10824 manual UK.book Seite 3 Freitag, 11. November 2005 3:38 15
TABLE OF CONTENTS
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Areas of use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up and electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Initial operation and use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
About microwaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooking and heating up in the microwave . . . . . . . . . . . . . . . . . . . . . . . 10
Before first use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
The meaning of the display symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mounting the glass dish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mounting the grill stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Heat appliance while empty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting clock time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Microwave/Grill Combi Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Hot Air/Hot Air Combi Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the defrost function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cooking in two stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the automatic programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Timer Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Hints for cooking with autoprogrammes . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cleaning, disposa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Additional functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Child security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Checking settings while cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3
Advertisement
Table of Contents
Summary of Contents for Medeli DD505
-
Page 1: Table Of Contents
10824 manual UK.book Seite 3 Freitag, 11. November 2005 3:38 15 TABLE OF CONTENTS Safety instructions ....... 4 Areas of use . -
Page 2: Safety Instructions
10824 manual UK.book Seite 4 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS Please read these operating instructions thoroughly and follow them and the safety notes in particular before using the appliance for the first time! Anything done to or with this appliance should only be undertaken as described in the operating instructions. -
Page 3: Setting Up And Electrical Connection
10824 manual UK.book Seite 5 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS Setting up and electrical connection • Connect the microwave only with an appropriate 230V~50Hz safety plug which has at least a 16 Amp fuse. To prevent tripping, please avoid using an extension cable. -
Page 4: Initial Operation And Use
10824 manual UK.book Seite 6 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS Initial operation and use • Use only the supplied accessories or those approved by us (see “Microwave-suitable materials and objects” on page 10.). • Never operate the appliance while empty. •... -
Page 5: Faults
10824 manual UK.book Seite 7 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS • With foods that have a firm skin, e.g. sausages or tomatoes, make small slits in the skin so that they do not burst during cooking. • Do not try to warm up eggs in their shells or pre-boiled eggs unless in specially designed microwave-suitable containers. - Page 6 10824 manual UK.book Seite 8 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS Warning! If the housing, door, door seal or the door catch is damaged then do not use the appliance under any circumstances. Have the appliance repaired immediately by a specialist workshop or contact your Medion Service Centre.
-
Page 7: About Microwaves
10824 manual UK.book Seite 9 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS About microwaves Microwaves are high-frequency electromagnetic waves which have a warming effect on the food within the oven. Microwaves heat all non-metallic objects. Therefore, do not place any metallic objects in the microwave oven. This heating effect works better the higher the water content of the foodstuff. -
Page 8: Cooking And Heating Up In The Microwave
10824 manual UK.book Seite 10 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS • After the cooking time has elapsed, or when the door is opened, the magnetron turns off immediately. Cooking and heating up in the microwave • To arrange food so that it cooks properly place the food with the largest pieces towards the outer edge. - Page 9 10824 manual UK.book Seite 11 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS Note: Do not use porcelain, ceramic or plastic containers in grill or grill combi mode. Cling film should also not be used. Due to the very high temperatures the materials could break, warp or even melt.
- Page 10 10824 manual UK.book Seite 12 Freitag, 11. November 2005 3:38 15 SAFETY INSTRUCTIONS Note: To test whether a dish is suitable for use in the microwave, put some water in the container and place it in the microwave. Press the button M i c ro / M ic r o + G r i ll and choose the highest power setting (100) using the dial.
-
Page 11: Before First Use
10824 manual UK.book Seite 13 Freitag, 11. November 2005 3:38 15 BEFORE FIRST USE • Completely unpack the appliance and accessories and check that all the parts are present before throwing away the packaging. An overview of all the parts can be found on the cover page of these instructions. Your microwave is wrapped in packaging to protect it against transportation damage. -
Page 12: Mounting The Glass Dish
10824 manual UK.book Seite 14 Freitag, 11. November 2005 3:38 15 BEFORE FIRST USE Mounting the glass dish • Place the roller ring into the middle of the cooking space. • Place the glass dish onto the roller ring and position it so that it clicks into the drive axis. -
Page 13: Heat Appliance While Empty
10824 manual UK.book Seite 15 Freitag, 11. November 2005 3:38 15 BEFORE FIRST USE • Before you use your new microwave with grill and hot air for the first time, please clean the appliance and all accessories to remove any possible production residues. - Page 14 10824 manual UK.book Seite 16 Freitag, 11. November 2005 3:38 15 BEFORE FIRST USE Attention! Do not remove the protective foil on the inside of the door or the card on the right of the cooking space otherwise microwaves could escape! Check the microwave for any damage –...
