Page 1 DIGITAL CENTRE-SURROUND PROCESSOR OWNER'S MANUAL...
Page 2: Table Of Contents
SYSTEM FEATURES SYSTEM SPECIFICATIONS SP23 OPERATION EMERGENCY BYPASS SP23-10 (OCTAVE EQUALISERS) CARD POSITIONS SP23-30 (1/3 OCTAVE EQUALISERS) CARD POSITIONS SP23 INSTALLATION CONNECTING THE INPUTS TO THE SP23. CONNECTING THE SP23 OUTPUTS. AUTOMATION INTERFACE - 25-PIN D-CONNECTOR CONNECTION DATA SYSTEM ALIGNMENT 1 –...
Page 3: System Features
The Panastereo SP23 Surround Processor decodes 6.1 channel sound from existing digital 5.1 installations. The SP23 works with any brand of 5.1 digital sound processor is inserted between the left and right surround outputs of the sound processor and the surround amplifiers. The SP23 provides a decoded rear surround channel which can be fed to rear wall surround speakers via a rear surround amplifier.
Page 4: Sp23 Operation
The SP23 does not require any operator intervention for normal operation. The unit is automatically controlled by the cinema processor. When a digital format is selected on the cinema processor the SP23 will switch to EX decode mode and the red DECODE-ON indicator will be illuminated. In Digital mode the left and right surround channel information is decoded into three channels, left, right and rear surround.
Page 5: Sp23 Installation
RACK MOUNTING THE SP23 The SP23 can be mounted anywhere in the sound rack, although it is preferable from a wiring point of view to mount the unit between the sound processor and the amplifiers. Provision should be made for ventilation above the SP23, so avoid mounting the unit directly beneath other equipment that will prevent air circulation at the top of the SP23 chassis.
Page 6: Connecting The Inputs To The Sp23
Connect the ground terminal of each processor output to the “-“ terminal of each corresponding SP23 input. Connect the cable shield to the “E” terminal of each SP23 input only. Do not connect the shields at the sound processor. SOUND PROCESSOR WITH BALANCED OUTPUTS (PANASTEREO) Disconnect the left surround and right surround connections at the sound processor outputs.
Page 7: Connecting The Sp23 Outputs
Connect the “-“ terminal of each SP23 output to the “-“ terminal of each corresponding amplifier input. Connect the cable shield to the “E” terminal of each SP23 input only. Do not connect the shields at the amplifier. SP23 Rear Panel...
Page 8 LK1 – Selects the input for the third equaliser slot (the upper middle slot). If the SP23 is fitted with 1/3 octave equalisers for the left and right surround channels (left eq in upper left slot, and right eq in upper middle slot) then this jumper should be in the left “RS”...
Page 9: Automation Interface - 25-Pin D-Connector Connection Data
PANASTEREO SP23 – Installation. AUTOMATION INTERFACE - 25-PIN D-CONNECTOR CONNECTION DATA SP23 automation connector pins 1-8 should be pulled low (connected to pin 12) to select a format. Pins 1, 2, 3, 4 & 7 select “decode off”. Pins 5, 6 & 8 select “decode on”.
Page 10: System Alignment
PANASTEREO SP23 – Alignment. SYSTEM ALIGNMENT Refer to the appropriate section of the manual for alignment with various sound processors. 1 – Panastereo CSP3200, CSP4200, CSP1200 2 - Dolby CP55 3 – Dolby CP65 4 - Dolby CP500 5 - Smart MOD 6 with DSP Matrix...
Page 11: Alignment With Panastereo Processors
Set up a Real Time Analyser and position the microphones in the auditorium. PRE-SET SP23 OUTPUT LEVELS Turn all four output trimmers on the SP23 anticlockwise until you feel a slight click. SWITCH SP23 TO BYPASS Switch the SP23 to bypass mode (Red Bypass button IN).
Page 12 Switch on the Left Surround button on the Pink Noise card. 14. ADJUST SP23 LS INPUT LEVEL Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated. 15. COARSE SET LS SPL LEVEL TO 85dBC...
Page 13 22. SET RIGHT SURROUND SPL LEVEL TO Re-adjust the Right Surround Output trimmer 85dBC on the SP23 for 85dBC in the auditorium. 23. SELECT BOTH LS AND RS ON PINK Switch on both left and right surround on the NOISE CARD Pink Noise Card 24.
Page 14 35. SET REAR LEFT SURROUND SPL Adjust the Rear Left Surround Output trimmer LEVEL TO 88dBC (CSL) on the SP23 for 88dBC in the auditorium. 36. TURN OFF LEFT REAR AMPLIFIER AND Switch off or disconnect the rear left-surround...
Page 15 PANASTEREO SP23 – Alignment with PANASTEREO PROCESSORS 43. END OF PROCEDURE The system is now ready to use.
