Central Hydraulics MOTORCYCLE LIFT 94813 Assembly And Operating Instructions Manual

Motorcycle lift air operated 1200 lb. capacity

Advertisement

MOTORCYCLE LIFT
ASSEMBLY AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
©
Copyright
2006 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve-
ments, actual product may differ slightly from the product described herein. Tools required for assembly
and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 10h; 11a
AIR OPERATED - 1,200 LB. CAPACITY
Model
®
. All rights reserved. No portion of this manual or any artwork
94813

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOTORCYCLE LIFT 94813 and is the answer not in the manual?

Questions and answers

Summary of Contents for Central Hydraulics MOTORCYCLE LIFT 94813

  • Page 1 SAVE THIS MANUAL. © Copyright 2006 by Harbor Freight Tools contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve- ments, actual product may differ slightly from the product described herein.
  • Page 2: Product Specifications

    PRODUCT SPECIFICATIONS Maximum Lift Capacity Working Pressure Air Hose Inlet Size Valve Operation Minimum Platform Height Maximum Platform Height Lock Mechanism Locking Heights Tire Vise Air Hose Dimensions Platform Dimensions Approach Ramp Dimensions Weight Optional Accessory You will need this manual for the safety warnings and precautions, assembly, oper- ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
  • Page 3: Personal Safety

    Stay alert. Watch what you are doing, and use common sense during use. Do not use the Motorcycle Lift while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating equipment may result in serious personal injury.
  • Page 4: Specific Safety Rules

    SPECIFIC SAFETY RULES Maintain labels and nameplates on the Motorcycle Lift. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replace- ment. Use the right product for the job. There are certain applications for which this product was designed.
  • Page 5 Use compressed air only. Use clean, dry, regulated, compressed air. Never use oxygen, carbon dioxide, combustible gases, or any other bottled gas as a power source for this tool. WARNING! The warnings and cautions discussed in this manual cannot cover all possible conditions and situations that may occur.
  • Page 6 QUICK COUPLER (49) MOTORCYCLE LIFT To Connect The Motorcycle Lift To An Air Compressor: For best service, you should incorporate an oiler, regulator, and in-line filter, as above. Hoses, couplers, oilers, regulators, and filters are all available at Harbor Freight Tools. Note: If an automatic oiler is not used, put 3-5 drops of pneumatic Tool Oil (not included) in the Motorcycle Lift’s Air Hose Connector (49) before each use.
  • Page 7 ASSEMBLY INSTRUCTIONS FIGURE C WARNING! As an additional safety precaution, ALWAYS lower the Safety Bar (11) completely and make sure it rests between the teeth of the Lifting Arms (24) when the Motorcycle Lift is in its raised position. To do so, raise the Mo- torcycle Lift to slightly above the desired height.
  • Page 8 STOP PLATE WASHER Align the two mounting slots in the Stop Plate (1) with the two mounting holes located at the rear of the Platform (8). Then secure the Stop Plate to the Platform, using two Bolts (2), two Washers (29), and two Nuts (27). NOTE: When adjusting the Stop Plate forward or backward, make sure to retighten the two Nuts.
  • Page 9 To Install The Ramp: PLATFORM RAMP (10) FIGURE F With assistance, lift the Ramp (10) and insert its two prongs into the two mounting holes located at the front of the Platform. (See Figure F.) For technical questions, please call 1-800-444-3353 SKU 94813 PAGE 9...
  • Page 10 OPERATING INSTRUCTIONS WARNING! Do not exceed the maximum lifting capacity of this tool (1,200 pounds). Exceeding the maximum lifting capacities could cause personal injury and/or property damage. Make sure the Platform (8) is fully collapsed to the floor. Also, make sure the Remov- able Plate (9) is properly positioned over the inspection hole of the Platform (8).
  • Page 11: Troubleshooting

    INSPECTION, MAINTENANCE, AND CLEANING Before each use: Inspect the general condition of the Motorcycle Lift. Check for cracked, worn or damaged parts, loose or missing parts, low or no hydraulic oil, and any other condition that may affect the tool’s safe operation. If a problem occurs, have the problem corrected before further use.
  • Page 12: Main Parts List

    Part Description Stop Plate Bolt (M10 x 25) Adjustable Shelf M10 x 25 Bolt (M8 x 20) Moveable Vise Assy. Stationary Vise Assy. Platform Removable Plate Ramp Safety Bar Clevis Pin R-Pin Safety Bar Handle Bolt (M16 x 130) Washer (#16) Lock Nut (M16) Lifting Arm Bolt (M16 x 80)
  • Page 13: Main Assembly Diagram

    MAIN ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. REV 10h For technical questions, please call 1-800-444-3353 SKU 94813 PAGE 13...
  • Page 14 PARTS LIST AND ASSEMBLY DIAGRAM - LIFT DOLLY (58) Part Description Dolly Handle Bolt Washer Wheel Dolly Set NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. PARTS LIST AND ASSEMBLY DIAGRAM - FOOT AIR VALVE (48) Part Description Foot Pedal...
  • Page 15: Limited 90-Day Warranty

    LIMITED 90 DAY WARRANTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
