We have written this manual with the aim of helping installers, sound engineers
and consultants alike get to grips with the MSR-604ii and obtain its maximum
capability.
Should you have any comments or questions about applying the MSR-604ii series
within your application, please write to us, or e-mail us, at the addresses in the
warranty section. We welcome any comments or questions regarding the MSR-
604ii series or other BSS products, and you may contact us at the address or World
Wide Web site given in the warranty section.
MSR-604ii User Manual version v1.4
th
4
December 1997
MSR-604ii
User Manual
EN55013
(1990) Associated Equipment
EN50082/1
(1992) RF Immunity, Fast
EN61000/3/2
(1995)
EN60065
(1993)
interstage
Phistersvej 31, 2900 Hellerup, Danmark
Telefon 3946 0000, fax 3946 0040
www.interstage.dk
- pro audio with a smile
Transients ESD
Page 1
