Summary of Contents for Tricity Bendix BWD 1011
-
Page 2: Your New Washer-Dryer
Your New Washer-Dryer Your new washer-dryer is gentle with your laundry, simple to use and easy to care for. Programme and temperature setting using the In the interest programme selector. of the environment Automatic cooling of the wash water to 60°C before draining, with the 95°C programme, prevents Materials marked with the symbol distortion of plastic pipes in the domestic water... -
Page 3: Important Safety Information
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. -
Page 4: Table Of Contents
Contents For the User Wash Care Symbols Maintenance and Cleaning 19-20 Your New Washer-Dryer Descaling Important Safety Information After each wash External cleaning Description of the Appliance Cleaning the dispenser drawer Detergent dispenser drawer Cleaning the drawer recess The Control Panel Cleaning the filter The dangers of freezing Operating sequence... -
Page 5: Description Of The Appliance
Description of the Appliance 1 Detergent dispenser drawer 2 Programme guide 3 “Mains-on” light 4 “ON/OFF” button 5 “Options” buttons 6 Drying indicator light 7 Drying time selector dial 8 Programme selector dial 9 Door opening handle 10 Filter 11 Adjustable feet Detergent dispenser drawer Prewash Wash... -
Page 6: The Control Panel
The Control Panel 1 Programme guide 7 Drying indicator light This light illuminates when the machine is drying. 2 Mains-on light This light illuminates when the machine starts working 8 Drying time selector dial and goes out when the ON/OFF button is released. Graduated up to 120 mins for cottons and synthetics, this dial allows you to select the desired drying time 3 ON/OFF button... -
Page 7: Operating Sequence
Operating Sequence Before the first wash, we recommend that you run a cotton cycle at 60°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine. -
Page 8: Select The Required Programme
4. Select the required programme Turn the programme selector dial clockwise to the required programme (1 or 2). 6. Start the machine Before starting up the machine check that: the appliance is plugged in the water supply taps are turned on the drain hose is correctly and securely positioned the door and the detergent dispenser drawer are closed. -
Page 9: Washing 2 Kg Of Mixed Fabrics At 50°C
WASHING 2 KG OF MIXED FABRICS AT 50°C Suppose you have 2 kg of mixed fabrics to wash. They are rather delicate fabrics and should not be washed at a high temperature. 1. Load the laundry Open the door by pulling the catch outward. Place the laundry in the drum, one item at a time, shaking them out as much as possible. -
Page 10: Select The Required Programme
5. Select the required programme Turn the programme selector dial clockwise to programme 8. 6. Start the machine Before starting up the machine check that: the appliance is plugged in the water supply taps are turned on the drain hose is correctly and securely positioned the door and the detergent dispenser drawer are closed. -
Page 11: Drying 2.25 Kg Of Cotton
DRYING 2.25 KG OF COTTON You have for example just machine-washed and spun at 1000 rpm 4.5 kg (10 lb) of laundry. They are cotton fabrics of medium weight which you want to iron as soon as they are dry. Switch off the machine. -
Page 12: At The End Of The Programme
5. At the end of the programme The machine stops automatically and the drying light goes out. The door is controlled by a safety device which releases 2 minutes after the end of the programme. Switch the machine off by depressing the ON/OFF button again, the mains-on light goes out. -
Page 13: Autodrying 1 Kg Of Mixed Fabrics
AUTODRYING 1 KG OF MIXED FABRICS You intend to wash and dry automatically 1 kg (2.2 lb) of mixed fabrics which do not need ironing. Proceed as follows: 1. Load the laundry. 2. Add the washing powder and additive. 3. Select the programme Turn the programme selector dial clockwise to programme 8. -
Page 14: Washing And Drying Programmes
Washing and Drying Programmes Programmes for cotton and linen WASHING Degree of soil Programme dial Possible Max. Wash programme Description and type of laundry position option load White cotton, for Prewash at 40 °C example heavy soiled HALF PREWASH & Wash at 95 °C 4.5 kg work garments, sheets,... -
Page 15: Washing And Drying Programmes
Washing and Drying Programmes Programmes for synthetics, delicates and wool WASHING Degree of soil Programme dial Possible Max. Wash programme Description and type of laundry position option load Synthetic or mixed Wash at 50 °C fabrics, underwear, MIXED 3 rinses RINSE coloured garments, 2 kg... -
Page 16: Washing And Drying Hints
Washing and Drying Hints Do NOT overload the machine. Weigh the laundry the Some stains such as fruit, wine, grass, rust etc. are first few times you use the appliance. difficult to remove and should be treated before washing with specific products, which can be found The average weights of the most common items are in most household shops. -
Page 17: Which Detergent To Use
And in which form? Which detergent?..Not only are there different types of detergent, but they To ensure you obtain the best wash results from your are also available in different forms. Whether you chose appliance, it is important to use the right detergent in a powder or liquid in traditional or compact form is to your everyday wash, and only detergents recommended your personal choice. -
Page 18: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 19: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 20: Cleaning The Filter
Cleaning the filter The water drain filter A clean filter is important for the correct functioning of the machine, and should therefore be cleaned after every washing programme. Open the filter door and place a container underneath to catch any spillage. If the filter is blocked and the machine is unable to drain you will need to drain the water manually from the machine at this stage. -
Page 21: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Electrolux Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 22: Service And Spare Parts
Symptom Possible causes The door will not open The programme is still running. The door lock has not yet released. Water in the tub: the door cannot be opened if water is present in the tub. The machine makes an unusual The machine is fitted with a type of motor which makes an unusual noise noise compared with other traditional motors. -
Page 23: Guarantee Conditions
Guarantee Conditions Standard guarantee conditions Exclusions We, Electrolux undertake that if, within 12 months of This guarantee does not cover: the date of the purchase, this Electrolux appliance or any Damage or calls resulting from transportation, part thereof is proved to be defective by reason only of improper use or neglect, the replacement of any light faulty workmanship or materials, we will, at our option, bulbs or removable parts of glass or plastic. -
Page 24: Electrolux Service Force
08705 929 929 To contact your local Service Force Centre telephone... - Page 25 08705 929 929 To contact your local Service Centre telephone...
-
Page 26: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 27: Unpacking
Unpacking Before starting the machine up, the packing must be removed as follows. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the rear right bolt. Lay the machine gently on its back, making sure that the hoses are not squashed. -
Page 28: Water Inlet
Water inlet The inlets on the back of the appliance are colour coded, blue for cold and red for hot. If only a cold water supply is available, connect the two hoses to a cold water outlet by means of a «Y» connection piece. -
Page 29: Levelling
Important Before connecting up the machine to new pipework or to pipework that has not been used for some time, run off a reasonable amount of water to flush out any debris that may have collected in the pipes. Levelling Level the machine by raising or lowering the feet. -
Page 30: Electrical Connection
Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance’s rating plate.
