Pocketalker ® Ultra Personal Amplifier •

Description:

The Pocketalker Ultra amplifies sound clearly and easily for better understanding. 100 hours of bat-
tery life ensures long-lasting performance. Each Pocketalker Ultra includes a plug-in sensitive micro-
phone; and for the TV listener: a TV listening extension cord. Use the Pocketalker Ultra with a vari-
ety of available earphones and headphones of your choice, or, a neckloop and a telecoil-equipped
hearing aid. With the optional Telelink adapter, listeners can use the Pocketalker Ultra to amplify
telephone calls to a comfortable listening level.

Applications:

• 1-on-1 Conversations • TV Listening • Listening in the Car • Small Groups and much more
PKT D1 Personal Amplifier:
Dimensions:
Weight:
Color/material:
Battery Type:
Battery Life:
Low Battery Indicator:
Microphone:
Tone Control:
Volume Control:
Microphone Jack:
Headphone Jack:
Accessories included:
Options:
Approvals:
Warranty:
Electrical Specifications (1k Hz ref.):
Distortion:
Frequency Response:
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
©2006, Williams Sound Corp. MCAT 033C
3.38"L x 2.23"W x .88" THK. (85.8mm x 56.6mm x 22.3 mm)
(Not including belt clip or microphone assembly)
2.5 oz. (70.9 grams) (with batteries and microphone)
Silver gray, ABS/Polycarbonate molded plastic case.
Two 1.5V (AAA size) alkaline
100 hours (typical usage)
Red light on top panel flashes.
Omnidirectional, electret microphone assembled in housing
with foam wind screen and 3.5mm mono plug.
External rotary control knob to allow user to optimize hearing.
External rotary control knob with power ON-OFF switch.
3.5 mm, mono, gold plated mini plug.
3.5 mm, mono, nickel plated mini plug.
Belt clip: Allows the user to wear the unit on a belt.
Lanyard: Allows the user to wear around the neck.
TV listening extension cord: extends the microphone to 12 ft.
Unit comes packaged with one of the Williams Sound options:
Mini earphone, single (EAR 013)
Dual mini earbud (EAR 014)
Wide range earphone; single (EAR 008)
Lightweight headphone (HED 021)
Wide range headphone (HED 026)
Induction neck loop (NKL 001)
CE, RoHS, WEEE
5 years, parts and labor (90 days on accessories)
Power output: 50 mW (max) into 16 ohms
AGC: Limits maximum output level
2% THD (max)
Tone at high position: 11dB boost at 5kHz, 8dB cut at 400 Hz.
Tone at mid position: 0dB boost at 5kHz, 4dB cut at 400Hz.
Tone at low position: 3dB cut at 5kHz, 4dB boost at 400 Hz.
www.ActiveForever.com
Model PKT D1
Tone
Control
1
Power
Belt Clip
On/Off
Mic Indicator
Jack
(3.5mm)
Earphone
Jack
PKT D1 Top
Plug-in
Mic
Volume
Control
Lanyard
P o c k e t a l k e r TM
Connection
PKT D1 Front
