- Page 1 User’s manual KNX MultiLight (ML-K) Article number: 44001 Picture: KNX MultiLight User Panel function Innovation & Technology AS...
- Page 2 Innovation & Technology AS - 2 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A...
-
Page 3: Table Of Contents
Table of content APPLICATION FOR THE KNX MULTILIGHT ROOM CONTROLLER ....4 INTRODUCTION .................... 4 MULTILIGHT START-UP AND GENERAL FUNCTIONS ........6 GENERAL FUNCTIONS AND USER PANEL ............. 8 MOVEMENT AND LUX LEVEL DETECTION ............. 9 5.1 M OVEMENT SENSOR ......................... -
Page 4: Application For The Knx Multilight Room Controller
19°C in standby mode (vacant) to 22°C in comfort mode (occupied). Example 2 – Lighting: The KNX MultiLight can turn on and off the luminaire. So, when a person walks into the room and the temperature set-point is changed from standby to comfort mode, the light will also be turned on. - Page 5 The KNX MultiLight can be fitted with a user panel that will replace the luminaire pull cord. The panel can give the user temperature control, control of shutters and lighting control.
-
Page 6: Multilight Start-Up And General Functions
The red programming LED on the KNX node and inside the lens of the movement detector will be lit when the KNX MultiLight is in learn mode. The programming LED will blink when the MultiLight is not programmed (un-programmed node). - Page 7 2. Detection of movement is shown by blinking the red LED inside the movement detector lens. Figure 3 – KNX MultiLight node, movement detector and user panel function Innovation & Technology AS - 7 - Manual – KNX MultiLight Art.nr 44001...
-
Page 8: General Functions And User Panel
4 General functions and user panel The status of the KNX MultiLight is shown by the object “Self-Test status”. For normal operational nodes this status object is low. If the movement sensor or user panel does not respond the self test status is set high. The object can be configured to be sent cyclic [1 to 24 hours]. -
Page 9: Movement And Lux Level Detection
Light dependent full automatic: "Movement Local" object can turn on and off a function base on both movement and the lux threshold switch (see chapter below). function Innovation & Technology AS - 9 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 10: Master Function "Movement General
ON telegrams. If the two values are the same, the sensor sends one cyclic sending right before the recovery time elapses. The cyclic sending time will not be affected by a re-trigged recovery time. function Innovation & Technology AS - 10 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 11: Lux Sensor
If the raw value V=1000, and the object is updated with 800, then the calibration factor will be: c=1-(1000-800)/1000=0.8. See the graph in Figure 7. The formula for calculating the lux is: Lux=c*V function Innovation & Technology AS - 11 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 12: Block Diagram
2000 if the raw lux level is 1000. Block diagram Figure 8 - Block diagram of movement and lux sensor function Innovation & Technology AS - 12 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 13: Object List
The object can be sent cyclic. It is possible to activate turn-on and/or turn-off delay via parameters. function Innovation & Technology AS - 13 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 14: Thermostat
35 ºC (not adjustable) Operational modes The KNX MultiLight has 4 operational modes; Comfort, Stand-by, Night and Frost/heat protection. The active mode is selected based on the three 1.bit objects "Comfort Mode", "Night Mode" and "Frost/heat protect". The table below shows which mode is active based on the status of these three objects (X = don’t care). -
Page 15: Parameters
The “Actual setpoint” will change depending on the “Base setpoint”, the active mode, if the regulator is in heating- or cooling mode and the local temperature adjustment. function Innovation & Technology AS - 15 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 16: Standby Mode
Frost/heat protection mode. The LED indication for the heating- and cooling system alternates between heating and cooling every second. function Innovation & Technology AS - 16 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 17: Basic Heating And Cooling Stage
See the description of the different regulator modes in chapters 6.3.1 to 6.3.4. 6.3.6 Additional heating and cooling stage The KNX MultiLight can control an additional heating and/or cooling system with ON/OFF control. The temperature limits for the additional heating- and cooling systems can be defined by parameters, see Figure 10 and Figure 11. -
Page 18: Local Temperature Adjustment
If the panel is removed, all regulator outputs will be set to “0” one time, and the actual temperature is send 0ºC. The “Self test” object will indicate the error and will be transmitted as “1”. function Innovation & Technology AS - 18 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 19: Regulator Function
Regulator function Figure 12 - Asymmetric regulator functionality function Innovation & Technology AS - 19 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 20: Pi Regulator
PI Regulator The KNX MultiLight thermostat can control heating and cooling systems with Pulse-With- Modulation. The communication object for the PWM control value output is a 1.byte 0- 100% of the type DPT5.001. The control value will automatically be transmitted every 40. -
Page 21: Object List
2 byte temperature in comfort mode Base setpoint 9.010 (heating). This value is the origin C R (W) T for all the different regulator modes. function Innovation & Technology AS - 21 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... - Page 22 (set by parameter). The integral part can be disabled by setting the reset time parameter to 0, resulting in a P-regulator. Cyclic sending every 40 min. function Innovation & Technology AS - 22 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A...
