Garden Lantern
92508
INSTALLATION AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
TO HELP PREVENT SERIOUS INJURY AND ELECTROCUTION,
READ AND UNDERSTAND ALL WARNINGS AND
INSTRUCTIONS BEFORE INSTALLATION OR USE.
©
®
Copyright
2005 by Harbor Freight Tools
. All rights reserved. No
portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for One Stop Gardens ONESTOP 92508
Summary of Contents for One Stop Gardens ONESTOP 92508
- Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts, please call 1-800-444-3353.
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS You will need this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures, parts list and assem- bly diagram. Keep your invoice with this manual. Write the invoice number on the inside of the front cover. Keep this manual and invoice in a safe and dry place for future reference. -
Page 3: Electrical Safety
4. This light must be installed into an outlet box properly installed and grounded in accordance with all codes and ordinances. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. If the light should electrically malfunction or break down, grounding provides a low resistance path to carry electricity away from the user. - Page 4 19. Maintain labels and nameplates on the Lantern. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement. 20. Only install type A bulbs rated at or below the maximum wattage (100 Watts) for this Lantern.
- Page 5 ASSEMBLY INSTRUCTIONS NOTE: For additional information regarding the parts listed in the following pages, refer to the Assembly Diagram on the last page. The power to the outlet box must be disconnected before attempting to install this item. If the power is left connected during installation, or if the power comes on accidentally, SEVERE PERSONAL INJURY or DEATH can occur.
- Page 6 8. While being careful not to scrape either the wall or the lantern, hang the Base (1) of the lantern on the plastic hookon the Mounting Bracket (10) by the hole in the side of the Base - see Figure 1 on the previous page.
-
Page 7: Maintenance Instructions
OPERATION INSTRUCTIONS Refer to Figure 3 on the right for the location of the different settings. TIME Setting This controls the amount of time that the light stays on when the sensor is tripped. Turn the dial clockwise for more time (up to 5 minutes) and counterclockwise for less time (down to one minute). -
Page 8: Parts List
NOTE: Some parts are listed and shown for illustration purposes only, and are not available individu- ally as replacement parts. PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
