Page 1
HD710 TRACK INDEX DISC STEP REPEAT ALL ONE Power Sensor Stop/Clear COMPACT DIGITAL AUDIO Compact Disc Player CD-Spieler Lecteur de compact-disques MODE D’EMPLOI Reproductor de CD CD-speler Open/Close INTRO MEMORY REMAIN TOTAL EACH AUTO SPACE RANDOM OVER Display Program Random...
Page 2
DANGER: Invisible laser radiation when sophisticated unit, please be sure to read this opened and interlock failed or defeated. owner’s manual and use your CD player only in Avoid direct exposure to the beam. accordance with its instructions. Keep the manual in a safe place for future reference.
Front Panel Controls harman/kardon HD 710 Power Sensor C O M P A C T COMPACT D I G I T A L A U D I O DIGITAL AUDIO Open/Close TRACK INDEX INTRO DISC STEP MEMORY REMAIN TOTAL EACH AUTO REPEAT SPACE...
Page 5
Front Panel Controls 1. POWER SWITCH 5. MULTI-FUNCTION DISPLAY The POWER switch turns the unit on and off. This display shows the corresponding information according to each mode. 2. COMPACT DISC DRAWER 6. PLAY BUTTON ( ) Load a disc (full-size or 3-inch/8 cm) into This button is used for starting play.
Before you begin to connect this unit 1. CONNECTION CORDS to your system, be sure that all On the back of your HD710 are output components are turned off and jacks that connect your CD player to your unplugged from the electrical outlet.
Operation LOADING AND UNLOADING • Do not insert any objects into the tray as it can damage the mechanism. • Press the OPEN/CLOSE button. The • To prevent dirt and dust from disc tray slides out automatically. entering the mechanism, do not •...
Page 8
CD will be when the desired point has been repeated. reached. • If the CD player reaches the end of • If the CD player reaches the end of the last track during forward search, the last track during forward search, the unit goes back to the beginning of the unit switches to the stop mode.
Page 9
RANDOM PLAY CHECKING THE CONTENTS OF THE PROGRAM In this mode, CD player plays the tracks You can check the contents of the on the CD in random sequence. program during programming or after • Press the RANDOM PLAY button.
Remote Control The remote control for the HD710 provides the same functions found on the front panel of the compact disc player Power ON itself. In addition, the remote control provides some functions that are not found on the front panel.
Page 11
CONCERNING USE OF harman/kardon BATTERIES Two batteries are provided with your remote control. To load batteries: 1. Locate the cover over the battery compartment on the back of the Power remote control. Remove the cover by sliding it in the direction of the embossed arrow.
Troubleshooting Guide If your HD710 does not operate as THE PLAY INDICATOR LIGHTS, expected, first check the items in the BUT NO SOUND IS HEARD following list. If you cannot deter- • The wrong SOURCE has been mine the source of the problem,...
Specifications • SIGNAL FORMAT Sampling Frequency 44.1 kHz D/A Conversion 1 bit (Bit Stream Conversion) Oversampling 4 times • Discrete Analog Output Section CIRC System Error Correction Frequency Response 8 Hz to 20 kHz 1.0 dB Total Harmonic Distortion (THD) 0.005% Dynamic Range 96 dB...