- Page 23 + additional cooling C R - T deadzone + parameter settings for Switch the different modes. Permanent hysteresis: +0,5K. Cyclic sending every 40 min. function Innovation & Technology AS - 23 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A...
-
Page 24: Switch Actuator
7 Switch actuator Parameter The relay functionality for KNX MultiLight includes regular ON/OFF switch capability, ON/OFF time delay and staircase function. The basic functionality is offered through three communication objects: “Switch”, “Force operation” and “Status switch”. The relay can be controlled by setting the “Switch” object high or low. The relay can be forced either ON or OFF by setting the “Force operation”... -
Page 25: On/Off Delay Function
(If node is not Operation programmed this i set to ON) Object: Relay Status Switch Figure 17 - Block diagram for the switch actuator function Innovation & Technology AS - 25 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 26: Object List
Holds the status information about OBJ 028 Relay: Status 1 bit the relay output (1=relay closed, switch 1.001 0=relay open) C R - T Flag: function Innovation & Technology AS - 26 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 27: Binary Inputs
8 Binary inputs Parameter KNX MultiLight has two digital inputs (1 and 2) that can be used as a simple switch, dimming switch or shutter control switch. The simple switch can be either configured as on, off or toggle. Detection of short and long switch operation will be determined for dimming- and shutter switch. -
Page 28: Shutter
Please note that the action for long operation is locked to "Toggle up/down" if the reaction for short operation is "Stop/toggle up/down". Block diagram Figure 18 - Block diagram for binary inputs function Innovation & Technology AS - 28 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 29: Object List
Up/Down C - W T down or toggle (depending on parameter). The action can be: “Up”, “Down” or “Toggle Up/Down” function Innovation & Technology AS - 29 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... - Page 30 Up/Down C - W T down or toggle (depending on parameter). The action can be: “Up”, “Down” or “Toggle Up/Down” function Innovation & Technology AS - 30 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A...
-
Page 31: Mechanical Dimensions
Figure 19 - Mechanical dimensions of ML-K in mm (30x120x17,5) Figure 20 - Mechanical dimensions of ML-M in mm (Ø31x21) Figure 21- Mechanical dimensions of ML-P function Innovation & Technology AS - 31 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 32: Detection Area Movement Sensor (Ml-M)
Pin number Binary input 1 Binary input 2 Table 10 – 4pin Molex connector (two paralel connectors J4 and J5) Signal Pin number +3.7V +20V function Innovation & Technology AS - 32 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 33: Wiring Diagram
10 Wiring Diagram function Innovation & Technology AS - 33 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... -
Page 34: Technical Data
- EIB / KNX nach EN 50 090-2-2 Certification CE mark - In accordance with the EMC guideline and low voltage guideline. Data subject to change without notice function Innovation & Technology AS - 34 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A... - Page 35 Innovation & Technology AS - 35 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A...
- Page 36 5 | N-5059 Bergen | Norway fabrikkgaten 5 | N-5059 Bergen | Norway Tlf.: +47 55 38 50 80 Epost: post@function.no Doc. no.: D-TS-ML-K-005-A Web: www.function.no function Innovation & Technology AS - 36 - Manual – KNX MultiLight Art.nr 44001 Doc.no. D-TS-ML-K-005-A...
