Summary of Contents for Medion Printer
-
Page 1: Table Of Contents
2. Ribbon installation............9 To change the ribbon ............10 3. Loading paper..............12 TRANSFERRING IMAGES .............13 Transferring Images from Memory Cards........13 Infrared transfer ..............15 Transferring Images via USB ..........16 1. Install the software ............16 2. Connect the printer to the computer........17... - Page 2 Copyright © 2005 All rights reserved. This manual is protected by Copyright. ® The Copyright is owned by Medion Trademarks: All trademarks are the property of their respective owners. The information in this document is subject to change without notice.
-
Page 3: Safety
Always keep these instructions near your printer for easy refer- ence. Keep these instructions and packaging safe. Use the original packaging in the event that you need to ship or transport your printer. -
Page 4: Point Of Use
• Only use in a suitable ambient temperature: NVIRONMENT CONDIDTIONS The printer can be operated at an ambient temperature of 15° C/59° F to 35° C/95° F and a relative humidity of 30% to 75% (not condensing). When switched off the printer can be stored at temperature from 15°... -
Page 5: Connecting
It contains no user- serviceable parts. • The power socket must be in the vicinity of the printer and within reach of the power adapter cables. DO NOT stretch the power cables tightly to reach a power socket. -
Page 6: Repairs
CDR disc. We cannot assume a liability for data loss or associated subsequent damage. ECYCLING AND DISPOSAL This printer and its packaging was produced mostly from materi- als which can be disposed of in an environmentally friendly man- ner and be professionally recycled. -
Page 7: Introduction
ERVICE Service and support is available any time you use your printer. Contact us, we will be glad to help you. This manual contains a separate chapter on the subject of service beginning on page 29. -
Page 8: Included In The Box
NCLUDED IN THE BOX Please check that the contents are complete and notify us within 14 days of purchase if any of the following components are miss- ing: • Printer • Power adapter (model: KSAFJ2400333T1M2) • Paper tray • Ink ribbon •... -
Page 9: Technical Data
ECHNICAL • Print method Dye-diffusion thermal trans- • Resolution 300 x 300 ppi • Colours 16,8 million continuous • Print speed Less than 60 seconds per photo (excluding image processing) • Interface CF cards (Type I & II) / SM / MS / MD / MMC / SD / xD cards USB 2.0 compatible port... -
Page 10: Setup
Remark: When installing your printer near a wall or some other object, keep an open space of at least 4 inches at the back of the printer, to make sure the movement of the sheet of paper being printed is not obstructed. -
Page 11: Ribbon Installation
2. R IBBON INSTALLATION Switch on the printer. Wait 10 seconds for the printhead to lift, then: 1. Open the external flap located on the right-hand side of the printer. 2. Remove the protective foam. 3. Take the new ribbon out of its pack-... -
Page 12: To Change The Ribbon
The chip card, which is supplied with every con- sumable item, must be read before each change to the printer, to do this. Switch on the printer. Wait 10 seconds for the printhead to lift, then: 1. - Page 13 5. Lift the locking lever and remove the used ink ribbon. 6. Pay attention to the position of the inked ribbon in accordance with the illustration on the right. 7. Lift the locking lever and push in the film cartridge until it touches the back of the compartment the locking lever must be locked after insertion.
-
Page 14: Loading Paper
There will be the risk of a reduced print quality. Warning! Make sure that a previously printed pho- tograph has not been slipped inadvertently into a packet of blank pages; this could damage the rib- bon of your printer. -
Page 15: Transferring Images From Memory Cards
You will now be able to print your photos with the printer, after you have carried out the steps of bringing it into operation. The images must be transferred to your printer to do this. Your printer offers various methods to receive photo files. -
Page 16: Transferring Images
Pay attention that the contacts, as described in the list below, are pointing in the right direction when inserting the memory card. Incorrect insertion of the memory card could lead to damage to the insertion slot and/or the memory card. Card format Contacts •... -
Page 17: Infrared Transfer
NFRARED TRANSFER You will be able to print images that you have taken with your mobile phone camera with your printer. The transfer of the im- ages takes place via the wireless infrared connection between the two devices. Remark: Mobile phones that are equipped with a camera work with a lower resolution. -
Page 18: Transferring Images Via Usb
“setup.exe”. Confirm by clicking “OK”. 2. You will install the driver of the printer and an additional graphics application by means of the installation menu (Install products). Both products will be installed by means of the All menu point. -
Page 19: Connect The Printer To The Computer
1. Connect the end of the USB cable to a free USB connection socket on your computer, which will have been switched on, and the other end to Connection B of your printer. The USB cable is not in the scope of delivery. -
Page 20: Print Your Photographs
SER INTERFACE ISPLAY User interface 1 – On/Off button (press and hold) 2 – Last photo selection button 3 – Next photo selection button 4 – Number of copies to print button (1 – 20) 5 – Photo format button 10x15 full page, no border 10x15 with a white border 10x13... -
Page 21: Function Crystal Image
6 – Print button 7 – Cancel button (The printer will be reinstalled if you press the button for longer than 3 seconds. It will return to the initial status at the time when the card was inserted.) 8 – Print basket button 9 –... - Page 22 9 – Paper error (refer to page 30) 10 – Consumable card icon (refer to page 30) 11 – Timer icon that flashes during printer activity 12 – Print basket function 13 – Number of the sheet to be printed...
