Sony VAIO FS VGN-FS25GP Specifications

VAIO FS
VGN-FS25GP
Intel Centrino Mobile Technology
® ™
Broaden your DVD creativity with style.
Specifications
Model VGN-FS25GP
®
Platform Intel Centrino™ Mobile Technology
® ® 1 ®
• Intel Pentium M Processor 740 (1.73GHz)* • Intel PRO/Wireless 2200BG Network Connection • Intel
® ®
Operating System Microsoft Windows XP Professional with Service Pack 2 (English version) Multilanguage User Interface (pre-installed Traditional Chinese)
Processor System Bus
533MHz
Memory Bus 333MHz
Cache Memory L1 Cache: 64KB L2 Cache: 2MB (on CPU)
Main Memory 2
512MB DDR SDRAM (upgradeable up to 1GB)* (partially shared with video memory)*
2 SO-DIMM slots (The pre-installed memory module uses one)
Hard Disk 4
60GB (C: 15GB, D: 45GB* ) Ultra ATA/100
5
Optical Drive DVD±RW Drive (supporting DVD+R Double Layer disc)*
Maximum reading speed: DVD+R, DVD-R, DVD-ROM: 8× / DVD-RW, DVD+RW: 6× / DVD+R DL (Double Layer): 4× / CD-R, CD-RW, CD-ROM: 24×
Maximum writing speed: DVD+R, DVD-R: 8× / DVD+RW, DVD-RW: 4× / DVD+R DL (Double Layer): 2.4× / CD-RW: 10× / CD-R: 24×
Graphics Accelerator
• Dual display compatible • 3D graphics acceleration compatible • NVIDIA
(PCI Express ×16 connection)
Video Memory 3
128MB*
15.4˝ Wide (WXGA: 1280 × 800) TFT colour display (Clear Bright LCD: Single Lamp)
Display
• USB 2.0 × 3* 6
Interfaces • i.LINK (IEEE 1394) S400 (4pin) • Network (RJ-45) connector (100BASE-TX/10BASE-T) • Headphone jack (stereo mini)
• Microphone jack (stereo mini) • Monitor connector (VGA, D-SUB 15 pin) • Modular (RJ-11) connector • Port Replicator connector
7
• Memory Stick Slot* (Standard/Duo Size compatible, Memory Stick PRO compatible, High-speed data transfer compatible*
9 ®
Wireless LAN • Integrated Wireless LAN IEEE 802.11b/802.11g* • Intel PRO/Wireless 2200BG Network Connection
10
• Data rate: maximum 11Mbps (802.11b)/54Mbps (802.11g)* • Frequency: 2.4GHz
Modem V.92 and V.90 Compliant
Type I/II × 1, CardBus Support
PC Card Slot
Audio ®
• Intel High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers
Keyboard / Input Device • ca 19mm Key pitch / 2.5mm Key stroke • 86 Keys • Intelligent Touchpad
11 12
Battery VGP-BPS2A* Lithium-ion battery: up to 2 hours of use*
Dimensions (W × H × D) 364 × 25.4-35.9 × 264.5mm
Weight
2.85kg (including the supplied battery)
Software Applications • Adobe Reader 6 • Adobe Photoshop Elements 3.0 (Installer) • Adobe Premiere Standard • WinDVD 5 for VAIO • RecordNow! 7 • Click
to DVD 2.4 • DVgate Plus 2.1 • PictureGear Studio 2.0 • SonicStage 3.0 • SonicStage Mastering Studio 1.4 • SonicStage Mastering
Studio Audio Filter 1.4 • VAIO Control Center 1.1 • VAIO Edit Components 5.0 • VAIO Media 4.1 • VAIO Original Screen Saver • VAIO
Recovery Utility 2.4 • VAIO Update 2.1 • VAIO Zone 1.4 • Norton Internet Security 2005
Supplied Accessories • AC adapter (VGP-AC19V10) • Lithium-ion battery (VGP-BPS2A)
Warranty 13
One year*
Features and specifications are subject to change without notice.
