Sony VAIO FS VGN-FS15GP Specifications

VAIO FS
VGN-FS15GP
Open up to new possibilities.
Sony recommends Microsoft
Specifications
Model VGN-FS15GP
®
Microprocessor Intel Centrino™ Mobile Technology
® ® 1
Intel Pentium M Processor 730 (1.60GHz)*
®
- Supports Enhanced Intel SpeedStep Technology
® ®
Operating System Microsoft Windows XP Professional with Service Pack 2 (English version) Multilanguage User Interface (pre-installed Traditional Chinese)
®
Chipset Intel 915PM Express Chipset
Processor System Bus 533MHz
Memory Bus 333MHz
Cache Memory L1 Cache: 64KB L2 Cache: 2MB (on CPU)
2
Main Memory 512MB DDR SDRAM (upgradeable up to 1GB)* (partially shared with video memory)*
2 SO-DIMM slots (The pre-installed memory module uses one)
Hard Disk 40GB (C: 15GB, D: 25GB) Ultra ATA/100
4
Optical Drive CD-RW/DVD-ROM Drive*
Maximum reading speed: DVD+R, DVD-R, DVD+RW, DVD-RW, DVD+R DL (Double Layer): 4 / DVD-ROM: 8x / CD-RW: 15 / CD-ROM : 25
Maximum writing speed: CD-R, CD-RW: 24
Graphics Accelerator • Dual display compatible • 3D graphics acceleration compatible • NVIDIA
(PCI Express 16 connection)
3
Video Memory 128MB*
Display 15.4˝ Wide (WXGA: 1280 800) TFT colour display (Clear Bright LCD: Single Lamp)
5
Interfaces • USB 2.0 x 3* • i.LINK (IEEE 1394) S400 (4pin) • Network (RJ-45) connector (100BASE-TX/10BASE-T) • Headphone jack (stereo mini)
• Microphone jack (stereo mini) • Monitor connector (VGA, D-SUB 15 pin) • Modular (RJ-11) connector • Port Replicator connector
6
• Memory Stick Slot* (Standard/Duo Size compatible, Memory Stick PRO compatible, High-speed data transfer compatible*
8 ®
Wireless LAN • Integrated Wireless LAN IEEE 802.11b/802.11g* • Intel PRO/Wireless 2200BG Network Connection
9
• Data rate: maximum 11Mbps (802.11b)/54Mbps (802.11g) * • Frequency: 2.4GHz
Modem V.92 and V.90 Compliant
PC Card Slot Type I/II 1, CardBus Support
®
Audio • Intel High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers
Keyboard / Input Device • ca 19mm Key pitch / 2.5mm Key stroke • 86 Keys • Intelligent Touchpad
10 11
Battery VGP-BPS2A* Lithium-ion battery: up to 2 hours of use*
Dimensions (W H D) 364 25.4-35.9 264.5mm
Weight 2.9kg (including the supplied battery)
Included Software • Adobe Reader 6 • Adobe Photoshop Elements 2.0 • Adobe Premiere Standard • InterVideo WinDVD 5 for VAIO • Sonic RecordNow! 7
• Sony DVgate Plus 2.0 • Sony PictureGear Studio 2.0 • Sony SonicStage 2.1 • Sony SonicStage Mastering Studio 1.4 • SonicStage
Mastering Studio Audio Filter 1.4 • Sony VAIO Control Center 1.1 • Sony VAIO Edit Components 5.0 • Sony VAIO Media 3.1 • VAIO
Original Screen Saver • Sony VAIO Update 2.1 • Sony VAIO Zone 1.2 • Symantec Norton AntiVirus 2005
Supplied Accessories • AC adapter (VGP-AC19V10) • Lithium-ion battery (VGP-BPS2A)
12
Warranty One year*
Features and specifications are subject to change without notice.
*1 CPU speed will be reduced under certain operating conditions. *2 By adding one 512MB memory module. *3 NVIDIA
video memory and dynamically available system memory for optimal system performance. *4 This product is designed to playback discs that conform to the Compact Disc Digital Audio
standard specifications (CD Standard). A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. Please be aware
that the audio side (non-DVD side) of a DualDisc may not play on this product because it does not conform to the CD Standard. *5 High-speed/Full-speed/Low speed compatible. *6 Does
not support MagicGate copyright protection technology. Does not support Memory Stick with capacity of 2GB and over. Compatibility confirmed with Sony branded "Memory Stick" media
only. *7 MagicGate copyright protection technology cannot be applied to Memory Stick PRO. *8 Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network may
reduce the communication speed due to radio interference. Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication speed to ensure
communication with IEEE 802.11b products. When the communication speed is not as fast as expected, changing the wireless channel on the access point may increase the communication
speed. *9 The communication speed varies depending on the distance between communication devices, existence of obstacles between such devices, the device configuration, the radio
conditions, and the software in use. In addition, communication may be cut off depending on the radio conditions. *10 This product may only function with a genuine Sony battery designed
for this model. *11 Estimated battery life (under JEITA Battery Run Time Measurement Method (ver.1.0).) When the power-saving mode is on. Actual battery life may vary with different
operating conditions and settings. For further details, please visit vaio-online.sony.com *12 Warranty conditions may vary by region.
The trademarks, including but not limited to "SONY", "VAIO", "Memory Stick" and "SonicStage" are either trademarks or registered trademarks of Sony Corporation and/or its subsidiaries.
Adobe, Adobe Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other countries. Intel, Pentium, SpeedStep and
Centrino are either trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are either trademarks or
registered trademarks of Microsoft Corporation in the United States and other countries. All other product and brand names may be trademarks or registered trademarks of their respective
owners. Whilst information given is true at time of printing, small production changes in the course of our company's policy of improvement through research and design might not necessarily
be included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.
Optional Accessories
(availability depends on region)
VGP-PRFS1 VGP-AC19V10
Port Replicator
AC Adapter
Monitor connector
(VGA, D-SUB 15 pin)
Universal voltage compatible:
Printer connector
AC100 – 240V
Network connector
USB 2.0 connector ( 2)
VGP-BPL2 PCGA-WMS5/S
Lithium-ion Battery Wireless Mouse
Rechargeable battery Stylish, user-friendly design
Highly sensitive receiver
Sensor resolution:
800 dots per inch
vaio-online.sony.com
Windows XP Professional.
® ®
VGN-FS15GP
3
® 3
GeForce™ Go 6200 with TurboCache™*
5 6 7
7
)
10
12
13 14 15 16
11. Wireless LAN switch
12. Headphone jack (stereo mini)
13. Microphone jack (stereo mini)
14. Indicators
15. Network (RJ-45) connector (100BASE-TX/10BASE-T)
16. Modular (RJ-11) connector
17. CD-RW/DVD-ROM drive
18. Manual eject button
19. Disc eject button
10. Built-in stereo speakers
® TurboCache™ technology combines the size and bandwidth of
11. Power button
12. Shortcut buttons
13. PC Card eject button
14. PC Card slot (Type I/II 1)
15. i.LINK (IEEE 1394) S400 (4 pin) connector
16. Memory Stick Slot
(Standard/Duo Size compatible, Memory Stick PRO compatible,
high-speed data transfer compatible)
17. USB 2.0 connector ( 3)
18. Monitor connector (VGA, D-SUB 15 pin)
19. DC-IN connector
1 2 3
4
8 9
11
17 18 19
