Connecting the 5.1 System

Note the instructions in the chapter „Safety and Service" (pages 2 and
following).
1. C
ONNECTING THE
After having positioned the components connect the cables of the loud-
speakers.
Use the drawing on page 6 and the table below as a guide:
Loudspeaker
Front left
Front right
Rear left
Rear right
Centre
2. C
ONNECTING THE
Your 5.1 system can take input from a sound card, a DVD-player or
another suitable sound source with the corresponding output connections.
Tip:
3.5mm stereo cinch female plugs are required. When not
available, adapters are required.
Attention!
Digital connections are not supported and can damage the
device.
Locate the output connections of the sound source (sound card, DVD-
player, etc) and connect the device with the supplied cables. The connec-
tions are usually colour-coded.
The colours might vary slightly. Check the user manual of your device as a
safeguard.
L
OUDSPEAKERS
Loudspeaker plug
Cinch black
Cinch black
Cinch black
Cinch black
Cinch black
S
OUND
S
S
E T
E T
Connection on the
subwoofer ( p. 6)
9, FRONT L – Cinch white
10, FRONT R – Cinch red
11, REAR L – Cinch white
12, REAR R – Cinch red
13, CENTER – Cinch yellow
S
OURCE
U
U
T I N G P
T I N G P
9