Page 16: Alignment With Dolby Cp55
Set up a Real Time Analyser and position the microphones in the auditorium. PRE-SET SP23 OUTPUT LEVELS Turn all four output trimmers on the SP23 anticlockwise until you feel a slight click. SWITCH SP23 TO BYPASS Switch the SP23 to bypass mode (Red Bypass button IN).
Page 17 NOISE CARD Pink Noise card. ADJUST SP23 INPUT LEVELS Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated. Adjust the Right Input trimmer on the SP23 so that the two green LEDs for the right channel are equally illuminated.
Page 18 SET RIGHT SURROUND SPL LEVEL Re-adjust the Right Surround Output trimmer TO 85dBC on the SP23 for 85dBC in the auditorium. UNMUTE THE LEFT CHANNEL On the SP23, release the left channel mute button. IF A TWO CHANNEL REAR...
Page 19 SET REAR LEFT SURROUND SPL Adjust the Rear Left Surround Output trimmer LEVEL TO 88dBC (CSL) on the SP23 for 88dBC in the auditorium. TURN OFF LEFT REAR AMPLIFIER Switch off or disconnect the rear left-surround AND TURN ON RIGHT REAR...
Page 20 PANASTEREO SP23 – Alignment with DOLBY CP55 REMOVE PINK NOISE CARD Remove the pink noise card from the processor and replace the Cat.150 decoder card. The system is now ready to use. END OF PROCEDURE...
Page 21: Alignment With Dolby Cp65
Set up a Real Time Analyser and position the microphones in the auditorium. PRE-SET SP23 OUTPUT LEVELS Turn all four output trimmers on the SP23 anticlockwise until you feel a slight click. SWITCH SP23 TO BYPASS Switch the SP23 to bypass mode (Red Bypass button IN).
Page 22 NOISE CARD Pink Noise card. ADJUST SP23 INPUT LEVELS Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated. Adjust the Right Input trimmer on the SP23 so that the two green LEDs for the right channel are equally illuminated.
Page 23 SET RIGHT SURROUND SPL LEVEL Re-adjust the Right Surround Output trimmer TO 85dBC on the SP23 for 85dBC in the auditorium. UNMUTE THE LEFT CHANNEL On the SP23, release the left channel MUTE button. IF A TWO CHANNEL REAR...
Page 24 SET REAR LEFT SURROUND SPL Adjust the Rear Left Surround Output trimmer LEVEL TO 88dBC (CSL) on the SP23 for 88dBC in the auditorium. TURN OFF LEFT REAR AMPLIFIER Switch off or disconnect the rear left-surround AND TURN ON RIGHT REAR...
Page 25 PANASTEREO SP23 – Alignment with Dolby CP65. REMOVE PINK NOISE CARD Remove the pink noise card from the processor and replace the Cat.150 decoder card. The system is now ready to use. END OF PROCEDURE...
Page 26: Alignment With Dolby Cp500
Set up a Real Time Analyser and position the microphones in the auditorium. PRE-SET SP23 OUTPUT LEVELS Turn all four output trimmers on the SP23 anticlockwise until you feel a slight click. SWITCH SP23 TO BYPASS Switch the SP23 to bypass mode (Red Bypass button IN).
Page 27 Ls channel. Do not adjust the output level of the CP500. ADJUST SP23 LS INPUT LEVEL Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated. COARSE SET LS SPL LEVEL TO...
Page 28 SET RIGHT SURROUND SPL LEVEL Re-adjust the Right Surround Output trimmer TO 82dBC on the SP23 for 82dBC in the auditorium. SELECT PINK NOISE TO Ms On the CP500 use the fader knob to select the CHANNEL Ms channel. Do not adjust the output level of the CP500.
Page 29 SET REAR LEFT SURROUND SPL Adjust the Rear Left Surround Output trimmer LEVEL TO 85dBC (CSL) on the SP23 for 85dBC in the auditorium. TURN OFF LEFT REAR AMPLIFIER Switch off or disconnect the rear left-surround AND TURN ON RIGHT REAR...
Page 30: Alignment With Smart Mod Vi With Dsp Matrix
PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix 5 – ALIGNMENT with SMART MOD VI with DSP MATRIX Equipment required: Real Time Analyser (RTA) SET UP REAL TIME ANALYSER Set up a Real Time Analyser and position the microphones in the auditorium.
Page 31 PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix SET PINK NOISE TO LS Select the Pink Noise generator output to Left Surround. (Time Delay switch position “D”). ADJUST SP23 LS INPUT LEVEL Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated.
Page 32 PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix TURN OFF THE LEFT AND RIGHT Switch off or disconnect the inputs to the left SURROUND AMPLIFIER(S) surround and right surround amplifier(s). IF A TWO CHANNEL REAR SURROUND AMPLIFIER IS...
