Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read
these instructions carefully before connecting,
operating or adjusting this product. Please keep
this manual for future reference.
Region number
The player plays DVD-Video marked with labels
containing the region number or "ALL".
Region
For the United Kingdom and
Continental Europe
For Asia
For Australia and N.Z.
For Russia
Example: For the United Kingdom and
Continental Europe
2
ALL
Operations in these instructions are described
mainly with the main unit, but you can do the
operations on the remote control if the remote
controls are the same (➜ back cover)
Unless otherwise indicated, illustrations in these
operating instructions are of DVD-LS50.
EB
EG GCS GN EE
Portable DVD/CD Player
Number
2
3
4
5
2
3
5
Operating Instructions
DVD-LS50
Model No.
DVD-LS55

Table of contents

Caution for AC Mains Lead . . . . . . . . .2
Precautions . . . . . . . . . . . . . . . . . . . . . .3
Discs that can be played . . . . . . . . . . .5
Accessories . . . . . . . . . . . . . . . . . . . . .6
Preparations
1 Attaching the battery . . . . . . . . . . 6
2 Recharging the battery. . . . . . . . . 6
3 The remote control . . . . . . . . . . . . 7
Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Useful functions . . . . . . . . . . . . . . . . .10
RAM disc play . . . . . . . . . . . . . . . . . . .13
Playing data discs . . . . . . . . . . . . . . .14
a track . . . . . . . . . . . . . . . . . . . . . . .15
Battery pack . . . . . . . . . . . . . . . . . . . .23
Using a car adaptor . . . . . . . . . . . . . .23
[DVD-LS55] [For]Asia]
Specifications . . . . . . . . . . . . . . . . . . .26
Maintenance . . . . . . . . . . . . . . . . . . . .27
Troubleshooting guide . . . . . . . . . . .28
Useful function guide. . . . . Back cover
[Note[
"EB" on the packaging indicates the
United Kingdom.
CD . . . . . . . . . .13
. . . .24
RQT7424-2B
®
