Summary of Contents for Pinnacle PCTV Dual DVB-T Pro PCI
- Page 1 PCTV Dual DVB-T Pro PCI Hardware...
- Page 2 All brand or product names are trademarks or registered trademarks of their respective holders. Pinnacle Systems GmbH has written this manual to the best of its knowledge, but does not guarantee that the programs/systems will fulfill the users’ intended applications.
-
Page 3: Table Of Contents
Table of Contents Introduction ......................1 Box Contents ......................2 System Requirements .................... 3 Operating System....................3 Processor ......................3 Working Memory....................3 Hard Disk ......................3 Graphics Card ....................3 Sound Card......................3 Expansion Slot ....................3 CD-ROM / DVD-ROM Drive or Recorder ............3 For Your Own Safety .................... -
Page 4: Introduction
Introduction Congratulations on your purchase of PCTV Dual DVB-T Pro PCI! The PCTV Dual DVB-T Pro PCI gives you two DVB-T tuners on a single PCI card – and you only need one antenna for it. Depending on the software you are using, this means you can watch or record two channels simultaneously. -
Page 5: Box Contents
Box Contents PCTV Dual DVB-T Pro PCI Installation CD (image is a sample) Remote control with batteries and receiver cable (images are samples) Quick Start Guide PDF files on CD-ROM: user manual, hardware operating instructions, remote control operating instructions Depending on the version of your product, package contents may vary. -
Page 6: System Requirements
System Requirements Your system must fulfill the following requirements if you want to guarantee proper PCTV Sat Pro PCI function: Operating System Windows XP (Home Edition, Professional Edition or Media Center Edition 2005) with the latest service pack Processor Minimum: Pentium IV with 2 GHz or equivalent AMD Athlon XP Recommended: Pentium IV with 2.8 GHz or equivalent AMD Athlon 64 Working Memory Minimum: 256 MB RAM... -
Page 7: For Your Own Safety
For Your Own Safety If you purchased your PCTV Dual DVB-T Pro PCI together with a PC and it is already installed, skip the next few sections and continue with the section "Connecting the Equipment". In the interest of your own safety and the flawless functioning of your new PCTV Dual DVB-T Pro PCI and computer system, note the following before installing any hardware: Computer components are sensitive to static charge. -
Page 8: Hardware Installation
Hardware Installation Preparing for Installation You will need a screwdriver to install your hardware. Divert any possible electrostatic charge from your body by touching the casing of your PC. Turn off your computer and all peripheral devices. Disconnect computer from the power supply and all necessary components. Loosen the computer cover screws and remove the cover. -
Page 9: Pctv Dual Dvb-T Pro Pci Hardware Installation
PCTV Dual DVB-T Pro PCI Hardware Installation Insert the card into the available PCI slot. Hold it firmly on the upper edge and ease it down into the slot by applying even pressure at both ends. Press down on the upper edge until the card fits securely in the slot. If you cannot easily insert the card into the slot, do not use force because this can bend and damage the contact springs on the socket connector. -
Page 10: Connecting The Equipment
Connecting the Equipment to motherboard for auto wake-up (internal, optional) from PC power switch TV antenna Remote control receiver (optional) -
Page 11: Tips On Positioning The Antenna
(if you are not certain, you can find out whether the antenna should have a transverse or upright position by trial and error). For active antennas without a separate power supply, activate the antenna power supply in the "Settings" menu of the Pinnacle Media Center application. Only double-shielded antenna cable should be used. -
Page 12: Technical Data
Technical Data Bus System PCI Rev. 2.3 TV Tuner 2 x Microtune MT2060 The frequency range is 48 - 860 MHz (VHF and UHF). DVB-T Demodulator 2 x Zarlink ZL10353 16.64 QAM, QPSK 6, 7, 8 MHz bandwidth UHF, VHF TV Format DVB-T Remote Input Terminal... - Page 13 Konformitätserklärung nach ISO/IEC 17050-1 Declaration of conformity in accordance with ISO/IEC 17050-1 Nr. / No 1.00 Anbieter / Supplier : Pinnacle Systems GmbH Anschrift / Address : Frankfurter Strasse 3c 38122 Braunschweig, Germany Produkt / Product : PCTV 2000i Das oben beschriebene Produkt ist konform mit: / The product described above is in conformity with: Dokument-Nr.
