- Page 1 BDP-799 BLU-RAY DISC Player Instruction Manual Read this manual before installation and use...
-
Page 2: Table Of Contents
Content Introduction Important Safety Instructions Caution Features Getting Started Front Panel and Rear Panel illustration Remote Control Connections TV set Connections Digital Audio Connections Output Illustration Network Connections Advanced Features System setup File Disc(MPEG4/WMA/MP3/JPEG) Playback BD-Live Others Troubleshooting Specifications... -
Page 3: Important Safety Instructions
Important Safety Instructions Introduction 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions. 8) Do not install near any heat sources such as radiations, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Caution
Caution Introduction Please use the original box and packing materials for safe transportation of this product. It is normal for the cover and rear panel to become warm after the player has been in operation for an extended period of time. Do not move this product during playback. - Page 5 Features Introduction Player Features Supports a Variety of Video Disc Types Supports Blu-ray (BD-ROM), DVD Video and DVD-RW/-R (V mode and finalized only) discs. HDMI (High Definition Multimedia Interface) HDMI reduces picture noise by allowing a pure digital video/audio signal path from the player to your TV.
-
Page 6: Getting Started
Getting Started Introduction Region code Both the Blu-ray Disc Player and the discs are coded by region. These regional codes must match in order to play the disc. If the codes do not match, the disc will not play. The Region Number for this Blu-ray Disc Player is described on the rear panel of the Blu-ray Disc Player. - Page 7 Getting Started Introduction Discs which cannot be played on this player. HD DVD CD-I CDGs play audio only, not graphics. DVD-RAM Super Audio CD(except CD layer) Discs which can be played on this player (For the following discs, the ability to play back may depend on recording conditions.) DVD+RW...
-
Page 8: Disc Format
Getting Started Introduction CD-RW/CD-R Use a 700MB(80 minutes) CD-RW/CD-R disc. If possible, do not use a 800MB(90 minutes) or above disc, as the disc may not play back. If the CD-RW/CD-R disc was not recorded as a closed session, you may experience delays when playing back the beginning of the disc or all recorded fles may not play. -
Page 9: Disc Handling
Getting Started Introduction DISC STORAGE & MANAGEMENT Disc Handling Disc Shape Use discs with regular shapes. If an irregular disc (a disc with a special shape) is used, this Blu-ray Disc Player may be damaged. Holding discs Avoid touching the surface of a disc where recording is performed. Blu-ray Discs If the player is not used for a long period of time, remove the Blu-ray Disc from the player and store it in its case. -
Page 10: Front Panel And Rear Panel Illustration
Front Panel and Rear Panel illustration Introduction Front Panel Disc Tray Play / Pause Button Plays a disc or pauses playback. Insert a disc here. Display Window Standby Button In standby mode. Shows the current status of the player. Standby OFF Light Remote Sensor In standby mode. -
Page 11: Remote Control
Remote Control Introduction Remote Control Function key Instruction 1. STANDBY STANDBY OPEN/CLOSE Press the STANDBY button to turn the BD player ON or ANGLE SUBTITLE AUDIO OFF. POP MENU/TITLE MENU RANDOM Note: Press STANDBY key during system (about 20s) startup will be no effect. BONUS VIEW Press STANDBY key during system is on, system... - Page 12 Remote Control Introduction 11. Bonus View On BD disks, this button is used to turn the video portion of the director's commentary (picture-in-a-picture) on and off. (Not available on all disks). Note: Director's commentary must have been turned on in the BD's main menu in order for this key to work.
- Page 13 Remote Control Introduction 25. STOP This button stops playback of a BD/DVD movie or files on disk. 26. Numeric Keypad These buttons are used with the GOTO button to jump to specific title/chapter (track) or time. 27. GOTO This button is used with the numeric keypad to jump to a specific track on an audio CD.
-
Page 14: Tv Set Connections
TV Set Connections Connections TV Set Connections HDMI VIDEO AUDIO IN VIDEO IN HDMI IN CONNECT BD PLAYER TO TV SET BY AV CABLE Connect the BD player s L and R jack to the audio input jack on the TV. Connect the BD player s video out jack to the video input jack of TV. -
Page 15: Digital Audio Connections
Digital Audio Connections Connections Digital Audio Connections Connecting to an AV Amplifier with Digital Audio Input Coaxial Digital Amplifier Notes: 1. Select the Coaxial digital audio output. 2. Set the digital Amplifier to the AV input connected to the BD player. -
Page 16: Output Illustration
Output Illustration Connections Output Illustration Video Output Capabilities Each of the video outputs are capable of different levels of functionality, as described in the table below. Actual output will depend on setup menu settings and TV capabilities for HDMI Televisions. BD Player Resolutions Supported Resolutions Supported... - Page 17 Output Illustration Connections Connectors Description SPDIF Digital Audio Output audio output The SPDIF output is a digital audio output. If you have a surround-sound receiver with a SPDIF (coaxial)input, connect this output to the coaxial input of the surround sound receiver. Stereo Audio Outputs These are analog, “old fashioned”...
