- Page 1 ZHT660 ZHT664 INSTRUCTIONS FOR INSTALLATION AND USE MONTAGE- UND GEBRAUCHSANWEISUNG INSTRUCTIONS POUR L'INSTALLATION ET L’UTILISATION ISTRUZIONI PER L'INSTALLAZIONE E L’USO INSTRUCCIONES PARA INSTALACIÓN Y USO INSTRUÇÕES DE INSTALAÇÃO Y UTILIZAÇÃO AANWIJZING VOOR GEBRUIK EN INSTALLATIE...
-
Page 2: Installation
ENGLISH DESCRIPTION The hood may be installed in the filtering or the ducting version. Filtering version (Fig. 1): The hood aspirates the kitchen air saturated with fumes and odours, purifies it through the grease filters and charcoal filters and returns clean air into the room. For constant efficiency, the charcoal filters must be replaced periodically. -
Page 3: Operation
- if the hood features a panel type charcoal filter (Fig. 15A), remove the charcoal filter by first of all removing the two filter retainers M (the two filter retainers must then be fitted back on). INSTALLATION IN FILTERING VERSION: Prepare a suitable power supply. - Page 4 Wiring Diagram (1 MOTOR) - Elektrischer Schaltplan (1 MOTOR) - Schéma Électrique (1 MOTEUR) - Schema Elettrico (1 MOTORE) - Esquema Eléctrico (1 MOTOR) - Esquema Eléctrico (1 MOTOR) - Elektrisch Schema (1 MOTOR) HOOD WITH SLIDE CONTROLS - GERÄT MIT SCHIEBEKNOPF-BEDIENUNG - HOTTE AVEC COMMANDES A CHARIOT - CAPPA CON COMANDI A SLITTA - CAMPANA CON MANDOS DESLIZANTES - EXAUSTOR COM COMANDOS DESLIZANTES - AFZUIGKAP MET SCHUIFKNOPBEDIENING...
- Page 5 Wiring Diagram (2 MOTORS) - Elektrischer Schaltplan (2 MOTOREN) - Schéma Électrique (2 MOTEURS) - Schema Elettrico (2 MOTORI) - Esquema Eléctrico (2 MOTORES) - Esquema Eléctrico (2 MOTORES) - Elektrisch Schema (2 MOTOREN) HOOD WITH SLIDE CONTROLS - GERÄT MIT SCHIEBEKNOPF-BEDIENUNG - HOTTE AVEC COMMANDES A CHARIOT - CAPPA CON COMANDI A SLITTA - CAMPANA CON MANDOS DESLIZANTES - EXAUSTOR COM COMANDOS DESLIZANTES - AFZUIGKAP MET SCHUIFKNOPBEDIENING...
- Page 7 Ø133 Ø 133 min650 Ø 8mm min650 MODELS 50cm 44cm 55cm 49cm 60cm 54cm 70cm 64cm 80cm 74cm 90cm 84cm...
- Page 8 MODELS 50cm 41cm 55cm 46cm 60cm 51cm 70cm 61cm 80cm 71cm 90cm 81cm Ø 6mm...
- Page 10 04306555/2 - SP2000 sen.nor.
