These buttons / keys have several functions.
All functions of the respective buttons / keys outlined in the following chart below.
Your display in Button / Key Length of
dicates following to be pushed pushing the
information
TRP-AVS-RID- MODE 1
STP-MAX
TCNT-CLK-TOT- MODE 1
ODO1-ODO2-
TOTODO
TRP-AVS-RID MODE 1
TRP MODE 1
CLK MODE 1
ODO 1-ODO 2 MODE 1
RID-AVS-STP-MAX MODE 1
TCNT MODE 1
TCNT-CLK-TOT- MODE 2
ODO1-ODO2-
TOTODO
TRP-AVS-RID- MODE 2
STP-MAX
TRP-AVS-RID-MAX MODE 2
TCNT MODE 2
TOT MODE 2
STP MODE 2
any of the following MODE 1
information: +
TRP-AVS-RID-STP- MODE 2
MAX-TCNT-CLK-
TOT-ODO1-ODO2-
TOTODO
STP SS
What is going on?
button / key
brief (0.1 sec) next information from MODE 1 is indicated
brief (0.1 sec) computer changes display information from MODE 2 data to
TRP-data of MODE 1
normal (1.5 sec) TRP-AVS-RID are automatically rotated, one at a time displayed
for 1.5 sec.
long (5 sec) enter set-up mode for wheelsizes
long (5 sec) enter set-up mode for clock is
long (5 sec) enter set-up mode for odometers
long (5 sec) switching from wheelsize 1 to wheelsize 2 and vice-versa
long (5 sec.) Set-up mode for TCNT (second trip counter) is called into display
brief (0.1 sec) next information from MODE 2 is indicated
brief (0.1 sec) computer changes display information from MODE 1 data to
MODE 2 data. TCNT always being the first information indicated
long (5 sec) TRP-AVS-RID-MAX information reset to zero.
long (5 sec.) Second trip counter TCNT is being reset to zero
long (5 sec) total riding time counter reset to zero
long (5 sec) stop watch STP reset to zero
brief (0.1 sec) FREEZE function either activated or deactivated, computer either
stops or picks up functioning in regular modes.
brief (0.1 sec) either start or stop run of stop watch