-
Page 18: Network Connections
You can also enjoy the BD-Live function(page 27). 10/100Mbps cable(not supplied) Connect through a Network Hub or Switch Network Cable Network Cable Network Cable Hub/Switch BDP-799 ADSL modem/ Internet Cable modem Connect through a wireless LAN router Network Cable Network Cable ADSL modem/ 802.11g/n Wireless... -
Page 19: Advanced Features
System Setup Advanced Features System Setup Press SETUP button under stop status or press RIGHT button in main menu. In setup menu, using UP/DOWN/LEFT/RIGHT and ENTER button to configure settings. System will bring out setting menu as below picture: Main Menu Setting Menu System Network... - Page 20 System Setup Advanced Features 2. Display 2.1 TV Type: Select to output NTSC or PAL video format . 2.2 Resolution: Set maximum resolution of your TV here to get best video quantity, if you are not sure, please use HDMI Auto, system will read the preferred resolution your TV supported via EDID.
- Page 21 System Setup Advanced Features 3. Audio 3.1 PCM Downsampling: select right bitrate for PCM signal to ensure your SPDIF receiver can handle it correctly. It's no effect for HDMI digital audio output. 3.2 Digital Output: If you only have two speakers, set PCM stereo. If you connect receiver with more than two speakers, please refer to below tables: Bitstream...
- Page 22 System Setup Advanced Features 4. System 4.1 Optical Disc Auto Play: This option is used to tell the BD player whether or not to start loading the main title menu of a disk as soon as the disk tray is closed.
- Page 23 System Setup Advanced Features 5.8 Secondary DNS: Show current Secondary DNS or access user input while in “Manual” IP mode. Press ENTER key while Apply button is highlighted to activate setting you made, or press ENTER key while Cancel button is highlighted to cancel changes you made for network settings.
-
Page 24: File Disc(Mpeg4/Wma/Mp3/Jpeg) Playback
File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features 4. Browsing video files 4.1 Select Videos icon in main menu which will appear after BD player read out disk or/and USB device. Press ENTER key while Video icon is highlighted, system will bring out a sub menu for file source selection.(Figure 4-1) Videos Optical Disk Settings... - Page 25 File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features 5. Browsing Audio files 5.1 Select Music icon in main menu which will appear after BD player read out disk or/and USB device. Press ENTER key while Music icon is highlighted, system will bring out a sub menu for file source selection.( Figure 5-1 ) Videos Optical Disk Settings...
- Page 26 File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features 6. Browsing picture files 6.1 Select Pictures icon in main menu which will appear after BD player read out disk or/and USB device . Press ENTER key while Pictures icon is highlighted, system will bring out a sub menu for file source selection.( Figure 6-1) Videos Optical Disk...
- Page 27 File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features 7. File playback 7.1 Refer to Figure 7-1, select “ Play All” to play all selected type files on selected media, or select ”Play Current Folder” to play all selected type files in current folder. Folder1 Please select play mode Folder2...
-
Page 28: Bd-Live
BD-Live Advanced Features BD-Live 1. D escription Some (but certainly not all) BD disks contain additional features that are made available to players that are connected to the internet, and have additional memory added. These additional features may include things like -the ability to download new movie trailers, -additional 'commentary' by actors and directors, multiperson... - Page 29 BD-Live Advanced Features 4.3 The player will connect to internet and show download menu as below picture. Note: This can take several minutes. 4.4 You can select the content to download from the Previews sub menu. Note: This can take several minutes. 4.5 The downloaded content is stored under My Downloads.
-
Page 30: Others
Troubleshooting Others Trouble shooting If you have any questions, Please consult the troubleshooting guide below. NO PICTURE OR SOUND REMOTE NOT WORKING Ensure the standby button in on. Ensure the remote batteries are working. Ensure the power outlet in operational. Point the remote control directly at the player’s IR sensor. -
Page 31: Specifications
Specifications Others Specifications General Power requirements AC100~240V 50/60Hz Power consumption < 35W 260mm(W) x48mm(H) x 240mm(D) Unit size Weight 1.83kg Audio out RCA pin Jack x2 Stereo out 0.5V(p-p)75, RCA pin Jack x l Coaxial out Frequency response 20Hz ~ 20kHz S/N ratio <... - Page 32 All specifications and figures are subject to change without notice. E-2.0V All trademarks and logos are the properties of their respective hbolders. C-0827N500...