*1 CPU speed will be reduced under certain operating conditions. *2 By adding one 512MB memory module. *3 NVIDIA
video memory and dynamically available system memory for optimal system performance. *4 Includes necessary data for recovery (setting back to initial shipment settings) in the hard disk
drive consuming approximately 5GB in size. *5 This product is designed to playback discs that conform to the Compact Disc Digital Audio standard specifications (CD Standard). A DualDisc
is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. Please be aware that the audio side (non-DVD side) of a DualDisc
may not play on this product because it does not conform to the CD Standard. *6 High-speed/Full-speed/Low speed compatible. *7 Does not support MagicGate copyright protection
technology. Does not support Memory Stick with capacity of 2GB and over. Compatibility confirmed with Sony branded "Memory Stick" media only. *8 MagicGate copyright protection
technology cannot be applied to Memory Stick PRO. *9 Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network may reduce the communication speed due to
radio interference. Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication speed to ensure communication with IEEE 802.11b products. When
the communication speed is not as fast as expected, changing the wireless channel on the access point may increase the communication speed. *10 The communication speed varies
depending on the distance between communication devices, existence of obstacles between such devices, the device configuration, the radio conditions, and the software in use. In addition,
communication may be cut off depending on the radio conditions. *11 This product may only function with a genuine Sony battery designed for this model. *12 Estimated battery life (under
JEITA Battery Run Time Measurement Method (ver.1.0).) When the power-saving mode is on. Actual battery life may vary with different operating conditions and settings. For further details,
please visit vaio-online.sony.com *13 Warranty conditions may vary by region.
The trademarks, including but not limited to "SONY", "VAIO", "Memory Stick" and "SonicStage" are either trademarks or registered trademarks of Sony Corporation and/or its subsidiaries.
Adobe, Adobe Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other countries. Intel, Intel logo, Intel Inside, Intel
Inside logo, Intel Centrino, Intel Centrino logo, Intel SpeedStep, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other
countries. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. All other product and brand names may be
trademarks or registered trademarks of their respective owners. Whilst information given is true at time of printing, small production changes in the course of our company's policy of
improvement through research and design might not necessarily be included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.
Optional Accessories
(availability depends on region)
VGP-PRFS1 VGP-AC19V10
Port Replicator
AC Adapter
● Monitor connector
(VGA, D-SUB 15 pin)
● Universal voltage compatible:
● Printer connector
AC100 – 240V
● Network connector
● USB 2.0 connector (×2)
VGP-BPL2 PCGA-WMS5/S
Lithium-ion Battery Wireless Mouse
● Rechargeable battery ● Stylish, user-friendly design
● Highly sensitive receiver
● Sensor resolution:
800 dots per inch
vaio-online.sony.com
®
915PM Express Chipset
3
Sony recommends Microsoft
Windows ® XP Professional.
VGN-FS25GP
® 3
GeForce™ Go 6200 with TurboCache™*
8
)
5 6 7
10
® TurboCache™ technology combines the size and bandwidth of
12
13 14 15 16
11. Wireless LAN switch
12. Headphone jack (stereo mini)
13. Microphone jack (stereo mini)
14. Indicators
15. Network (RJ-45) connector (100BASE-TX/10BASE-T)
16. Modular (RJ-11) connector
17. DVD±RW drive (supporting DVD+R Double Layer disc)
18. Manual eject button
19. Disc eject button
10. Built-in stereo speakers
11. Power button
12. Shortcut buttons
13. PC Card eject button
PC Card slot (Type I/II ×1)
14.
15. i.LINK (IEEE 1394) S400 (4 pin) connector
16. Memory Stick Slot
(Standard/Duo Size compatible, Memory Stick PRO compatible,
high-speed data transfer compatible)
17. USB 2.0 connector (×3)
18. Monitor connector (VGA, D-SUB 15 pin)
19. DC-IN connector
®
1 2 3
4
8 9
11
17 18 19
