- Page 1 AIR STAPLER 1/4” CROWN Model 54425 ASSEMBLY AND OPERATING INSTRUCTIONS ® Visit our Web site at http://www.harborfreight.com ® For technical questions, please call 1-800-444-3353.
-
Page 2: Product Specifications
You will need this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures, parts list and as- sembly diagram. Keep your invoice with this manual. Write the invoice number on the inside of the front cover. Keep this manual and invoice in a safe and dry place for future reference. - Page 3 USE EYE AND HEARING PROTECTION. DRESS SAFELY. DO NOT OVERREACH. INDUSTRIAL APPLICATIONS MUST FOLLOW OSHA REQUIREMENTS. STAY ALERT. CHECK FOR DAMAGED PARTS. REPLACEMENT PARTS AND ACCESSORIES: MAINTAIN THIS PRODUCT WITH CARE. USE THE RIGHT TOOL FOR THE JOB. WARNING:...
-
Page 4: Specific Product Warnings And Precautions
SPECIFIC PRODUCT WARNINGS AND PRECAUTIONS IMPORTANT CONSUMER INFORMATION: Contact Trip Trigger. USE ONLY CLEAN, DRY, REGULATED, COMPRESSED AIR AT BETWEEN 60 TO 115 PSI. NOTE: 4 to 6 CFM delivery at 90 PSI. WHEN CONNECTING TO THE AIR SUPPLY: 60 to 115 PSI (See Figure A.) PSI AIR REGULATOR STAPLER... - Page 5 ALWAYS DISCONNECT THE AIR SUPPLY HOSE FROM THE AIR STAPLER BEFORE LOADING THE STAPLES TO PREVENT A STAPLE FROM BEING ACCIDENTALLY FIRED DURING CONNECTION. DO NOT LOAD STAPLES WITH THE TRIGGER (part #31) OR SAFETY ELE- MENT (part #55) DEPRESSED. ALWAYS KEEP YOUR FINGER OFF THE TRIGGER (part #31) WHEN NOT DRIVING STAPLES.
- Page 6 NOTE: Assembly Diagram on page 10. To Attach A Quick Connector To The Air Stapler: (See Figure B.) FIGURE B NOSE To Prepare The Air Stapler For Use: CAUTION: Make sure to keep the Air Stapler pointed away from you and others at all times.
- Page 7 SAFETY ELEMENT (#55) To Use The Air Stapler: (See Figures B, and C.) To Remove A Jammed Staple: CAUTION: Make sure to disconnect the Air Stapler from its air supply before performing this procedure. (See Figure C.) (See Figure C.) AIR HOSE (NOT INCLUDED) TRIGGER (#31)
-
Page 8: Before Each Use
(See Figure C.) INSPECTION, MAINTENANCE, AND CLEANING CAUTION: Always disconnect the Air Stapler from its compressed air sup- ply source before performing any inspection, maintenance, or cleaning. BEFORE EACH USE, Do not use damaged equipment. PERIODICALLY, PLEASE READ THE FOLLOWING CAREFULLY... -
Page 9: Parts List
PARTS LIST Part # Description Part # Description Part # Description NOTE:... -
Page 10: Assembly Diagram
NOTE: ASSEMBLY DIAGRAM 54 55 60 62 58 57 61 62 95: AIR TOOL OIL NOT SHOWN 96: HEX KEYS NOT SHOWN...
