Summary of Contents for Yamaha YST-SWO11
-
Page 2: Precautions: Read This Before Operating This Unit
• Secure placement or installation is the owner’s If the vessel falls by vibrations and water spills, it responsibility. YAMAHA shall not be liable for any may cause damage to the speaker, and/or you may get accident caused by improper placement or installation of the subwoofer. -
Page 3: Table Of Contents
Pre-adjusting the subwoofer volume ..........4 Advanced Yamaha Active Servo Technology ....... . 5 Troubleshooting . -
Page 4: Positioning The Subwoofer
Positioning the subwoofer One subwoofer will have a good effect on your audio system, however, the use of two subwoofers is recommended to obtain more effect. If using one subwoofer, it is recommended to place it on the outside of either the right or the left front speaker. -
Page 5: Connections
Connections Connecting components and the Caution: Plug the power cables for the sub- woofer and other audio/video components into subwoofer to AC power an AC outlet only after you complete all other connections. After you complete a subwoofer connection, plug the amplifier, other audio/video component, and Basic connection example the subwoofer into an AC outlet of appropriate... -
Page 6: Using The Subwoofer
Using the subwoofer Pre-adjusting the subwoofer volume INPUT Before you use the subwoofer, first adjust the vol- Rear panel ume balance between the subwoofer and the front speakers by following the procedure below. Set the VOLUME control to minimum (0). VOLUME INPUT VOLUME... -
Page 7: Advanced Yamaha Active Servo Technology
Advanced Yamaha Active Servo Technology The theory behind Yamaha Active Servo Technol- By employing negative-impedance drive circuits, ogy is based on two factors: the Helmholtz resona- the amplifier is able to generate precise, low-ampli- tor and negative-impedance drive. Active Servo... -
Page 8: Troubleshooting
Refer to the chart below if the unit does not function properly. If the problem you are experiencing is not listed, or if the instructions fail to help you resolve the problem, disconnect the power cord and contact your authorized Yamaha dealer or service center. Problem... -
Page 9: Specifications
Specifications YST-SW011 Frequency characteristics Type..Advanced Yamaha Active Servo Technology <YST-SW011> Driver ......... 20 cm (8") cone woofer 100 dB Magnetically shielded type Output Power ..........50 W Dynamic Power .........100 W, 5 Ω Input Impedance ..........12 kΩ Frequency Response ....30 Hz – 200 Hz Input Sensitivity..... - Page 10 YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA...
