- Page 1 LAVADORA-SECADORA WASHER-DRYER WDJD 1082 MANUAL DE USO INSTRUCTION BOOKLET 124976161...
- Page 2 YOUR NEW WASHER-DRYER This new washing machine, which is fitted with Measure out detergent according to the the Jet System, patented Zanussi, meets all water hardness, the degree of soiling and the modern needs for effective treatment of laundry quantity of laundry being washed.
-
Page 3: Table Of Contents
CONTENTS Warnings Maintenance Bodywork Description of the appliance Detergent dispenser drawer Detergent dispenser drawer Drain filter Water inlet filter Technical specifications Emergency emptying out Frost precautions Installation Transit devices Something not working? 42-43 Positioning Water inlet Water drainage Electrical connection Door reversal Control panel Controls... -
Page 4: Warnings
WARNINGS It is important that this instruction book be kept with the appliance for future reference. If you sell or give the appliance away, make sure that the book is passed to the new owners so that they can familiarise themselves with its operation and relevant warnings. The following warnings are provided in the interests of overall safety. -
Page 5: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE 01 Detergent dispenser drawer 02 Programme card 03 Drying pilot light 04 Drying time selector dial 05 Delicate drying button 06 On/Off button 07 Temperature selector dial 08 Operating pilot light 09 Programme selector dial 10 Door handle 11 Filter 12 Adjustable feet Detergent dispenser drawer and... -
Page 6: Installation
INSTALLATION Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. 1. Using a spanner, unscrew and remove the rear right-hand bolt and lay the machine on its back, taking care not to squash the hoses. -
Page 7: Water Inlet
Water inlet Connect the water inlet hose to a tap with a 3/4" thread after having inserted the small filter “A” supplied with the machine. The other end of the inlet hose which connects to the machine can be turned in any direction. Simply loosen the fitting, rotate the hose and retighten the fitting, making sure there are no water leaks. -
Page 8: Door Reversal
Door reversal The opening direction of the outer door on this washing machine can be reversed. To carry out this operation, proceed as follows: 1) Disengage the end of the catch (1) from the door and turn it through 90° to remove it from its seat (Fig. -
Page 9: Use
Control panel 1 Detergent dispenser drawer 5 On/Off button Press this button to start the machine, press 2 Drying pilot light again to interrupt a programme or switch off the power supply to the machine. It illuminates when drying starts. 6 Temperature selector dial 3 Drying time selector dial Turn this dial clockwise or anti-clockwise to select... -
Page 10: Programme Selection
Programme selection Automatic washing and drying Washing only (NON-STOP programme) Load size: Automatic washing and drying is only – cotton, linen max 4.5 kg possible with linen, cotton and synthetics – synthetics, delicate fabrics programmes. – woollens The maximum load size is 2.25 kg for cotton –... -
Page 11: Washing And Drying Hints
Washing and drying hints Washing a maximum load makes the most efficient use of water and energy. For heavily soiled laundry, reduce the load size. Sorting the laundry Follow the wash code symbols on each garment Laundry weights label and the manufacturer’s washing instructions. Sort the laundry as follows: The following weights are indicative: whites, coloureds, synthetics, delicates, woollens. -
Page 12: Detergents And Additives
Red wine: soak in water and detergent, rinse Follow the product manufacturer’s and treat with acetic or citric acid, then rinse. recommendations on quantities to use and do Treat any residual marks with bleach. not exceed the «MAX» mark in the detergent dispenser drawer. -
Page 13: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 14: Operating Sequence
Operating sequence Automatic washing and drying (non-stop programme) This option is only possible for cottons and synthetics. Maximum load: – cotton, linen 2.25 kg – synthetics 1.50 Before washing your first load of laundry, we recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. -
Page 15: Select The Drying Time
6. Select the drying time Turn the selector dial clockwise to the required time setting (blue or green sector). M0031S 7. Select the programme and start the machine Turn the programme selector dial clockwise to the required programme and press the On/Off button: the operating pilot light comes on and the machine starts to operate. -
Page 16: Washing And Drying Programmes
Energetic programmes for cotton and linen Maximum load: washing 4.5 kg washing+drying 2.25 kg Washing Possible Progr. Temp. Type of laundry Cycle description option Wash at 60°-90°C Whites, 60°-90° 3 rinses normally soiled Long spin Wash at 40°-60°C Coloureds, 40°-60° 3 rinses normally soiled Long spin... - Page 17 Delicate programmes for synthetics, mixed fibres, delicates, and woollens Maximum load: washing 2 kg (woollens 1 kg) washing+drying (synthetics) 1.5 kg At the end of these programmes, the last rinse water is not emptied out, so as to avoid creasing of the fabrics.
-
Page 18: Maintenance
MAINTENANCE 1. Bodywork Clean the outside of the machine with warm water and a neutral, non-abrasive household detergent. Rinse with clean water and dry with a soft cloth. Important: do not use methylated spirits, solvents or similar products to clean the bodywork. -
Page 19: Water Inlet Filter
4. Water inlet filter If you notice that the machine is taking longer to fill, check that the filter in the water inlet hose is not blocked. Turn off the water tap. Unscrew the hose from the tap and remove the filter. -
Page 20: Something Not Working
SOMETHING NOT WORKING? Problems which you can resolve yourself Problem Possible cause The machine does not start up: Check that the door is firmly closed. Check that the machine is plugged in and that there is power at the socket. Check that the main fuse has not blown. - Page 21 The door will not open: The programme is still running. The door lock has not been released. There is water in the drum. Spinning starts late or the The electronic unbalance detection device has cut in because the laundry is not evenly machine does not spin: distributed in the drum.
