- Page 1 User's manual SUNGOO Mobile Navigation 43.01 English (UK) October 2007...
- Page 2 This symbol showing a crossed-through refuse container signifies that, within the European Union, the product must be disposed of as sorted waste. This applies both to the product itself, as well as to all accessories that carry this symbol. This product may not be disposed of with unsorted household waste.
-
Page 3: Table Of Contents
Legal notice ...................6 1.2.1 Liability..................6 1.2.2 Trademarks................6 Before you begin................7 Scope of Delivery...................7 Description of the SUNGOO Mobile Navigation 43.01 ......8 Preparing SUNGOO Mobile Navigation 43.01 for use......9 2.3.1 Charging the rechargeable battery ..........9 2.3.2 Memory card................9 2.3.3 Preparing the navigation system for use .......10 Navigation with GPS ................11... - Page 4 User's manual SUNGOO Mobile Navigation 43.01 4.2.4 Quick access to special destinations ........23 4.2.5 Information about the destination ..........23 Selecting a saved destination ..............24 4.3.1 Last Destinations ..............24 4.3.2 Favourites ................25 Navigating homewards ................25 Voice commands .................25 Determining destinations on the map ..........26 Starting navigation ................26...
- Page 5 User's manual SUNGOO Mobile Navigation 43.01 Turn-by-Turn List .................43 9.2.1 Blocking route sections............43 9.2.2 Removing blocks and using original routes ......44 TMC (Traffic Information)..............44 9.3.1 Displaying traffic messages ...........44 9.3.2 TMC Settings .................44 Logbook ....................45 Configuring SUNGOO Mobile Navigation 43.01 ......46 Handsfree Module................47...
-
Page 6: Introduction
User's manual SUNGOO Mobile Navigation 43.01 Introduction About this manual 1.1.1 Conventions For better legibility and clarification, the following styles are used in this manual: Bold and italics: Registered names, company and product descriptions. Window and dialogue box titles. MALL CAPITALS Bold: Highlighting of important parts in the text. -
Page 7: Before You Begin
Windows and ActiveSync are trademarks of the Microsoft ► Corporation. NAVIGON is a registered trademark of NAVIGON AG. ► Sungoo is a registered trademark of Media-Saturn-Holding GmbH. ► Before you begin Scope of Delivery Please check that the contents of the delivery are complete. If the contents are incomplete, please notify us within 14 days of purchasing. -
Page 8: Description Of The Sungoo Mobile Navigation 43.01
User's manual SUNGOO Mobile Navigation 43.01 Description of the SUNGOO Mobile Navigation 43.01 Touch screen Microphone Reset Headset socket (also used to connect TMC-antenna) Mini-USB-socket for USB-cable / Car charger cable Show Map On/Off/Standby Slot for SD-memory card Connection for external GPS-antenna... -
Page 9: Preparing Sungoo Mobile Navigation 43.01 For Use
11) The LED of the SUNGOO Mobile Navigation lights orange during charging. The LED lights green when the SUNGOO Mobile Navigation is fully charged. Note: It takes approx. 4-5 hours to charge the device when the battery is flat. -
Page 10: Preparing The Navigation System For Use
User's manual SUNGOO Mobile Navigation 43.01 Inserting a memory card Insert the memory card provided into the device (see image). Press ► the card into the device until it locks into place. 2.3.3 Preparing the navigation system for use Caution! Please be sure to refer to the safety information in chapter "Important safety information"... -
Page 11: Navigation With Gps
Supplying power to the navigation device Included in delivery of the SUNGOO Mobile Navigation is a car charger cable with which power can be supplied to the navigation device via the vehicle's cigarette lighter. -
Page 12: Important Safety Information
User's manual SUNGOO Mobile Navigation 43.01 places. This enables the device to calculate a route between a starting point and a destination. The calculation of the current position and its representation on the map takes place once every second. So your current position is always shown on the map. -
Page 13: Safety Guidelines When Installing In Your Car
User's manual SUNGOO Mobile Navigation 43.01 Caution! After installation, check all safety-relevant equipment in the car. Caution! Unplug the navigation device's power supply when you park the vehicle. The navigation device requires power in standby-modus, and may drain the vehicle's battery. -
Page 14: Operating The Navigation Software
User's manual SUNGOO Mobile Navigation 43.01 Caution! Do not attach the cradle within the deployment zone of airbags. Caution! When installing the cradle, ensure that it does not represent a risk in the event of an accident. Caution! Do not run cables directly next to safety-relevant devices and power supplies. - Page 15 S, SW, W and NW. TMC (Traffic Information) The SUNGOO Mobile Navigation has an integrated TMC-receiver which provides the navigation system with up to date traffic messaging. If necessary, it can alter the route dynamically in order to avoid a traffic jam for example.
