STOWE MARINE DATALINE-X COMPASS User Manual

Dataline-x
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER GUIDE FOR
DATALINE-X
COMPASS
Stowe Marine Ltd.
www.stowemarine.com
Tel +44(0)1590 610071
Dataline-X Compass Manual, Part Number 06267SM, Issue 2, Dec 1995.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DATALINE-X COMPASS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for STOWE MARINE DATALINE-X COMPASS

  • Page 1 USER GUIDE FOR DATALINE-X COMPASS Stowe Marine Ltd. www.stowemarine.com Tel +44(0)1590 610071 Dataline-X Compass Manual, Part Number 06267SM, Issue 2, Dec 1995.
  • Page 2 Warning The equipment to which this manual applies must only be used for the purpose for which it was designed. Improper use or maintenance may cause damage to the equipment and/or injury to personnel. The user must be familiar with the contents of the manual before attempting to operate or work on the equipment.
  • Page 3 Contents CONTENTS Part 1 Introduction Part 2 Operation Part 3 Installation Part 4 Setting Up Part 5 Fault Finding Part 6 Maintenance Appendix A Received NMEA 0183 Messages...
  • Page 7 This User Guide describes the Navigation System Repeater digital display, known as Dataline-X COMPASS, used within the Dataline-X System. This User Guide also describes the installation and use of the Dataline HEADING SENSOR and the Robertson RFC250 HEADING SENSOR with the COMPASS display.
  • Page 8 Introduction Part 1 Figure 1.1 - Dataline-X System Diagram Page 2...
  • Page 9 Part 1 Introduction Figure 1.2 - Dataline-X COMPASS Instrument Page 3...
  • Page 10 Introduction Part 1 Dataline-X COMPASS Specification Heading Functions Heading Display (Digital) 0 to 359 Heading Precision Heading Reference True or Magnetic North (See Note 2.) Locked Course Functions Locked Course Display (Digital)0 to 359 Locked Course Precision Off Course Precision...
  • Page 11 Part 1 Introduction Notes: 1. Values and functions given relate to the display; the heading sensor installed will determine the actual values and functions. 2. All headings and bearings may be referenced to either True or Magnetic North. If True North is selected, and True data is not directly available then the local magnetic variation may be entered (or received from a suitable Radio Navigator via NMEA).
  • Page 12 Introduction Part 1 Page 6...
  • Page 13 Part 2 Operation CONTENTS General Description 2.1.1 The Dialplate 2.1.2 The LCD Display 2.1.3 The Buttons Powering Up The Heading and Locked Course Displays 2.3.1 The Heading Display 2.3.2 The Locked Course Display 2.3.3 Locking and Changing the Set Course To Set The Display Backlighting Heading Sensor Error Displays Demonstration Mode...
  • Page 14 Operation Part 2 2.1.3 The Buttons The word below the button indicates the main function for that button. The HEADING button changes the current display mode to heading. The LOCK button acts in heading and locked course modes to re-lock the locked course and enable it to be changed.
  • Page 15 Part 2 Operation Notes: 1. The heading may be referenced to either Magnetic or True North. If only one type of data is available, and the other data is required then the local magnetic variation may be entered, or it may be read in from a Radio Navigator if one is fitted, and the correct NMEA message is transmitted by it.
  • Page 16 Operation Part 2 To Set Display Backlighting 1. Press the LOCK button and hold. The display backlighting will change from 0 to level 7, then level 6, then level 5, and so on to level 0. If the button is still held, the level will then increase back to 7 again.
  • Page 17 Part 2 Operation Demonstration Mode The Demonstration Mode allows the user to familiarize himself/herself with all the functions of the instrument with the device removed from the system. Demonstration software within the instrument produces realistic values for the display. A +12V power supply will be required to be connected as follows: 0V to the BLACK (far right) terminal.
  • Page 18 Operation Part 2 Page 12...
  • Page 19 Part 3 Installation CONTENTS General Installation of the COMPASS Display Installation of the Dataline Heading Sensor Installation of the RFC250 Heading Sensor Compass System Wiring Choosing the Cable Routes Securing the Cable General The instrument head is fully waterproof and can, therefore, be installed on deck or below.
  • Page 20 Installation Part 3 Depth sounders, etc. TWO metres from: Engines / electric motors Large masses of soft iron, e.g., keels THREE metres from: Radar magnetrons. It is possible to use a small hand-held magnetic compass to check the mounting location. Move the compass in a horizontal circle of approximately 30 cm (1 ft) radius around the desired mounting location.
  • Page 21 Part 3 Installation Installation of the COMPASS Display 1. Carefully position the self-adhesive template provided on the surface where the instrument is to be mounted. 2. Drill a small pilot hole first, and then check the location on the other side of the panel or bulkhead to confirm suitability.
  • Page 22 Installation Part 3 If the cable routing cannot be made with the Dataplug connector attached, then simply disconnect it from the cable. The cable may then be run through holes of down to 6 mm (0.25 ins.) diameter before reconnecting the Dataplug connector, making sure that the colours are correctly wired to the terminals.
  • Page 23 Part 3 Installation Figure 3.3 - Electrical Connections to the Display 6. Check that the instrument functions correctly. 7. Temporarily disconnect the Dataplug connectors and coat the terminals and wires with silicone grease or petroleum jelly. These products will not harm the instrument. 8.
  • Page 24 Installation Part 3 4. Release the transit screw on the sensor. This is found at the base of the sensor towards the rear. Unscrew the screw 10 full turns to allow full movement of the sensor assembly. If the sensor is being mounted externally then the screw should be removed and shortened by 10mm before refitting tightly.
  • Page 25 Part 3 Installation Compass System Wiring A Dataline Heading sensor is connected directly to a display as below: Display Sensor Wire Function Terminal +12V Power In (Fused 1A) White Blue NMEA Heading Data Brown White NMEA Calibration Data Sensor Green Black NMEA Reference (0V Power In) Black...
  • Page 26 Installation Part 3 Yellow No Connection, Isolate A Robertson RFC250 Heading sensor is connected to a Databox as below: Databox Sensor Wire Function Terminal Dataline Red White +12V Power In Dataline Blk Black 0V Power In Compass + Blue NMEA Heading Data Compass - Brown NMEA Reference...
  • Page 27 Part 3 Installation 3. Secure the cable ends with enough slack to allow for easy connection. 4. Cut any spare wire ends to an appropriate length. Page 21...

