• Microphone
(10)
• Audio
Headphones
(11)
• Digital
Audio
(S/P-DIF
(12)
By using the external connections you have the possibility to con-
nect your notebook with a 5.1 surround system.
The bundled software allows you to make the necessary settings:
1. Click the following symbol in the taskbar:
The help program for the audio configuration is now invoked. A
large number of settings can be carried out with this.
It is also used to set the loudspeaker configuration you are going
to use for the surround sound.
Click on 'Audio-I/O', in order to set the system according to your
requirements.
Four configurations modes are available to you:
• headphones
• 2CH* speakers for stereo loudspeaker output
• 4CH speakers for 4 loudspeaker output
• 6CH speakers for 5.1.-loudspeaker output
Your notebook is factory set to 2-channel mode
*
48
In For recording via an external micro-
phone.
For sound reproduction via an exter-
nal surround system for external
center / subwoofer.
Out / For reception through an external
source of sound.
For sound reproduction with a sur-
round system for speakers back.
For sound reproduction via external
Out stereo
optical) speakers (active) or headphones.
For sound reproduction with an ex-
ternal surround decoder via an opti-
cal cable (available separately at a
specialist shop).
Main Components
equipment such
.
as loud-