-
Page 16: Software Keyboard
No Bluetooth: Bluetooth is deactivated. Connected: The SUNGOO Mobile Navigation is connected to another device. Not connected: The SUNGOO Mobile Navigation is not connected to another device. Bluetooth is activated. Software keyboard A software keyboard appears on the screen when text entries are necessary. -
Page 17: Lists
User's manual SUNGOO Mobile Navigation 43.01 opens the numeric keypad. opens the letter keyboard. opens the special character keyboard. As soon as you have entered a special character, the letter keyboard reappears automatically. Lists Often, lists appear from which you can select an entry. This is the case, for example, when you enter a location. -
Page 18: Starting Sungoo Mobile Navigation 43.01
User's manual SUNGOO Mobile Navigation 43.01 Caution! Please be sure to refer to the safety information in chapter "Important safety information" on page 12. Impaired GPS reception If GPS reception is impaired, navigation will be interrupted. The navigation software remains active. -
Page 19: Specifying A New Destination
AIN WINDOW opens. Specifying a new destination New destinations for the SUNGOO Mobile Navigation are all destinations that you have not yet navigated, or you have not yet stored. You can enter an address here, select a special destination, or select a destination from the quick search function. -
Page 20: Destination Address
User's manual SUNGOO Mobile Navigation 43.01 1. Tap the Country button. The C list opens. OVERED COUNTRIES 2. Tap on the country in which your destination lies. The C list closes again. OVERED COUNTRIES The symbol will display the country code of the destination country. -
Page 21: Special Destinations
User's manual SUNGOO Mobile Navigation 43.01 The map opens in Preview mode. Note: For detailed information on how to start navigation, please refer to chapter "Starting navigation" on page 26. 4.2.3 Special destinations Special destinations, also called POIs (Points Of Interest) for short, are useful addresses that are catalogued according to particular criteria. - Page 22 User's manual SUNGOO Mobile Navigation 43.01 The Name of the Destination list opens. It contains the nearest special destinations in the specified category, sorted by distance. 4. Tap on the name of the destination. 5. Tap the Start Navigation button.
-
Page 23: Quick Access To Special Destinations
User's manual SUNGOO Mobile Navigation 43.01 4. Specify a sub-category from which you would like to select a special destination. The Name of the Destination list opens. It contains special destinations from the specified category, sorted alphabetically. 5. Tap on the name of the destination. -
Page 24: Selecting A Saved Destination
(Call) button to call the number entered. ► Note: The Call function is only available when the SUNGOO Mobile Navigation is connected via Bluetooth to a mobile phone. For detailed information about connecting to a mobile phone, please refer to chapter "Handsfree Module" on page 47. -
Page 25: Favourites
For detailed information on how to start navigation, please refer to chapter "Starting navigation" on page 26. Navigating homewards In SUNGOO Mobile Navigation you can save your address as home address. You can navigate to your home address at anytime by activating a single button. -
Page 26: Determining Destinations On The Map
, tap the Voice Command button. AIN WINDOW 2. On prompting, repeat the voice command that you have stored for the desired destination into the SUNGOO Mobile Navigation. A dialog window shows the name of the destination. 3. Tap the Start Navigation button. -
Page 27: Route Profile
User's manual SUNGOO Mobile Navigation 43.01 The navigation destination is depicted by a small flag. The route and the estimated trip time are displayed. Route Profile A so called route profile forms the basis of the route calculation. Tap the Route Profile button if you want to view or change the route profile. -
Page 28: Managing Destinations
User's manual SUNGOO Mobile Navigation 43.01 Managing Destinations Every destination that you enter, and the destinations from the L list may be saved to the F list. This makes ESTINATIONS AVOURITES sense if you frequently navigate to a particular destination. -
Page 29: Routes With Stages
User's manual SUNGOO Mobile Navigation 43.01 You will be prompted by a dialog window to repeat the voice command into the SUNGOO Mobile Navigation for the selected destination. 3. Repeat the command for the selected destination into the SUNGOO Mobile Navigation. -
Page 30: Entering Route Points
User's manual SUNGOO Mobile Navigation 43.01 3. Enter the starting point. (See the corresponding section of chapter "Navigation" on page 17 ff.) 4. Tap the Set Starting Point button. The selected starting point will now be displayed next to the 0°(Starting Point) button. -
Page 31: Managing Routes
User's manual SUNGOO Mobile Navigation 43.01 Route Point Down: Moves the selected route point backwards. (Example: route point 2 becomes route point 3). Delete: Deletes the selected route point. A dialog window prompts you to confirm deletion. Managing routes You can save each planned route under a particular name. -
Page 32: Simulating Routes
User's manual SUNGOO Mobile Navigation 43.01 The R window is open. The starting point and at least OUTE LANNING one route point have been entered. 1. Tap the Show Route button. The map window opens in Preview mode. The starting point and the route points are marked by flags. For each stage, the distance and the estimated trip time is given. -
Page 33: Options
Show on Map: Shows the specified address on the map. Settings: Opens the S window. Here you can configure the navigation ETTINGS system. For more detailed information, please refer to chapter "Configuring SUNGOO Mobile Navigation 43.01" on page 45. Options - 33 -... - Page 34 User's manual SUNGOO Mobile Navigation 43.01 Logbook: Opens the .L window. Here you can begin and end logbook OGBOOK recording. For detailed information, please refer to chapter "Logbook" on page 45. Saved Routes: Opens a dialog window in which you can load a stored route.