  • Page 28: Table Of Contents

    Setting-Up Part 4 CONTENTS System Calibration Calibration Mode Lighting Colour Selection Lighting Bank Selection LCD Contrast Setting True / Magnetic Headings and Bearings Selection Magnetic Variation Entry Compass Auto-Deviation Compensation 4.8.1 Compass Auto-Deviation Compensation - With the Dataline Heading Sensor 4.8.2 Compass Auto-Deviation Compensation - With...
  • Page 29 Part 4 Setting-Up 4. The HEADING and LOCK buttons may be used to decrement or increment values, which are flashing. When the value is correct, press both buttons together again to save it. 5. Selecting the Calibration Mode End Screen and pressing both buttons together will return the instrument to its normal working mode.

  • Page 30: Press Both Buttons Together, And Hold For More Than 3 Seconds, Until

    Setting-Up Part 4 The Dataline-X instrument system can have two separate banks of instruments. Setting the lighting level on one display will set all the other displays in that bank to the same level, but will not effect any displays in the other bank.
  • Page 31 Part 4 Setting-Up 3. Select the required LCD contrast level, either 1 or 2, by pressing both buttons together. 4. Return to the main display by pressing the HEADING button three times to select the Calibration Mode End Screen, and then pressing both buttons together.

  • Page 32: True / Magnetic Headings And Bearings Selection

    Setting-Up Part 4 True / Magnetic Headings and Bearings Selection The displayed heading and bearings may be set to reference either Magnetic or True North. 1. Press both buttons together, and hold for more than 3 seconds, until 'rEd', 'Grn', or 'YEL' is shown on the display. 2.

