Seiko DM50 Instruction Manual

DIGITAL METRONOME DM50
INSTRUCTION MANUAL

NAME AND OPERATION OF PARTS

Power button
Press it to turn on and off the metronome and to change over the
displays.
Tempo LED display
It visually represents the tempo of the metronome with the
flashing of the LED.
Selector button
Press it to select the setting item from tempo, beat/rhythm and
volume.
Liquid crystal display
It indicates the tempo, beat/rhythm and volume settings you have
made and the current time.
DOWN button
UP button
Press the buttons to change the setting of the item selected by
pressing the selector button
Clip
Use it to attach the metronome to a music stand or musical score.
Speaker
It gives out the tempo sound of the metronome.
Reset switch
Push it when the battery is replaced with a new one or when the
metronome does not work properly.

HOW TO USE

The battery included with the metronome is a monitor battery, and
its life may be shorter than the specified period.
Changeover of displays
POWER OFF
display
Press the power
button . Press the
power button
METRONOME
display
Keep the power
button pressed.
Press the
power button
When the metronome is turned off (when the display is blank),
pressing the power button will turn it on. Another press of the
button will turn it off again.
.
Keep the power
button pressed.
.
TIME
display
Keep the
selector
button
pressed.
.

TIME SETTING

display

Tempo setting

1. Press the selector button
the display to "TEMPO". The tempo setting mode will be
shown on the display.
2. Press UP or DOWN
With each press, the tempo is increased or decreased by one,
respectively. The digits move quickly by 10 tempos if the
button is kept pressed.
30 ⇔ 31 ⇔ • • • • • ⇔ 119 ⇔ 120 ⇔ 121 ⇔ • • • • • ⇔ 249 ⇔ 250

Beat/rhythm setting

1. Press the selector button
the display to "BEAT". The beat/rhythm setting mode will be
shown on the display.
2. Press UP or DOWN
rhythm.
With each press, the beat/rhythm changes one by one in the
following order.
0 ⇔ 1 ⇔ 2 ⇔ 3 ⇔ 4 ⇔ 5 ⇔ 6 ⇔ 7 ⇔

Volume setting

1. Press the selector button
the display to "VOLUME". The volume setting mode will be
shown on the display.
2. Press UP or DOWN
desired level.
With each press, the volume level changes one by one in the
following order.
High ⇔ No sound ⇔ Low ⇔ Mid
Time setting
Keep the power button pressed when the power is turned off
or when the metronome display is shown. The time display will be
shown. Follow the procedure below to set the current time.
1. While in the time mode, keep the selector button
to show the time setting display.
2. Press the selector button
from hours and minutes. Press UP
set the desired time.
3. After the time adjustment is completed, press the power
button to return to the time display.
* To turn the power off, press the power button
* If you decide not to use the metronome for a long time, it is recommended that
the power is turned off to save battery energy.

MEMORY BACKUP FUNCTION

Even after the metronome is turned off, the settings you have made
are stored in memory and will not be erased.
If the battery is replaced with a new one or if the reset switch
pushed, the metronome will return to the following initial settings.
1. Tempo [120]
2. Beat/rhythm [0]
3. Volume [High]
to set " " mark at the bottom of
button to set the desired tempo.
to set " " mark at the bottom of
button to set the desired beat/
⇔ ⇔
to set " " mark at the bottom of
button to set the volume to the
pressed
to select the digits to be adjusted
or DOWN button to
again.
is