-
Page 35: Working With The Map
Maps Even if you have stored several navigation maps on the navigation system's memory card, SUNGOO Mobile Navigation can only operate with one map at a time. Tap on Options > Settings > Current Map to see which map is currently being used. -
Page 36: Map In Preview Mode
User's manual SUNGOO Mobile Navigation 43.01 Map in Preview mode You have entered a destination and tapped the Start Navigation button. - OR – You have planned or loaded a route and tapped the Show Route button. The map opens in Preview mode. The entire route is visible. -
Page 37: Map In Navigation Mode
User's manual SUNGOO Mobile Navigation 43.01 Tap on Options > Show Turn-by-Turn List to view detailed ► directions for the route. (See "Turn-by-Turn List" on page 43) Tap the (Destination search) button to view the map in ► Destination search mode. (See "Map in Destination search mode"... -
Page 38: Quitting Navigation
User's manual SUNGOO Mobile Navigation 43.01 If you don't have to change direction for a longer period, you will see only a forward-facing arrow. The distance for which you are to follow the road you are on is displayed beneath the arrow. -
Page 39: Reality View
User's manual SUNGOO Mobile Navigation 43.01 Map functions in Navigation mode When the map is open in Navigation mode, tap any point on the map. Buttons with various functions will be displayed. 2D/3D: Changes between 2D and 3D mode. The symbol for the mode that is currently set is marked orange. -
Page 40: Map In Destination Search Mode
User's manual SUNGOO Mobile Navigation 43.01 The Reality View mode shows very clearly, the signposting and lanes you must follow. This display remains unchanged until you have passed the motorway junction. The map will then change back to Navigation mode. -
Page 41: Operating In Destination Search Mode
User's manual SUNGOO Mobile Navigation 43.01 Zoom Out: The map section shown becomes larger, but you will see fewer details. Zoom In: The map section becomes smaller, but you will see more details. Zoom Mode: When this button is active, you can plot a map section with the pen or with your finger. -
Page 42: Useful Functions
User's manual SUNGOO Mobile Navigation 43.01 This function is only active during navigation. Set as Destination: Adds the selected point as the last point in the route plan. If no route plan was open, the selected point will become the first point in a new route plan. -
Page 43: Turn-By-Turn List
User's manual SUNGOO Mobile Navigation 43.01 Turn-by-Turn List You can display detailed directions of the calculated route before starting navigation or at any time during navigation. This list displays all of the driving instructions in table form. The map is open in Preview mode, Navigation mode or Reality View mode. -
Page 44: Removing Blocks And Using Original Routes
User's manual SUNGOO Mobile Navigation 43.01 3. Tap the (Back) button to close the T window. 9.2.2 Removing blocks and using original routes Section blocks can be removed at anytime. In the T window, tap on Options > Calculate ►... -
Page 45: Logbook
Logbook You can use SUNGOO Mobile Navigation to record a logbook. The logbook is recorded in the "Logbook.xls" file. You can open the file with Microsoft Excel. Each recorded trip is added at the bottom of the table as a new entry. -
Page 46: Configuring Sungoo Mobile Navigation 43.01
SUNGOO Mobile Navigation 43.01 The S window is where you can adapt ETTINGS SUNGOO Mobile Navigation to suit your personal requirements. The settings can be reached via the options of several windows. Tap on Options > Settings. ► The S... -
Page 47: Handsfree Module
(Bluetooth HF Phone) to open the B LUETOOTH ► HF P window. Here you can connect HONE SUNGOO Mobile Navigation to a mobile phone or open the C list. ISTORY 11.2 Closing the hands-free module In the B HF P window, tap on (Close). -
Page 48: Connecting To A Telephone
