Sony D-E505 Operating Instructions

3-864-732-21 (1)
Compact Disc
Compact Player
Operating Instructions
About area code
The area code of the player you purchased is shown on upper left of the bar
code label on the package.
For accessories supplied with your player, check the area code of your model
and refer to "Supplied accessories" toward the end of this manual.
D-E505
D-E554
Sony Corporation ©1998 Printed in Malaysia
For the customers in the USA
Welcome!
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
Thank you for purchasing the Sony
These limits are designed to provide reasonable
Compact Disc Compact Player.
protection against harmful interference in a
Before operating your player, please
residential installation. This equipment
read this manual and retain it for
generates, uses, and can radiate radio frequency
future reference. energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
About this manual
However, there is no guarantee that interference
The instructions in this manual are for the
will not occur in a particular installation. If this
D-E505 and D-E554. Before you start reading,
equipment does cause harmful interference to
check your model number.
radio or television reception, which can be
determined by turning the equipment off and on,
Owner's Record the user is encouraged to try to correct the
The model and the serial numbers are located at interference by one or more of the following
the bottom. Record these numbers in the spaces measures:
provided below. Refer to them whenever you - Reorient or relocate the receiving antenna.
call upon your Sony dealer regarding this - Increase the separation between the equipment
and receiver.
product.
- Connect the equipment into an outlet on a
Model No. __________ Serial No.__________ circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV
WARNING
technician for help.
You are cautioned that any changes or
To prevent fire or shock modifications not expressly approved in this
manual could void your authority to operate this
hazard, do not expose
equipment.
the unit to rain or
For the customers in Australia
moisture.
The supply cord of the AC power adaptor cannot
be replaced; if the cord is damaged, the AC
power adaptor should be discarded.
To avoid electrical
shock, do not open the
For the customers not in Poland
cabinet. Refer servicing
The mark on the unit is valid only for
to qualified personnel products marketed in Poland.
only.
For the customers not in Europe
The CE mark on the unit is valid
CAUTION only for products marketed in the
The use of optical instruments with this product European Union.
will increase eye hazard.
For the customers not in Russia
The mark on the unit and package
is valid only for products marketed
in Russia.
Playing a CD right
away!
If you want to play a CD right now, choose to use your player on house
current. Other choices are the following three: rechargeable battery, dry
batteries (see "Power Sources" on the reverse side) and car battery.
1
Connect
When using
earphones
AC power adaptor
Earphones
DC IN 4.5 V
2/REMOTE
For models supplied with the AC plug adaptor
If the AC power adaptor does not fit the wall outlet, use the AC plug adaptor.
For models supplied with the remote control
• Connect the plug of the earphones to the remote control.
• Connect the earphones to the remote control firmly. A loose connection may cause noise
during playback.
2
Place a CD
OPEN
Label side up
1
2
Slide OPEN to open the lid.
Fit the CD to the pivot.
3
Close the lid.
3
Play
2
Adjust the volume.
To use the player
1
1
2
Press the jog
Adjust the volume.
lever toward
^.
To stop play, press p.
To use the remote control zOther Operations
The lever marked with =-^-+ is the
jog lever. When you press or slide the lever,
Playing tracks repeatedly
operation starts.
(Repeat Play)
You can play tracks repeatedly in normal,
INTRO PGM, shuffle or RMS (Random Music
Sensor) play modes. Repeat all the tracks or
Slide Slide
only one track.
Press
To Do this
Pause Press the jog lever
toward ^.
Resume play after Press the jog lever
pause toward ^.
To repeat all the tracks
Find the beginning
Slide the jog lever
to a wall Press RPT/ENT (REPEAT/ENTER on the
of the current track =
toward
player) during play.
outlet
(AMS*) once.**
The "
Find the beginning Slide the jog lever
of previous tracks toward =
(AMS) repeatedly.**
Find the beginning Slide the jog lever
+
of the next track toward
To cancel repeat play, press RPT/ENT again.
once.**
(AMS)
To repeat a single track
Find the beginning Slide the jog lever
1 Press RPT/ENT while the track you want
of succeeding toward +
to repeat is playing.
tracks (AMS) repeatedly.**
The "
Go forward Slide and hold the
quickly jog lever toward
+.**
hold the
Go backwards Slide and
quickly jog lever toward 2 Press P (play) MODE (PLAY MODE on the
=.** player) repeatedly until "1" appears.
*AMS = Automatic Music Sensor
**These operations are possible during both
play and pause.
If you press RPT/ENT (REPEAT/ENTER on
To repeat another track, slide the jog lever
the player) to display " ", you can locate the
toward = or + .
tracks continuously in the following order:
• When using +: next track n next track
To cancel repeat play, press RPT/ENT again.
...... last track n first track n second track
......
• When using =: previous track n previous
track ...... first track n last track ......
Playing only the tracks
You can do the operations shown in the above
you want
table using the buttons with the same marks
on the player.