  • Page 33: Compass Auto-Deviation Compensation

    Part 4 Setting-Up 6. Press both buttons together to save the variation value. 7. Return to the main display by pressing the HEADING push-button five times to select the Calibration Mode End Screen, and then pressing both buttons together. Compass Auto-Deviation Compensation The Calibration process must be performed after installation of the system, after any movement, additions, or removals of metal objects from the vicinity of the sensor, and also if the vessel is moved to a latitude of more than 20°...
  • Page 34 Setting-Up Part 4 should show 'HdG0' to indicate that the sensor is no longer compensated and is ready to be compensated again. 5. If the LCD shows 'HdG0' then it is not compensated, and is ready to be compensated, so continue with the steps below: Place the vessel in a position where it can be swung through a full 360 degrees.
  • Page 35 Part 4 Setting-Up 11. If possible check the compass against known compass points. If a constant heading error is found then consult your dealer. 4.8.2 Compass Auto-Deviation Compensation - With the Robertson RFC250 Heading Sensor The RFC250 Heading sensor is calibrated automatically by performing at least two sequential 360°...

  • Page 36: Test Mode Entry Screen

    Setting-Up Part 4 Test Mode Entry Screen The Test Mode will test all display functions (See Part 5 for further details). 1. Press both buttons together, and hold for more than 3 seconds, until 'rEd', 'Grn', or 'YEL' is shown on the display. 2.
  • Page 37 Part 4 Setting-Up 2. Return to the main display by pressing both buttons together. Page 31...
  • Page 38 Fault Finding Part 5 CONTENTS General Test Mode Fault Finding Chart General This instrument has been tested before shipment. However, installation conditions and procedures are outside the control of the manufacturer and can sometimes produce faults. The following check list is provided to assist the user in diagnosing such faults and suggests remedial action to be taken.
  • Page 39 Part 5 Fault Finding The LCD will then show the software code version, and after a few seconds the pointer will start to move backwards and forwards through its whole movement. This will be repeated until a button is pressed. LCD Segments Test After the pointer test, the display will show 'tSt2’, and start the LCD test.
  • Page 40 Fault Finding Part 5 After the NMEA Output test, the display will show 'tSt7’, then test the two buttons, prompting with the button number. After a successful test of both buttons, the display will automatically return to normal mode. The buzzer should beep on every button test. Page 34...
  • Page 41 Part 5 Fault Finding Fault Finding Chart This chart assumes that the instrument is part of a Dataline-X instrument system. If it is connected to another instrument system then perform the equivalent checks on that system. General Display and Communications Faults Condition Probable Cause Action...
  • Page 42 Fault Finding Part 5 Condition Probable Cause Action All instruments always show No data is reaching any of the Check that the battery voltage ‘----’, with pointers instruments. at the Databox Power Input analogue instruments at their terminals is greater than 10V. zero positions.
  • Page 43 Part 5 Fault Finding For Standalone Displays - Connected to a Heading Sensor or Autopilot Condition Probable Cause Action The LCD display is blank and No 12V power supply. Check the fuse(s) and / or circuit the pointer does not move. breaker(s).
  • Page 44 Fault Finding Part 5 Some headings Heading sensor auto Re-calibrate the sensor. incorrect, by different amounts. deviation compensated. Note: Magnetic ferrous objects Check for possible objects that When checking Compass moved into or away from the may affect the sensor, e.g. a ensure that the check is against vicinity of the heading sensor.
  • Page 45 Part 5 Fault Finding Condensation forms inside the Slight internal moisture. Turn the lights to Level 7 and instrument. leave on until cleared. Page 39...
  • Page 46 Maintenance Part 6 CONTENTS General Maintenance Annual Maintenance Removal of Instrument Return for Service General Maintenance The instrument head will require no maintenance apart from occasional cleaning. Do this using fresh water and a mild soap solution (not a detergent). CAUTION DO NOT USE ANY ABRASIVES, CHEMICAL CLEANERS, PETROL OR DIESEL TO CLEAN...
  • Page 47 Part 6 Maintenance 5. If they are not yet removed, unplug the Dataplug connectors from the rear of the case, and make up the cable if necessary. Figure 6.1 - Removal of Instrument Return for Service Please ensure that an instrument that is believed to be faulty is correctly installed, the wiring is in good condition and correct, that all connections are secure, and that a 12V supply is present at it’s power input terminals.
  • Page 48 Maintenance Part 6 The NMEA 0183 messages that are received by the COMPASS display are as below: Heading Magnetic Variation Page 42...