Page 33 PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix COARSE SET REAR LEFT Adjust the Rear Left Surround Output trimmer SURROUND SPL LEVEL to 82dBC (CSL) for approximately 82dBC SPL in the auditorium. EQUALISE REAR LEFT SURROUND Remove the Rear Equaliser from the SP23 CHANNEL and connect it via the extender card and cable.
Page 34 PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix TURN ON LEFT AND RIGHT Switch on, or re-connect the inputs to the left SURROUND AMPLIFIERS and right surround amplifier(s). END OF PROCEDURE The system is now ready to use.
Page 35: Alignment With Smart Mod Vi With Analog Matrix
PANASTEREO SP23 – Alignment with SMART MOD VI – Analog Matrix 6 – ALIGNMENT with SMART MOD VI with Analog Matrix Equipment required: Real Time Analyser (RTA) SET UP REAL TIME ANALYSER Set up a Real Time Analyser and position the microphones in the auditorium.
Page 36 PANASTEREO SP23 – Alignment with SMART MOD VI – Analog Matrix SELECT “OPTICAL STEREO” Select the sound processor to OPTICAL FORMAT STEREO (to send pink noise to the outputs). TURN OFF SP23 BYPASS Switch the SP23 out of bypass mode (Red Bypass button OUT).
Page 37 PANASTEREO SP23 – Alignment with SMART MOD VI – Analog Matrix SET RIGHT SURROUND SPL LEVEL Re-adjust the Right Surround Output trimmer TO 85dBC on the SP23 for 85dBC in the auditorium. SELECT BOTH LS AND RS PINK Set SW2-4 and 5 down.
Page 38 PANASTEREO SP23 – Alignment with SMART MOD VI – Analog Matrix EQUALISE REAR LEFT SURROUND Remove the Rear Equaliser from the SP23 CHANNEL and connect it via the extender card and cable. Adjust the left equaliser controls for a frequency response in accordance with the standard ISO surround channel response curve.
Page 39: Alignment With Smart Mod Iic
PANASTEREO SP23 – Alignment with SMART MOD IIC 7 – ALIGNMENT with SMART MOD IIC Equipment required: SMART Pink Noise Card, Real Time Analyser (RTA) SET UP REAL TIME ANALYSER Set up a Real Time Analyser and position the microphones in the auditorium.
Page 40 NOISE CARD Pink Noise card. ADJUST SP23 INPUT LEVELS Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated. Adjust the Right Input trimmer on the SP23 so that the two green LEDs for the right channel are equally illuminated.
Page 41 PANASTEREO SP23 – Alignment with SMART MOD IIC EQUALISE RIGHT SURROUND Adjust the right equaliser controls for a CHANNEL frequency response in accordance with the standard ISO surround channel response curve. SET RIGHT SURROUND SPL LEVEL Re-adjust the Right Surround Output trimmer TO 85dBC on the SP23 for 85dBC in the auditorium.
Page 42 PANASTEREO SP23 – Alignment with SMART MOD IIC COARSE SET REAR LEFT Adjust the Rear Left Surround Output trimmer SURROUND SPL LEVEL to 85dBC (CSL) for approximately 85dBC SPL in the auditorium. EQUALISE REAR LEFT SURROUND Remove the Rear Equaliser from the SP23 CHANNEL and connect it via the extender card and cable.
Page 43: Alignment With Ultra Stereo Jsx1000
Set up a Real Time Analyser and position the microphones in the auditorium. PRE-SET SP23 OUTPUT LEVELS Turn all four output trimmers on the SP23 anticlockwise until you feel a slight click. SWITCH SP23 TO BYPASS Switch the SP23 to bypass mode (Red Bypass button IN).
Page 44 NOISE CARD Noise card. ADJUST SP23 INPUT LEVELS Adjust the Left Input trimmer on the SP23 so that the two green LEDs for the left channel are equally illuminated. Adjust the right Input trimmer on the SP23 so that the two green LEDs for the right channel are equally illuminated.
Page 45 PANASTEREO SP23 – Alignment with ULTRA STEREO JSX1000 UNMUTE THE LEFT CHANNEL On the SP23, release the left channel MUTE button. IF A TWO CHANNEL REAR SURROUND AMPLIFIER IS INSTALLED GOTO 31 COARSE SET LEFT REAR Adjust the Rear Left Surround Output trimmer...
Page 46 PANASTEREO SP23 – Alignment with ULTRA STEREO JSX1000 EQUALISE REAR LEFT SURROUND Remove the Rear Equaliser from the SP23 CHANNEL and connect it via the extender card and cable. Adjust the left equaliser controls for a frequency response in accordance with the standard ISO surround channel response curve.
