior openness and
realism of the legendary Vandersteen boxless design with the
powerful, extended bass of an
amplified subwoofer in a com-
pact and elegant loudspeaker.
Unique features optimize the
Model Seven for a wide vari-
ety of placements, environ-
ments, and system configura-
tions. It is available in any
automotive finish to comple-
ment any décor.
The Model Seven incorpo-
rates advanced patented Car-
bon Fiber/Balsa sandwich cones and domes for the midbass,
midrange and tweeter. This technology allows true piston
operation for each driver in its pass-band, allowing very low
distortion and uniformity in sound. This innovation offers
Unless the high-pass crossover is built into the electronics, (See page 3.) the Model
Seven system requires a M5-HP crossover between the preamplifier and main power
amplifier that is matched to the input impedance of the power amplifier. Using the
speakers without a properly configured M5-HP in place will severely damage the
midbass drivers. The drivers in your Model Sevens are critically paired to within one
tenth of a dB. In most cases if one driver is damaged, the pair must be replaced.
Physical damage (probing fingers) or damage due to a missing or improperly config-
ured M5-HP crossover will require non-warranty replacement of two very expensive
drivers. (Minimum $480.00 per pair for the tweeters alone.)
High-Pass Electronics
The Speaker Cables
Bi-Wire Connections
V
ANDERSTEEN
M
S
ODEL
EVEN
L
OUDSPEAKER
M
ANUAL
C
ONTENTS
Listening Height
2
2
Plugging-In The SW Amp
3
LF Room Optimization
4
Controls
5
6
7
8
11
incredibly transparent reproduction because all drivers
from 100Hz and above are made of the same material
R
EFERENCE
O
PERATIONS
|
tailor your Model Sevens to your own personal taste.
The Vandersteen Model Seven is designed and built in
the United States of America.
11
SW Amplifier Replacement
11
Crossover Replacement
12
12
Driver Replacement
13
Troubleshooting
15
Common Questions
15
15
PACKING INFORMATION
15
WARRANTY
1
$5.00
Vandersteen Audio
with exactly the same char-
acteristics. These very stiff
diaphragms allow for dy-
namic contrast unheard of
with typical materials. On
the rear input plate are
eleven room compensation
controls that a qualified tech-
nician uses to match the low
frequencies to the listening
room, and level and contour
controls that allow you to
17-18
Model Seven Operation Manual
16
16
16
18
18
18
19
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEVEN and is the answer not in the manual?

Questions and answers

Summary of Contents for Vandersteen Audio SEVEN

  • Page 1: Table Of Contents

    For a complete understanding of the Model Seven’s innovative technology and unique fea- tures we recommend that you review this entire manual before connecting or using your new speakers.

  • Page 2: Setting-Up

    These examples show the interaction between the external cross- power and control of the Model Seven’s internal 400 watt over, the main amplifier and the Model Seven subwoofer section. amplifier.
  • Page 3 Without reference recordings, it is easy to fall into the trap of trying to retune the system for every different recording. Model Seven Operation Manual...
  • Page 4 The Model same type. While it is tempting to use a cable known for Seven easily passes the amount of information required good bass response on the low frequencies and a different to hear these differences between cables.
  • Page 5 If your amplifier has multiple impedance taps, try the 4 ohm taps and 8 ohm taps to see which sound better. (They will sound different.) The Model Seven is an easy load and always stays between 4 and 8 ohms so there is no danger of damaging your amplifier or the speakers by using either set of taps.

  • Page 6: Vertical Bi-Amp Connections

    If your amplifier has multiple impedance taps, try the 4 ohm taps and 8 ohm taps to see which sound better. (They will sound different) The Model Seven is an easy load and always stays between 4 and 8 ohms so there is no danger of damag- ing your amplifier or the speakers by using either set of taps.

  • Page 7: Internal Bi-Wire Connections

    4 ohm taps and 8 ohm taps to see which sound better. (They will sound different.) The Model Seven is an easy load and always stays between 4 and 8 ohms so there is no danger of damaging your amplifier or the speakers by using either set of taps.

  • Page 8: Speaker Placement

    With their extensive subwoofer controls and room compensation adjustments, the Model Seven’s low frequency response can be optimized for any placement. The speakers’ positioning will effect the midbass, midrange, and treble performance with some positions offering better imaging and superior frequency balance and de- tail.
  • Page 9 By overlaying the width and length graphs, we can see speakers will sound best placed on a short wall, while in the intersection points of the lines. These points represent other rooms the speakers will work better on a long wall. Model Seven Operation Manual...
  • Page 10 The Model Sevens break-in and significantly improve during the first 100 hours of use. Until this period has elapsed, the speakers exhibit some sonic aberrations as the parameters of the Model Seven were established with completely broken-in drivers. ANDERSTEEN UDIO...

  • Page 11: Installing The Cones

    At no time should the weight of Be careful not to cross thread the the speaker be on the cones with less than seven threads into cones as you install them into the bot- the speaker bottom. Two people are required to safely in- stall the cones.
  • Page 12 The Model Seven amplifier levitates the subwoofer cone and centers the voice coils. If the subwoofer amplifier has been unplugged for more than a few hours - includ- ing when the speakers are first set-up - avoid playing deep bass above a moderate conversational level until the amplifier has been plugged-in for at least one hour to allow the subwoofer driver to center.
  • Page 13 REQUENCY EVEL ONTROLS Three controls on the Model Seven’s input plate allow the speakers are positioned according to previous instruc- you to tailor the characteristics of the speaker’s bass and tions, that the cones are installed with the tilt required to...
  • Page 14 The decision to incorporate the rear tweeter into the The Model Seven’s Low-Frequency Contour control is Model Seven was not an easy one. Even though it can pro- leveled from 1 to 10. As shown in the graph below, posi-...

  • Page 15: Amplifier Requirements

    The input terminals on the Model Seven and the spade Do not use Windex or any product with ammonia on the lugs on the speaker wire should be cleaned periodically Model Seven.

  • Page 16: Battery Replacement

    ATTERY EPLACEMENT The Model Seven contains an internal battery pack battery pack. The measurement process will drain that continuously biases some of the crossover compo- the batteries more than several months of normal nents. The battery pack is mounted on the crossover use.
  • Page 17 Do not touch the three screws forming the green wires coming from the square module. inner circle. 4. The tweeter will be serviced with the module. Model Seven Operation Manual...

  • Page 18: Support

    SUPPORT This manual has dealt with the installation, use, and capabilities of Vandersteen Model Seven loudspeakers. You should review this manual with anyone who will use the audio system to insure that they will exercise proper care and judgment.
  • Page 19 Please keep the boxes, pallets and hard- ware. Replacement boxes and pallets must The Model Seven must be bolted to its pallet and prop- be shipped by truck and will cost at least erly packed in its original box prior to shipment.
  • Page 20 The speaker must be packed in the original packing and returned to VANDERSTEEN AUDIO via insured freight by the customer at his or her own expense. A returned product must be accompanied by a Return Authorization Form, (available from VANDERSTEEN AUDIO upon request) which includes a written description of the defect and return shipping information.
