- Page 1 TL AUDIO M4 TUBE CONSOLE...
- Page 2 USER MANUAL TL AUDIO M4 TUBE CONSOLE...
-
Page 3: Table Of Contents
M4 INTRODUCTION............................3 M4 MIXER TECHNICAL SPECIFICATION....................4 Mic Input: ................................ 4 Line Input:................................ 4 Phase Rev: ............................... 4 High Pass Filter: ............................. 4 Frequency Response: ............................4 Distortion:................................ 4 Noise: ................................4 EQ: ................................... 4 Insert Point: ..............................4 Track Output:.............................. -
Page 4: M4 Introduction
The M4 offers you the quality of our outboard, in a desk that is more compact and affordable than the VTC – but still offers you the same great sound. -
Page 5: M4 Mixer Technical Specification
M4 User Manual M4 MIXER TECHNICAL SPECIFICATION. Mic Input: Balanced XLR socket with switchable 48V phantom power, Gain range +16dB to +60dB with 30dB pad, Frequency response +0, -2dB, 20Hz to 40KHz (at 40dB gain), Input noise (EIN) -127dBu (150 ohm source, 22Hz to 22KHz), Switchable +48V Phantom Power. -
Page 6: Fader
Level trim +/-15dB, Nominal level switchable to +4dBu or -10dBu, Noise -85dBu / -97dBu (+4dBu / -10dBu nominal), Maximum level +22dBu / +12dBu (+4dBu / -10dBu nominal), Balanced output on TRS jack. Fader: 100mm “K” Series, Mute and PFL switches and LED’s, Routing to L+R busses via Pan control, “Drive”... -
Page 7: Digital I/O
Digital I/O: Optional digital ouput module for L+R outputs, and I/O module for each group of 8 channels. Outputs follow “Track” outputs, inputs normalled to analogue “Line” inputs. Please see separate sheets for digital specifications. Dimensions: All consoles are 815mm (32”) deep, plus at least 100mm (4”) at rear of console for PSU and audio connections, All consoles are 222mm (8.75”) high. -
Page 8: M4 Mixer Operation
Microphone Input When connecting a microphone to the M4, start with the gain set to a minimum value and gradually increase until the sound source is just tickling 0dB on the meters when the source sound is at average output level. -
Page 9: Phase Reverse
Phase Reverse The phase reverse switch, located to the bottom left of the gain control and labeled 'PHASE', is used to invert the phase of the input signal. It is active on both mic and line inputs. This function could be required when processing a signal that is out of phase with other signals in a mix, in which case the resultant phase error typically appears as a loss of low frequency content, due to cancellation of out of phase components. -
Page 10: Insertion Points
By making frequent comparisons you can make sure you do not stray from the required sound. It is also worth spending some time getting used to the EQ on the M4 - it sounds great and you'll be amazed how versatile and musical it can be. -
Page 11: Pan Control
Pan Control The pan control positions the image within the stereo field, from fully left in the anticlockwise position, through centre at the dented position to fully right in the clockwise position. The gain law is -3dB at the centre. Mute Switch The channel may be muted or switched on without affecting the level set on the channel fader. -
Page 12: Aux Masters
Monitor and Headphone Level The M4 provides a stereo monitor output, for connection to a power amplifier and monitor loudspeakers, plus a front panel headphone output. The Monitor level control governs the level of signal fed to both these outputs. The monitor signal... -
Page 13: Loudspeaker Mute
Digital Output Option The optional DO8 card can be fitted to the back of the M4 and each card provides 8 channels over ADAT lightpipe. This professional protocol makes for easy connection when conducting computer based recording, and makes the M4 the perfect front-end solution for digital recording set ups. -
Page 14: Wordclock Input
BNC-type terminated in 75 ohms. A FINAL WORD We hope you will enjoy your new M4 console, we're confident that once you start using it you'll wonder how you managed without one! For best results, switch your M4 console on 30 minutes before the start of your...
