POLTI VAPORETTO LECOASPIRA INTELLIGENT 2.0 Usage Instructions

Steam cleaners
Hide thumbs Also See for VAPORETTO LECOASPIRA INTELLIGENT 2.0:

Advertisement

Quick Links

Download this manual See also: Manual
Intelligent 2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the VAPORETTO LECOASPIRA INTELLIGENT 2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for POLTI VAPORETTO LECOASPIRA INTELLIGENT 2.0

Summary of Contents for POLTI VAPORETTO LECOASPIRA INTELLIGENT 2.0

  • Page 1 Intelligent 2.0...
  • Page 2 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 6 Fig. 6a Fig. 7 Fig. 5 Fig. 8 Fig. 9 Fig. 10 Fig. 11a Fig. 11c Fig.12 Fig. 11b Fig. D Fig. B Fig. C Fig. A1 Fig. A2 Fig. A3...
  • Page 3 MAX 21...
  • Page 4 OPTIONAL S1 S2 S4 Vaporetto Lecoaspira Intelligent 2.0 - M0S10050 Edizione 1S01...

  • Page 5: Optional Accessories

    C) Universal brush 1) Main switch C1) Bristle insert for universal brush C2) Rubber insert for universal brush 2) “OK” button C3) Rigid insert for universal brush 3) “SET” button C4) Slides for locking fittings into place 4) Steam/programme “UP” button D)Steam+suction nozzle 5) Steam/programme “DOWN”...
  • Page 6 The heart of the filtration system is represented by the exclusive “Eco-Active” water filter, patented by Polti. The “Eco-Active” water filter uses the natural purifying force of water to trap dirt, preventing dispersion of dust into the environment. In addition, the HEPA filter collects impurities including pollen as well as dust mites.

  • Page 7: Safety Warnings

    KEEP THESE INSTRUCTIONS Read these instructions carefully before using the appliance. Any use which does not comply with these instructions will invalidate the warranty. SAFETY WARNINGS Risk of electric shock and/or short circuit: - The wiring system to which the appliance is connected must always comply with the laws in force. - Before connecting the appliance, make sure that the mains voltage is the same as the voltage indica- ted on the data label of the appliance and that the power outlet is connected to earth.
  • Page 8 This allows avoiding scale formation and protec- ting the metal walls of the boiler. KALSTOP FP 2003 can be found in small appliance stores and Polti service centres. Alternatively, use a 50/50 mixture of tap water and demineralised water.
  • Page 9 Polti S.p.A. declines all liability for any damage or accident deriving from any use of this appliance which is not in conformity with the instructions contained in this booklet.
  • Page 10 Lecoaspira Intelligent 2.0 s a multi-function appliance which, depending on the need and type of cleaning you want to do, can be used: - Just as a vacuum to remove dust from surfaces. In this case, remember to add water to the dirt collection container (see Paragraph 1 of the “preparing for use”) - Just as a steam cleaner to sanitise surfaces.
  • Page 11 Do not use only demineralized water but mix it as described above with tap water. We recommend you use original Polti products only, as products of other brands may not be suitable for use in Polti products and could cause unwelcome difficulties. Never use distilled water or scented water.
  • Page 12 surfaces and have been developed on surfaces with standard dimensions. When cleaning very large areas, at the end of the cycle it is possible to immediately restart the programme by simply pressing the A5key in order to complete the cleaning of the entire surface. Otherwise it is possible to finish the job in manual mode (see paragraph SET THE SUCTION LE- VEL IN MANUAL MODE for the suction function or paragraph SET THE STEAM LEVEL IN MA- NUAL MODE for the steam function).
  • Page 13 pressure of the steam corresponds to the one actually selected and the appliance is ready to be used. Press the button (A5) on the handle to dispense steam over the surface to be cleaned and the in- dicator (8D) lights up. To stop the steam flow, simply release the button (A5).
  • Page 14 165; 167 SPECIFIC MARKS/LIMESCALE/SPACE BETWEEN TILES pages 170 ; 172 UPHOLSTERY/WALL COVERINGS/CAR INTERIORS page 168 BEDS/MATTRESSES page 171 DOUBLE CURTAINS page 174 PLANTS page 175 PROFESSIONAL IRON ( only works with Polti iron connected page 175 TURBO SUCTION page 151...
  • Page 15 To select a pre-set programme, press the SET key (3); when the indicator (8A) starts to flash, it is possible to select the desired programme with the UP (4) and DOWN (5) keys. Press the OK (2) key to confirm the selection. The boiler turns on automatically in the 1 to 9 programmes.
  • Page 16 - Check that it is firmly connected. - There is also a lock button on the steam-suction extension tubes - B and B1: proceed as above for the accessories, releasing the tubes by sliding the button as far as the lock position (Fig. A3). - To connect the special accessories only for suction (E2-F-G-H-I-L) it is only necessary to attach them without coupling them to the locknut.
  • Page 17 A1) HARD FLOORS (MARBLE, GRANITE, TILE) ACCESSORIES TO BE USED: extension tubes (B-B1) or telescopic suction tube (I) only in suc- tion mode, universal brush (C) with insert, as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Extension tubes or telescopic tube + (B + B1) or I + C...