User's manual SUNGOO Mobile Navigation 43.01 11.3 Connecting to a telephone SUNGOO Mobile Navigation must be connected to a mobile phone in order to use the telephone functions. 11.3.1 Pairing with a mobile phone Pairing describes the procedure involved when connecting two Bluetooth devices for the first time. -
Page 49: Accepting A Call
(Ring Tone Off) if you want to turn off the ring ► tone. 11.5 Calling With SUNGOO Mobile Navigation you can make a call in various ways: 11.5.1 Dialling a telephone number 1. In the navigation software, tap on (Handsfree Module). -
Page 50: Calling Most Recently Dialled, Received Or Missed Numbers
11.5.3 Dialling on the mobile phone When SUNGOO Mobile Navigation is connected to a mobile phone, it functions as a hands-free kit even when the number was dialled from the mobile phone. You can also make use of the mobile phone's telephone book. -
Page 51: Adjusting The Volume
ALL IN ROGRESS 11.6.4 Transferring a call from your mobile telephone With SUNGOO Mobile Navigation, you can transfer a call from your mobile phone if a Bluetooth connection exists between the two devices. Handsfree Module - 51 -... -
Page 52: Entering Numbers
User's manual SUNGOO Mobile Navigation 43.01 1. In the C window, tap on (Use ALL IN ROGRESS handsfree). 2. Continue the call on the hands-free kit. You will be prompted to confirm whether you want to transfer the call. Note: If Bluetooth is activated on the mobile phone, the connection can also be established during a call. -
Page 53: Ending The Call
User's manual SUNGOO Mobile Navigation 43.01 11.6.7 Ending the call In the C window, tap on (Hang up) to ALL IN ROGRESS ► end the call. The B HF P window opens. LUETOOTH HONE 11.7 Hands-free module troubleshooting Practically all of the problems that may arise with the hands-free module can be solved in the following way: 1. -
Page 54: Appendix
User's manual SUNGOO Mobile Navigation 43.01 Appendix 12.1 Technical data Dimensions 131.6 x 91.5 x 21.6 mm Weight approx. 195 g Operating -10°C bis 60°C temperature Operating Storage conditions -20°C bis 70°C temperature Humidity 0% bis 90%, non-precipitating Samsung 2440-400Mhz ®... -
Page 55: Declaration Of Conformity
User's manual SUNGOO Mobile Navigation 43.01 12.2 Declaration of Conformity Products with the CE marking comply with Radio & Telecommunication Terminal Equipment Directive (R&TTE) (1999/5/ECC), the Electromagnetic Compatibility Directive (89/336/ECC) and the Low Voltage Directive (73/23/ECC) – as amended by Directive 93/68/ECC - issued by the European Community Commission. -
Page 56: Index
User's manual SUNGOO Mobile Navigation 43.01 Index Block..........39, 43 Energy......... 11, 15 Bluetooth Entering data........17 Connect ........48 Connection with Mobile Phone ..48 Handsfree Module ......47 Pairing........... 48 Factory Settings ........ 35 Symbols ........16 Calibration ......... 34 Faulty reception ...... - Page 57 User's manual SUNGOO Mobile Navigation 43.01 Handsfree Module Route Profile......27, 32 Close..........48 Skip Route Point......39 Connect ........48 Start ........26, 32 Connection with Mobile Phone ..48 Turn-by-Turn List ....27, 33 Open ..........47 New Destination ........ 19 Pairing...........
- Page 58 User's manual SUNGOO Mobile Navigation 43.01 Search for POI Connection with Mobile Phone ..48 Direct Access........ 23 Pairing .......... 48 in a City......... 22 Telephone ......... 47 Nationwide ........22 Nearby .......... 21 Recalculate Route ......45 Settings Show..........44 Calibration........
- Page 59 User's manual SUNGOO Mobile Navigation 43.01 Imprint NAVIGON AG Schottmüllerstraße 20A D-20251 Hamburg The information contained herein may be changed at any time without prior notification. This manual nor any parts thereof may not be reproduced for any purpose whatsoever without the express written consent of NAVIGON AG, nor transmitted in any form either electronically or mechanically, including photocopying and recording.
