Magneplanar DW 1 Woofer Instruction Manual

Table of Contents

1. Introduction/General Description

2. Carton Contents

3. Packaging

Introduction/General Description
1.
The Magneplanar DW 1 is a dipole, thin-film planar/magnetic woofer which is a derivative of the MG 20.1
DiPlanar woofer technology. The DW 1 can be driven simultaneously by 3 separate amplifiers (typically the front
left, center and right channels).
The DW 1 is a "fast" woofer with flat response to 5 kHz which makes the DW 1 ideal for blending with all
Magneplanar on-wall models or center channels that have limited bass response.
Carton Contents
2.
1 - DW 1 Loudspeaker
1 - Magnepan "Shaped" Pink Noise CD Test Disk
1 - Hex Wrench
1 - Speaker Logo
1 - Owner's Manual
Packaging
3.
Save all packaging. The DW 1 can be shipped safely only in the original packaging. Should you discard it,
packaging is available from Magnepan.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAGNEPLANAR DW 1

  • Page 1 DiPlanar woofer technology. The DW 1 can be driven simultaneously by 3 separate amplifiers (typically the front left, center and right channels). The DW 1 is a "fast" woofer with flat response to 5 kHz which makes the DW 1 ideal for blending with all Magneplanar on-wall models or center channels that have limited bass response.
  • Page 2 Cosmetically, the front and back of the DW 1 are identical. To identify the back of the speaker and ensure proper phasing, the back of the DW 1 can be identified as shown in Fig. 1. Connect the output of a high pass crossover (such as the Magneplanar XO 2) to the input of the DW 1 (observing correct polarity).
  • Page 3 The DW 1 is a woofer, not a subwoofer. And the superior performance of the DW 1, as compared to a subwoofer, is due in part, to extremely wide bandwidth (flat to 5 kHz). The DW 1 can seamlessly cross over at a higher frequency to any of the limited bandwidth "Maggie"...
  • Page 4 Phasing The Magnepan Pink Noise CD Test Disk included with your DW 1 can be used to determine if the DW 1 is in phase with your limited bandwidth Magneplanar. The test CD has a 9 db peak at 80-100 Hz that draws attention to the frequencies which will be depressed in an out-of-phase condition.
  • Page 5: Specifications

    Service and Shipping In the unlikely event you should need service for your DW 1 Woofer, we recommend you return it through your dealer. He is experienced in providing service and can assist you if the speaker must be returned to the factory. If...