  • Page 18: Manual Mode

    HARD FLOORS (MARBLE, GRANITE, TILE) VACUUM FUNCTION vacuum up dust and liquids or effectively remove animal hair MANUAL MODE PROGRAMMED MODE Press the suction button (A4) to begin vacuu- PROGRAMME P0 ming. Adjust suction to level 4 (see specific Set the P0 programme described in the para- paragraph) to vacuum up dust or liquid.
  • Page 19 A2) CARPETING/RUGS N.B. Before treating delicate fabrics with steam, consult the manufacturer’s instructions and al- ways carry out a test on a hidden part or on a sample of the material. Allow the steamed part to dry to make sure that no changes in colour or deformations have occurred. ACCESSORIES TO BE USED: extension tubes (B-B1) or telescopic suction tube (I) only in suc- tion mode, universal brush (C) with insert, as in the following table: REFERENCE...
  • Page 20 CARPETING/RUGS VACUUM FUNCTION To vacuum up dust and animal hair. MANUAL MODE PROGRAMMED MODE Press the suction button (A4) o begin vacuu- PROGRAMME P0 Set the P0 programme described in the para- ming. Adjust suction to level 3 (see specific graph “TO USE THE APPLIANCE WITH THE paragraph) to vacuum up dust or liquid.
  • Page 21 A3) PARQUET AND TERRACOTTA N.B. Please pay careful attention when cleaning wooden surfaces and treated terracotta flooring with steam as prolonged use of steam may damage the wax, polish or colour of the surfaces to be cleaned. We therefore recommend dispensing steam on these surfaces only for short periods of time and suggest always using a cloth, avoiding direct steam being dispensed onto the surface.
  • Page 22 PARQUET AND TERRACOTTA VACUUM FUNCTION To vacuum up dirt and dust on parquet/terracotta MANUAL MODE PROGRAMMED MODE Press the suction button (A4) o begin vacuu- PROGRAMME P0 ming. Adjust suction to level 3 (see specific Set the P0 programme described in the para- paragraph) to vacuum up dust or liquid.
  • Page 23 A4) BATHROOMS/TAPS AND FITTINGS/KITCHEN WORK SURFACES ACCESSORIES TO BE USED: accessory 120° (E) with accessories as in the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER 120º accessory + Steam delivery* steam lance + E+E1 + E3 + O2 (to reach hidden cor- coloured brush + cloth ners and to remove stubborn dirt)
  • Page 24 A5) TILE WALLS ACCESSORIES TO BE USED: steam + suction nozzle (D) with insert as per the following table: REFERENCE LET- ACCESSORIES PHOTOGRAPH FUNCTION Steam + suction nozzle To vacuum and clean and 200 mm window D + D1 large surfaces with cleaning insert...
  • Page 25 B1) GLASS/MIRRORS/SHOWER CUBICLE ACCESSORIES TO BE USED: steam + suction nozzle (D) with insert as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Steam + suction nozzle Vacuum/steam cleaning and 200 mm window D + D1 for large surfaces cleaning insert Steam + suction nozzle Vacuum/steam cleaning...
  • Page 26 GLASS/MIRRORS/SHOWER CUBICLE STEAM-VACUUM FUNCTION To dissolve deposited scale, remove grease, polish and remove smears. To clean glass surfaces in particularly cold seasons, preheat the windows starting from a distance of about 50 cm) from the surface. MANUAL MODE PROGRAMMED MODE After turning on the boiler, by following the PROGRAMME P3 instructions listed in the paragraph “SET THE...
  • Page 27 B2) UPHOLSTERY/WALL COVERINGS/CAR INTERIORS N.B. Before treating leather or delicate fabrics with steam, consult the manufacturer’s instructions and always carry out a test on a hidden part or on a sample of the material. Allow the steamed part to dry to make sure that no changes in colour or deformations have occurred. ACCESSORIES TO BE USED: Upholstery suction nozzle (G), suction lance (F), steam+suction nozzle (D) with insert as per the following table: REFERENCE...