-
Page 15: Operation
10824 manual UK.book Seite 17 Freitag, 11. November 2005 3:38 15 OPERATION Every time a button is pressed you will hear a beep. Setting clock time As soon as the microwave is connected to the power the display shows 0:00. To set the clock proceed as follows: •... - Page 16 10824 manual UK.book Seite 18 Freitag, 11. November 2005 3:38 15 OPERATION Microwave • Press the M i c ro / M ic r o + G r i ll button. The display will appear as well P100 as the symbol for microwave operation.
-
Page 17: Hot Air/Hot Air Combi Operation
10824 manual UK.book Seite 19 Freitag, 11. November 2005 3:38 15 OPERATION Note: To check whether you have set the grill programme. During grilling only the heating element and the ventilator are in operation. When the cooking time reaches the half-way stage you will hear two beeps to remind you to turn over the food. - Page 18 10824 manual UK.book Seite 20 Freitag, 11. November 2005 3:38 15 OPERATION HOT AIR OPERATION WITH PRE-HEATING • Press the H o t ai r /M ic r o +H o t ai r button. • Use the dial to choose a temperature from 140 °C to 230 °C and press the S t a r t /O K button to confirm.
-
Page 19: Using The Defrost Function
10824 manual UK.book Seite 21 Freitag, 11. November 2005 3:38 15 OPERATION • Press the S t a r t /O K button to start cooking. During this operation the symbol and the microwave symbol will flash in the display. In order to reach the set hot air temperature in the minimum time, the hot air function will be supported by the grill function. -
Page 20: Using The Automatic Programmes
10824 manual UK.book Seite 22 Freitag, 11. November 2005 3:38 15 OPERATION Note: The defrost function can only be set as stage number one. The "Cooking in two stages" function is not available for automatic programmes. Using the automatic programmes •... -
Page 21: Timer Function
10824 manual UK.book Seite 23 Freitag, 11. November 2005 3:38 15 OPERATION Auto- programme Setting on Meat Reheat Pizza Porridge dial Bread 100 g 50 g 300 g 1 portion 200 g 100 g 400 g 2 portions 300 g 150 g 400 g 200 g... -
Page 22: Hints For Cooking With Autoprogrammes
10824 manual UK.book Seite 24 Freitag, 11. November 2005 3:38 15 OPERATION Hints for cooking with autoprogrammes In general, if you cook packed food, always follow the microwave description on the packet. Cooking rice The following table shows the amount of water needed for a given quantity of rice. -
Page 23: Cleaning, Disposa
10824 manual UK.book Seite 25 Freitag, 11. November 2005 3:38 15 CLEANING, DISPOSAL Cleaning The microwave should be cleaned regularly and food particles should be removed. Poor appliance hygiene can lead to damage to the surfaces, which in turn can reduce the lifespan of the appliance and even lead to dangerous situations. -
Page 24: Additional Functions
10824 manual UK.book Seite 26 Freitag, 11. November 2005 3:38 15 ADDITIONAL FUNCTIONS Child security Block buttons: • Press the C an c e l/ S t o p button for about 3 seconds. You will hear a beep and the display will show the symbol . - Page 25 10824 manual UK.book Seite 27 Freitag, 11. November 2005 3:38 15 ADDITIONAL FUNCTIONS Special features/Notes The maximum cooking time is 95 minutes for microwave, grill, hot air, microwave/grill and microwave/hot air modes. When the cooking time reaches the halfway point in grill mode there be two beeps to remind you to turn the food over.
-
Page 26: Troubleshooting
10824 manual UK.book Seite 28 Freitag, 11. November 2005 3:38 15 TROUBLESHOOTING Problem Possible cause Solution The appliance will not The mains plug is not Pull out the plug, wait 10 start. properly connected. seconds and then plug it back in again. -
Page 27: Technical Data
10824 manual UK.book Seite 29 Freitag, 11. November 2005 3:38 15 TECHNICAL DATA Power supply: 230 V ~ 50 Hz Microwave frequency: 2450 MHz Microwave input performance: 1450 W Microwave output performance: 850 W Performance grill: 1400 W Performance hot air: 1000 W Performance heating element (total): 2400 W max.
Need help?
Do you have a question about the DD505 and is the answer not in the manual?
Questions and answers
this is a manual for a microwave! NOT the dd505 menelli dele tronic drum kit. despite having the image of it at the beginning. .where is thebproper manual please?
