American Standard Champion 4 Round Front Toilet 2023.214 Specification Sheet

CHAMPION 4 ROUND FRONT TOILET
®
❑
2023.214
• Vitreous china
• EverClean surface inhibits the growth of
®
stain- and odor-causing bacteria, mold,
and mildew on the surface
• Low-consumption (6.0 Lpf/1.6 gpf)
• Features Champion® 4 Flushing System
performance platform
• 4" non-adjustable, piston action Accelerator™
flush valve
• Siphon action jetted bowl
• 2-3/8" fully-glazed trapway
• Speed Connect tank/bowl coupling system
®
• Chrome-plated trip lever
• Sweeping pier on bowl
• 100% factory flush tested
• 2 bolt caps
• 10 year warranty
❑
3110.016 Bowl
❑ 4266.014 Tank
Nominal Dimensions:
721 x 464 x 797mm (28-3/8" x 18-1/4" x 31-3/8")
Fixture only, seat and supply by others
Alternate Tank Configurations Available:
❑ 4266.504 Tank complete with Aquaguard Liner
❑ 4266.604 Tank complete with tank cover
locking device
❑
4266.704 Tank complete with Aquaguard Liner
and tank cover locking device
❑ 4266.804 Tank complete with trip lever
located on right side
❑
4266.904 Tank complete with tank cover locking
device and trip lever located on right side
❑ 4266.954 Tank complete with Aquaguard Liner,
tank cover locking device, and trip lever
on right side
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specification for
Non-Adjustability - July, 2003 revision
© 2008 AS America Inc.
ROUND FRONT TOILET
SEE REVERSE FOR ADDITIONAL ROUGHING-IN
DIMENSIONS
To Be Specified:
❏ Color:
❏ White ❏ Bone ❏ Silver ❏ Linen ❏ Black
❏ Seat: (please specify color)
❏ Champion Slow Close Round Front #5330.010
®
❏ Rise & Shine Round Front #5322.011
❏ EverClean Round Front Seat with Slow Close
®
Snap-Off Hinges #5320.110
❏ Supply with stop:
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the
range of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
K37
CHAMPION 4
®
VITREOUS CHINA
Revised 2/08
