Summary of Contents for Phonic DIGITRACK
-
Page 3: Table Of Contents
APPLICATIONS ...................11 SPECIFICATIONS..................12 PURCHASING PHONIC GEAR AND OPTIONAL ACCESSORIES ..............13 SERVICE AND REPAIR ................13 CUSTOMER SERVICE AND TECHNICAL SUPPORT......13 Phonic reserves the right to improve or alter any information supplied within this document without prior notice. V1.0 MAR 31, 2005... -
Page 4: Safety Instructions
S/PDIF input and output let you avoid digital-to-analog-to-digital conversion, which also can degrade signal quality. Use Digitrack to transfer analog or digital audio to the computer from a mixer, CD player or tape deck to create high quality digital recordings. Digitrack also provides a convenient way to play back audio from the computer through home stereo and professional sound systems. -
Page 5: Box Contents
BOX CONTENTS Digitrack USB Audio Interface One standard USB cable User's Manual FEATURES USB computer interface (compatible with most PC and Mac computers) 16-bit digital audio Supports 44.1 and 48 KHz sampling rates Two unbalanced line-level RCA inputs Two unbalanced line-level RCA outputs... -
Page 6: System Requirements
OS 9.0.4 or later with native USB support OS X 10.x or later with native USB support PowerPC G3 (300 MHz or higher) 128 MB or more of RAM 120 MB or more of free hard drive space page 6 Digitrack User's Manual PHONIC CORPORATION... -
Page 7: Panel Description
PANEL DESCRIPTION 1) USB Power Indicator The LED will illuminate to indicate that Digitrack is receiving power from the USB bus and ready to send and receive signals. The computer must be turned on and Digitrack must be connected to a properly functioning USB port on the computer. - Page 8 The digital output of your computer is converted to analog and is sent to these stereo RCA output jacks. Using these jacks, connect Digitrack to the record input on a mixer, tape deck or CD player, or connect them to the AUX inputs on your home stereo system for great sounding playback.
-
Page 9: Installation
The LED illuminates to indicate that Digitrack is receiving power from the computer. SETUP There is no need to install external drivers for Digitrack. It works with the core audio driver in Microsoft® Windows® and Apple® Macintosh® computers. However, please note under "System Requirements"... -
Page 10: Asio Drivers
Note: These entities are not affiliated with Phonic, however they offer ASIO drivers that will work with Digitrack. Phonic does not offer technical support for ASIO drivers and will not be held responsible for any damage sustained to property from installing or using these drivers. This information is merely for our customers' reference. -
Page 11: Applications
USB port. Then, locate the stereo RCA outputs of your mixer or tape deck. Use a stereo RCA cable to connect the outputs of the device to the stereo RCA inputs on Digitrack. Open the audio recording software on the computer. Increase the source output until it reaches the desired level. -
Page 12: Specifications
SPECIFICATIONS Sampling Rates DAC: 32, 44.1 and 48 KHz ADC: 8, 11.025, 16, 22.05, 32, 44.1 and 48 KHz page 12 Digitrack User's Manual PHONIC CORPORATION... -
Page 13: Purchasing Phonic Gear And Optional Accessories
SERVICE AND REPAIR Phonic has over 100 service centers worldwide. Please contact an authorized Phonic distributor for service and repairs. For a list of nearby Phonic distributors please visit our website at www.phonic.com and click on Get Gear. CUSTOMER SERVICE AND TECHNICAL SUPPORT We encourage you to visit our website at www.phonic.com.