You can choose and play your favorite tracks
To remove the CD by scanning through the beginning of each
Remove the CD while track in a CD.
pressing the pivot.
Notes on controlling the volume with the
remote control
Set the VOL (volume) control on the remote
control to the maximum. Then adjust the 1
During play, press P MODE repeatedly
volume on the player to the level that you
until "INTRO PGM" flashes.
want to be the maximum volume of the remote
control.
Notes on display
• When you press ^ (when RESUME is set to
OFF), the total number of tracks in the CD
and the total playing time appear for about 2
2
seconds.
Press the jog lever toward ^ to start
• During play, the track number and the
scanning.
elapsed playing time of the current track
The player plays about the first 15
appear.
seconds of each track and "INTRO PGM"
• During pause, the elapsed playing time
flashes faster.
flashes in the display.
• Between tracks, the time to the beginning of
3
Press RPT/ENT while the track you want
the next track will appear with the "–"
is playing. To skip the track, slide the jog
indication.
lever toward + or just wait for the next
track.
Notes on handling CDs
• To keep the CD clean, handle it by its edge. After you have gone through the CD,
Press ^.
Do not touch the surface. "INTRO PGM" stops flashing and the tracks
• Do not stick paper or tape onto the CD. you have chosen play automatically.
• Do not expose the CD to direct sunlight or
heat sources such as hot air ducts. Do not To finish programming before going through
leave the CD in a car parked under direct
the whole CD, press the jog lever toward ^.
sunlight.
The selected tracks will be played.
If you press p, the program will be erased.
To prevent accidental erasure, set the
RESUME switch at the rear of the player to
ON.
Not these ways
To cancel INTRO PGM play, press P MODE
repeatedly until the play mode indication
disappears from the display.
Playing tracks in random
order
(Shuffle Play)
You can play the tracks in a CD in random
order.
^
= +
P MODE
During play, press P MODE repeatedly until
"SHUF" appears.
The tracks play in random order.
P MODE RPT/ENT
" indication appears. To cancel shuffle play, press P MODE
repeatedly until the play mode indication
disappears from the display.
Note
• During shuffle play, you cannot return to
previous tracks by sliding the jog lever toward
= .
Playing tracks in the order
" indication appears. you want
(RMS play)
You can program up to 22 tracks to play in
any order you choose.
^
= +
p
P MODE RPT/ENT
1
During play, press P MODE repeatedly
until "RMS*" flashes.
Flashing
(INTRO PGM Play)
*RMS = Random Music Sensor
2
Slide the jog lever toward = or + to
^ choose a track.
The track number and the playing order
= +
appear.
p
Track number Flashing
P MODE RPT/ENT
Playing order
3
Press RPT/ENT to program the track.
Flashing
4
Repeat steps 2 and 3 to program the
remaining tracks.
5
Press the jog lever toward ^ .
"RMS" stops flashing and the tracks you
have chosen play in the order you
specified.
If you press p, the program will be erased. To
prevent accidental erasure, set the RESUME
switch at the rear of the player to ON.
To cancel RMS play, press P MODE until
"RMS" disappears from the display.
To check the program
During programming:
Press RPT/ENT before step 5.
During RMS play:
Press P MODE repeatedly until "RMS"
flashes, then press RPT/ENT.
Each time you press RPT/ENT, the track
number and the playing order appear in the
order you specified.
Note
• If you program another track after the 22nd
track, the first track programed is cleared and
the new track is programed instead.
Using other functions
To minimize skipping (ESP 2 )
The ESP (Electronic Shock Protection)
function minimize skipping by using a buffer
memory that stores music data and plays it
back in the event of a shock.
The new ESP 2 (ESP Squared) system uses a
new DSP (Digital Signal Processor) which can
read and store music data more efficiently,
providing a level of continuous skip
protection not found in traditional buffer
memory units. This decreases the frequency
of sound skipping and the need to utilize the
buffer memory. Use this function when
listening in a car or while walking.*
2
* Although ESP provides excellent protection
against skipping, it will not prevent skipping
while jogging or running.
ESP
Press ESP.
The ESP indication appears.
To release the ESP function, press ESP again.
Notes
• Playing may stop when the player gets a strong
shock even with the ESP function on.
• You may hear a noise or sound skip when:
— listening to a dirty or scratched CD,
— listening to an audio test CD or,
— the player receives continuous shock.
• Sound may drop for a while if you press ESP
during play.
• When you use an optical digital connecting
cord, the ESP function will be disabled.
To enjoy more powerful bass sound
(Sound function)
You can enjoy a powerful bass-boosted sound.
SOUND
Press SOUND to select "MB (Mega Bass)" or
"GRV (Groove)." "GRV" is more effective.
Note
• If the sound is distorted when emphasizing
bass, turn down the volume.
To lock the buttons
You can lock your player against any
accidental operations.
You can still operate the player with the
remote control.
Slide HOLD in the direction of the arrow.
When you press any button, "Hold" appears in
the display and you cannot operate the player.
To unlock, slide HOLD back.
Continue to the reverse side m
