Dear Panasonic Customer, Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your new colour television. The best way to understand the features of this television is to read this book thoroughly, before operating the set. -
Page 3: Warnings And Precautions
If the fitted plug has a removable fuse cover you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug must not be used until a replacement cover is obtained. Replacement fuse covers can be purchased through your local Panasonic dealer. The plug fitted to this appliance incorporates a mains filter circuit. If this is removed or replaced with a non ---filtered mains plug this television will no longer meet the European standards for Electromagnetic Compatibility (EMC). -
Page 4: Accessories
ACCESSORIES Check that you have the accessories and items shown Remote Control Transmitter EUR511300 AV cover TV Guarantee TKK8E043 (TX---21JT1) Operating Instruction book Colour TQB8E3019---2 Tube Batteries for the Remote Control Transmitter. (2 x R6 (UM3) size) CRT Guarantee Questionnaire T.V. -
Page 5: Installation And Set
INSTALLATION AND SET---UP TV only Mains Connect Aerial co---axial cable direct to TV RF IN Socket socket. Mains USING A VCR Socket Connect aerial co---axial cable to RF Input socket of VCR and a RF co---axial cable from VCR RF Out socket to TV RF IN socket. - Page 6 INSTALLATION AND SET---UP If the TV has not been tuned for you then Switch ON your VCR (if connected). Auto setup will begin. TV stations will be Switch ON your Satellite Receiver (if connected).* located, sorted and stored.* Plug the TV into a mains socket and switch ON. Programmes will appear immediately if your dealer has already tuned the TV for you.
-
Page 7: Location Of Controls
LOCATION OF CONTROLS On Screen Displays Menu Title Main Menu Contrast Brightness Cursor Bar Colour Sharpness Sub Menu C---A---T---S Tuning Menu Commands : : Select ---/+ : Adjust A guide to the various options available : Exit when in On Screen Menu operations. Front Panel Controls Headphone socket Mains Power On/Off switch... -
Page 8: Menu Operation
MENU OPERATION Menu operation is to be used in conjunction with the On Screen Display commands to guide you through function adjustments and tuning operations Auto Setup start Display Menu / Previous Menu Adjust / Access Select Exit Menu Main Menu Contrast Brightness Colour... -
Page 9: Tuning Menu
MENU OPERATION Tuning Menu The Tuning menu provides access to both manual and automatic tuning menus. Display Menu and select “Tuning Menu” Access “Tuning Menu” Main Menu CH44 Contrast Brightness Tuning Menu Colour Auto Setup Sharpness C ---A ---T ---S Manual Tuning Tuning Menu Shipping Condition... -
Page 10: Manual Tuning
MENU OPERATION Shipping Condition start Manual Tuning store Select Manual Tuning programme select Adjust / Access Manual Tuning search Display Menu / Exit Menu Previous Menu Manual Tuning The Manual tuning menu allows individual programme positions to be tuned manually. First access the Tuning menu as described on Page 9. - Page 11 MENU OPERATION Shipping Condition (Continued) Ready for Auto Setup or Manual Tuning. Confirm Start Refer to Page 9 and 10. Tuning Menu Shipping Condition Auto Setup TV/AV : Yes Manual Tuning : Previous Menu Shipping Condition : Exit Swap Tuning data will be Erased ! : Select ---/+ : Access Are you sure ?
-
Page 12: Teletext Operation
TELETEXT OPERATION Teletext features may vary depending on the Broadcasting Companies and are only available if the selected channel is transmitting Teletext. If the F button is pressed in Teletext mode the cyan contrast scale will appear; press buttons “+” and “---” to change the settings. -
Page 13: Audio / Video Connections
AUDIO / VIDEO CONNECTIONS (FRONT OR REAR) AV (Audio / Video) is a dedicated input for VCR’s, Satellite Receivers and other Audio / Video equipment. This TV is capable of switching to AV operation automatically if the equipment connected provides a switching signal to the SCART socket. -
Page 14: Vcr Installation
VCR INSTALLATION Your new TV is supplied with programme position ‘0’ designed specifically to receive an RF signal from a VCR. However, depending on the VCR’s setting you may not receive any picture or sound from the VCR on programme position ‘0’ of the TV. It will be necessary to either adjust the RF channel of the VCR or to adjust the tuning of the TV’s programme position ‘0’... -
Page 15: Vcr Operation
VCR OPERATION The Remote Control is capable of operating some functions of selected Panasonic VCR’s, please consult your dealer for details. Some VCR’s have different functions, so to ensure compatibility please refer to the VCR’s instruction book. VCR Standby Record... -
Page 16: Trouble
Do not operate the television set for a continuous period of time while using TV games or home computers. This type of picture tube damage is not an operating defect and as such is not covered by the Panasonic warranty. -
Page 17: Specifications
SPECIFICATIONS Model Number: TX ---21JT1 TX ---14JT1 Power Source: 220---240V 50Hz A.C. Power Consumption: Standby Power Consumption: 1,1W Picture Tube: 51cm visible diagonal 34cm visible diagonal Audio Output (music) 6W, 8Ω impedance, mono Dimensions: 476 (H) x 512 (W) x 470 (D) mm 352 (H) x 371 (W) x 371,5 (D) mm Weight: 20,6 kg... - Page 20 Most major credit and debit cards accepted. All enquiries, transactions and distribution facilities are provided directly by Panasonic UK Ltd. It couldn’t be simpler! Also available through our Internet is direct shopping for a wide range of finished products, take a browse on our website for further details.
