Summary of Contents for German ElectroniX ZAGIL
- Page 1 MANUAL ZAGIL GSM/GPRS MODEM OPERATION MANUAL Operation Manual User Guide...
- Page 2 G E R M A N E L E C T R O N I X ZAGIL GSM/GPRS MODEM User Guide German ElectroniX © Erzgiessereistr. 39 b in 80335 Munich / Germany Tel: +49-179-295-3496 Fax: +49-89-4209504159...
-
Page 3: Table Of Contents
T able of Contents Package Content ............... 1 Features ..................1 Specifications ................2 Installation ................. 3 Basic Operation ................. 4... -
Page 4: Package Content
G E R M A N E L E C T R O N I X Package content 1. ZAGIL GSM MODEM Terminal. 2. FS socket fixed with Flat cable 20cm. 3. Female connector for Supply. 4. Serial Cable. 5. User manual... -
Page 5: Specifications
G E R M A N E L E C T R O N I X Specifications Frequency - Tri-band: EGSM 850, 900, DCS 1800, PCS 1900. The MODEM can search the 4 bands frequency bands automatically. The frequency bands also can be set by AT COMMAND. - Compliant to GSM Phase 2/2+ GSM class Small MS... -
Page 6: Installation
Interfaces 1 Serial port RS232 1 TTL Voltage level Socket “FC10” Power supply（DC 5V、500mA） Antenna interface Status lights, Green light indicate power status SIM Card Holder TTL FC10 socket, FIGURE 1 Serial Port, Power supply socket Installation a) Open the SIM card holder, insert in a valid SIM Card provided by GSM network operator or Service provider. -
Page 7: Basic Operation
TTL socket description You supply the modem throw FC10 socket as it shown in figure 4 so no need to supply it from 2.5 connector Basic Operation A. Module connection with Hyper Terminal. 1. Establish or Open Hyper Terminal from All Programs >... - Page 8 (2). Setting up usage port. (3). Setting up port parameters.
- Page 9 (4). Setting up property File Menu Hyper Terminal...
- Page 11 2. You can input word “AT” then press “Enter” key, it should be response word “OK” means work Property. All commands are executed by pressing “Enter” key.
