Summary of Contents for Mira fight ACE
- Page 1 pivot and bi-fold door installation and User Guide These instructions must be left with the user 1115815-W2-C...
-
Page 2: Table Of Contents
ConTenTs Introduction ..................... 3 General ....................3 Guarantee .................... 3 recommended Usage ................3 Pack Contents ..................4 safety precautions .................. 5 General ....................5 Installation ....................5 Maintenance ................... 17 General Maintenance ................. 17 Cleaning ..................... 17 Care ....................17 Chrome Parts .................. -
Page 3: Introduction
Follow all warnings, cautions and instructions contained in this guide. Guarantee For domestic installations, Mira Showers guarantee this shower enclosure against any defect in materials or workmanship for a period of ten years from the date of purchase. For non-domestic installations, Mira Showers guarantee this shower enclosure against any defect in materials or workmanship for a period of one year from the date of purchase. -
Page 4: Pack Contents
PaCk ConTenTs Tick the appropriate boxes to familiarise yourself with the part names and to confirm that all of the parts are included. 4 x Plastic Covers 2 x U Channels 8 x Concealing Caps 12 x Screws (8 required for Pivot and Bi-fold Door) 8 x Plastic Washers 1 x Pivot Door or bi-fold door... -
Page 5: Safety Precautions
saFeTy PreCauTIons General Care should be taken when drilling into walls and floors to avoid any hidden pipes or wires. We strongly recommend that all glass panels are moved by a minimum of two people and that any protective packaging along the glass edges is kept in place for as long as possible to prevent damage before installation. - Page 6 (a) Install the shower tray in accordance with the manufacturer’s instructions. Caution! Make sure that the shower tray is level and that the walls are vertical and square. note! Cover the tray waste to prevent the loss of small parts. note! Protect the tray surface during enclosure installation.
- Page 7 (a) Position the U-channel (handle side) on the wall. Using a spirit level make sure that it is upright. (b) Mark the position of the fixing holes, then remove the U-channel. (c) Drill with a 6 mm masonry bit (not supplied) and plug using the wall plugs (supplied).
- Page 8 (a) Position the second U-channel (pivot side) on the wall. Using a spirit level make sure that it is upright. (b) Mark the position of the fixing holes, then remove the U-channel. (c) Drill with a 6 mm masonry bit (not supplied) and plug using the wall plugs (supplied).
- Page 9 Doors are reversible for lH or RH fitting (a) Install the first U-channel over the door frame and hold in position. 1115815-W2-C...
- Page 10 (a) Install the door frame over the U-channel that had been secured to the wall earlier. (b) Adjust the door frame so that it is in the correct position. 1115815-W2-C...
- Page 11 (a) Open the door and remove the rubber sealing strip. (b) Partially install the fixing screws. (c) Apply silicone sealant according to the manufacturers instructions along the length of the wall. (d) Fully tighten the fixing screws, making sure that the U-channel is upright. (e) Refit the rubber sealing strip.
- Page 12 (a) Lift up the door frame within the U-channels and apply silicone sealant in accordance with the manufacturers instructions to the area shown. (b) Lower the door frame until it sits firmly on the shower tray. Remove any excess sealant. (c) Centralise the door frame within the U-channels, making sure that the door frame is square.
- Page 13 L & R (a) Drill four 3 mm holes from inside the shower enclosure in the door frame and through into the U-channel with the 3 mm HSS drill (supplied). (b) Install the plastic washer and the screw. (c) Tighten the screws and fit the plastic concealing caps. (d) Repeat the process for the other U-channel.
- Page 14 L & R (a) Apply sealant in accordance with the manufacturers instructions along the inner surfaces of the door frame. 1115815-W2-C...
- Page 15 (a) Partially remove the door sealing strips as shown above. (b) Apply a small amount of sealant in accordance with the manufacturers instructions as shown above. (c) Fit the door sealing strips back in position. Remove any excess silicone sealant. 1115815-W2-C...
- Page 16 Pivot Door Only Door Catch In (Clockwise) Adjustment 24hrs (Anti-clockwise) (a) Fit the plastic covers to the top of the extrusions. (b) Apply sealant in accordance with the manufacturers instructions along the bottom of the door frame. (c) Fit the door handle to the door. (d) For the Pivot Door only - fit the splash guards and adjust the door catch if necessary (e) Allow the silicone sealant to cure for 24 hours before use.
-
Page 17: Maintenance
MaInTenanCe General Maintenance Providing the shower enclosure has been correctly installed and is operated in accordance with the instructions contained in this guide, difficulties should not arise. If any maintenance is required then it must be carried out by a competent tradesperson to whom the maintenance instructions are provided. -
Page 18: Spare Parts
sPare ParTs 200071 200470 302325 200504 200652 308168* 302328 200470 200470 302328 204325 200470 202157 200470 200652 302325 200470 200470 204124 1115815-W2-C... - Page 19 1115815-W2-C...
-
Page 20: Customer Service
Guarantee of Quality As part of our quality and training programme calls may be recorded or monitored. Mira Showers guarantee your product against any defect in materials or workmanship, provided that it is installed and maintained in accordance with the Our Customer Services Team is comprehensively instructions given in this guide.
