Fisherman's Habit 94569 Assembly And Operating Instructions

Digital fish scale

Download this manual

DIGITAL FISH SCALE

ASSEMBLY & OPERATING INSTRUCTIONS

Diagrams within this manual may not be drawn proportionally.

Due to continuing improvements, actual product may differ slightly from the product described herein.

Distributed exclusively by Harbor Freight Tools

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SaVe THiS Manual.

2006 by Harbor Freight Tools

or any artwork contained herein may be reproduced in any shape or form without the

express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

Model

3491 Mission Oaks Blvd., Camarillo, CA 93011

94569

Page 1 Copyright 2006 by Harbor Freight Tools © or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions or replacement parts, please call 1-800-444-3353. Model 94569 .
Page 2 Use the right product for the job. There are certain applications for which the Fish Scale was designed. Do not modify the Fish Scale and do not use the Fish Scale for a purpose for which it was not intended.
Page 3 Figure 1. The Fish Scale can be held by hand or hung from the loop at the top of the Scale. Place the fish onto the Hook. Press the Hold Button down while the fish is being weighed; the Hold Indicator light will go on-see Figure 2.
Page 4: Troubleshooting
Press down on the release tab on the back of the Fish Scale to open the Battery Compartment. Insert one 9V battery (not included) and line up polarity with the markings indicated in the Battery Compartment. When the Battery is running low, the LCD readout will show a picture of a battery. This indicates that the battery needs replacing.
