Left Side
®
10 - Kensington
lock ....................................................................(
11 - External monitor port VGA .....................................................(
12 - LAN port (RJ-45) ....................................................................(
13 - HDMI connector .....................................................................(
14 - e-SATA / USB port ...................................................................(
15 - USB port ...............................................................................(
16 - Multimedia card reader .........................................................(
17 - Express Card .........................................................................(
Right Side
18 19 20
15 - USB port ...............................................................................(
16 - Line Out * ...............................................................................(
19 - Microphone* ........................................................................(
20 - Audio Out* /
Digital Audio Out (S/P-DIF, optical) ....................................... (
21 - Optical Drive ........................................................................(
22 - Power socket ........................................................................(
* Ports with dual function. Configuration is set with the included software (
10
11
12
13
14
15
21
Views
16
17
(Diagram the same)
p. 64)
p. 32)
p. 49)
p. 33)
p. 63)
p. 62)
p. 53)
p. 54)
15
22
(Diagram the same)
p. 62)
p. 45)
p. 45)
p. 45)
p. 39)
p. 26)
p. 45).