-
Page 23: Rapid Printing
APID PRINTING Your printer is switched on, and you have inserted a memory card or you have transferred the photos via the infrared connection. Your photos are printed in four stages. The printer first prints the three colours: yellow, magenta and cyan in that order, then deposits a protective film on the sheet of paper, and finally ejects the photo. -
Page 24: Example Of Rapid Printing From A Memory Card
2. Insert the memory card into the correct printer slot. 3. The printer will analyze the memory card and show the number of valid images in the display (there are 5 in our example). -
Page 25: Create A Contact Sheet (Index)
2. Insert the memory card into the correct printer slot. 3. After inserting the memory card, the number of valid pho- tos is displayed on the screen. -
Page 26: Printing A Series Of Photos (Print Basket Function)
2. Insert the memory card into the correct printer slot. 3. After inserting the memory card, the number of valid pho- tos is displayed on the screen. -
Page 27: Deleting Photos From The Print Basket
6. Select photograph 8, using the key, press key to add this to the shopping trolley (the default number of copies is 1). 7. Press the key to add the photograph to the "shopping trolley" (the series). 8. Select photograph 16, using the key, press until the figure 2, corresponding to the desired number of copies, is displayed. -
Page 28: Pictbridge / Dpof
RIDGE Your printer will support both the PictBridge and the DPOF modes. You will be able to connect your digital camera to the printer and to send the photos directly to your printer in the PictBridge mode with a USB cable. -
Page 29: Maintenance
You will need a methylated alcohol based cleaning product and some off-the-shelf cotton tips ("Q-tips"). • Switch off your printer, disconnect the main cables and wait for five minutes; since the print head operates at a high temperature, there is a risk of burning if you touch it. - Page 30 Warning! Never touch the print head with your fingers or any object that might scratch 5. Replace the lower hatch, turn the printer right side up, connect the mains cable and switch on the printer. 6. Replace the film cartridge. Take care that the film is taut before inserting the cartridge into its compartment.
-
Page 31: Service
The printer was unplugged during a print job • Reconnect the power cable. Switch the printer on again and wait to the end of the ini- tialization. Remove any paper jam (refer to page 31) and restart the printing process. -
Page 32: Error Messages
RROR MESSAGES After any intervention on your printer, do not forget to press the key to restart the current print job. Error Icon Error Description Action displayed type Err 01 Paper No paper Check that the paper has been correctly inserted in the loading tray. -
Page 33: Paper Jam
If error persists, contact your re- tailer. APER JAM Follow this procedure if a sheet becomes stuck in the printer and cannot simply be pulled out: 1. Switch off your printer by pressing button and discon- nect the mains cable. -
Page 34: Technical Support
ECHNICAL SUPPORT This printer has been vigorously tested in our laboratories in con- junction with a wide variety of devices and peripherals. However, it is not unusual, that drivers are updated from time to time. This is due to possible compatibility problems with other components, programs and equipment not yet tested with the printer. -
Page 35: Guarantee
UARANTEE The sales receipt serves as proof of first purchase and should be kept in a safe place. It is required should you need to make use of the guarantee. Your legal rights are not restricted by these Guarantee Conditions. If the product is passed onto another user, then they shall be entitled to guarantee services for the remaining period of the guarantee. -
Page 36: Liability Limitations
IABILITY LIMITATIONS The contents of this manual are subject to unannounced changes caused by technical progress. Manufacturer and sales shall not be responsible for any damages which have been caused as a result of omissions or errors in the information provided in this manual. Under no circumstances shall we be liable for any of the following: 1.