  • Page 28: Programmed Mode

    UPHOLSTERY/WALL COVERINGS/CAR INTERIORS VACUUM FUNCTION To vacuum up dust, human hair and animal hair. MANUAL MODE For suction only, we recommend using just the manual mode. Press the suction button (A4) o begin vacuuming. To vacuum up dust, adjust suction to level 3 (see specific paragraph) .
  • Page 29 B3) REMOVING STAINS FROM CARPETS/UPHOLSTERY ACCESSORIES TO BE USED: accessory 120° (E) as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER 120º accessory + cloth E + O2 Steam delivery STEAM-VACUUM FUNCTION To eliminate a specific mark MANUAL MODE PROGRAMMED MODE After turning on the boiler, by following the PROGRAMME P4...
  • Page 30 B4) BEDS/MATTRESSES ACCESSORIES TO BE USED: Upholstery suction nozzle (G), steam+suction nozzle (D) with insert as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Upholstery suction noz- Suction Steam+suction nozzle + bristle insert + terry D + D3 + O1 Steam delivery* cloth * After fitting the bristled insert (D3), the steam + suction nozzle (D) must be covered with the terry...
  • Page 31 B5) LIMESCALE/SPACE BETWEEN TILES ACCESSORIES TO BE USED: accessory 120° (E) with accessory as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Accessory 120° + small To remove dirt with the suction nozzle + colou- E + E2 + E3 steam, wiping the surfa- red brushes ce and vacuuming.
  • Page 32 LIMESCALE/SPACE BETWEEN TILES STEAM - VACUUM FUNCTION To remove deposited scale, remove dirt in tile grouting MANUAL MODE PROGRAMMED MODE After turning on the boiler, by following the PROGRAMME P4 instructions listed in the paragraph “SET THE Set the P4 programme described in the para- STEAM LEVEL IN MANUAL MODE”, set the graph “TO USE THE APPLIANCE WITH THE steam pressure on Level 2.
  • Page 33 B6) DOUBLE CURTAINS ACCESSORIES TO BE USED: steam + suction nozzle (D) with insert as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Steam nozzle+ bristle D + D3 + O1 Steam delivery insert + terry cloth N.B. After fitting the bristled insert (D3), the steam + suction nozzle (D) must be covered with the terry cloth supplied (O1).

  • Page 34: Steam Function

    S) PROFESSIONAL IRON (OPTIONAL ACCESSORY) PROGRAMME P9 Vaporetto Lecoaspira Intelligent 2.0 can quickly become an extremely efficient ironing system, allowing you to iron more quickly and with less effort. Simply connect the iron accessory to the product for Vaporetto Lecoaspira (Mod. PFEU0021). The iron can be pur- chased from Polti service centres and the best electrical appliance stores.

  • Page 35: Steam Ironing

    all levels off = SYNTHETICS and SILK 3 levels on = LINEN 2 levels on = COTTON 1 level on = WOOL NOTE: Because of the high pressure at which the product supplies steam, the maximum level of steam which can be selected for the ironing programme is 3 notches. This value is however suffi- cient to obtain the best results also on heavier fabrics.
  • Page 36 Do not swallow. Keep out of the reach of children. CONTAINS: Eugenol, Citral, Cinnamal* Contents: 100 ml Bioecologico is available in pine or citrus scents. Bioecologico is available to purchase from your local Polti retailer. *May cause allergic reaction (in direct contact with the skin).
  • Page 37 When surfaces and fabrics are sanitised using the Steam Disinfector, the risk of contagion deriving from surface contamination is drastically reduced. The Steam Disinfector is a Polti exclusive and is only available from the best electrical appliance stores.
  • Page 38 Separate all the components and rinse them under running water. (If the filter sponge has tears, replace it. To purchase one, contact an authorized Polti Service centre). After drying the various components of the “Eco-Active ” water filter, reinsert the water filter assem- bly, in the water container (20).
  • Page 39 ATTENTION: the HEPA filter (17) included with Vaporetto Lecoaspira is washable. To clean the filters, proceed as follows: • Unhook the water container handle (22) and remove the container (20) as described in the chap- ter “PREPARING FOR USE”. • Lift the HEPA filter release lever and remove the filter (18) from its housing (fig.12). •...
  • Page 40 TROUBLE CAUSE SOLUTION The suction fan does not start No power supply Check the cable, plug and socket The boiler filling pump can be Air in the boiler circuit. Switch off the appliance, allow it to heard working continuously cool and repeat the operations de- scribed in the “SWITCHING ON ”...
