Gibson Echoplex Digital Pro Plus User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Echoplex
Digital Pro Plus
User 's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Echoplex Digital Pro Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gibson Echoplex Digital Pro Plus

  • Page 1 Echoplex Digital Pro Plus User ’s Manual...

  • Page 2: Credits

    A N D A L L W H O H A V E C O N T R I B U T E D T H E I R T H O U G H T S A N D I D E A S T H R O U G H O U T T H E H I S T O R Y O F T H E C H O P L E X Echoplex Digital Pro Plus User’s Manual...
  • Page 3 O N T A C T N F O R M A T I O N O R M O R E I N F O R M A T I O N C O N T A C T U R O P E R A C E L L I O T...
  • Page 4 Echoplex Digital Pro Plus User’s Manual...

  • Page 5: Table Of Contents

    Echoplex Digital Pro Plus ’ C o n t e n t s Introduction Credits ................i-2 Contact Info ................i-3 Contents ................ii-1 About This Manual..............iii-1 Typeface Conventions ................iii-1 Terminology ....................iii-2 Section I – User Guide User Guide Introduction ..............I-i Chapter 1 Quick Start ...............1-1 Instant Gratification and Depth..............1-1 Before Powering Up .................1-2 Level Adjustment ..................1-3...
  • Page 6 SamplerStyle...................4-44 Source #....................4-47 SwitchQuant ...................4-48 Sync ......................4-57 Threshold....................4-59 Velocity....................4-60 VolumeCont....................4-61 Chapter 5 Functions..............5-1 Dump ......................5-2 Feedback ....................5-4 GeneralReset.....................5-8 HalfSpeed....................5-9 Insert .......................5-10 Load......................5-18 LoopDivide .....................5-20 LoopTriggering ..................5-21 LoopWindowing..................5-22 MultiIncrease..................5-26 Multiply....................5-28 Mute ......................5-38 NextLoop ....................5-41 ii-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 7 Overdub ....................5-43 PreviousLoop..................5-46 Record .....................5-47 Rehearse....................5-53 Replace....................5-54 Reset ......................5-55 Retrigger....................5-56 Reverse ....................5-58 SamplePlay .....................5-62 StartPoint ....................5-64 Substitute....................5-65 SUS Commands ..................5-69 SUSNextLoop ..................5-71 Undo......................5-72 Chapter 6 Synchronization ............6-1 AutoStartPoint ..................6-2 BeatSync ....................6-3 BrotherSync ....................6-7 Global/Local MIDI Clock ................6-9 MIDI Sync Indicators ................6-11 MuteQuantMIDIStartSong..............6-12 QuantMIDIStartSong................6-13 QuantStartPoint ..................6-14...
  • Page 8 Visual Tempo Guide................9-30 Chapter 10 MIDI Sample Dump ..........10-1 Introduction ...................10-2 Sample Dump User Guide..............10-9 Other Device Implementations ............10-16 Sample Dump Trouble Shooting ............10-20 Chapter 11 MIDI SysEx ..............11-1 MIDI SysEx Detailed Reference ............11-2 ii-4 Echoplex Digital Pro Plus User’s Manual...

  • Page 9: About This Manual

    About This Manual Y P E F A C E O N V E N T I O N S User Interface elements like Buttons, Jacks, and Knobs are shown in bold, since references to them are usually about actions that you might take.

  • Page 10: Terminology

    THER ODES These are the states that the Echoplex Digital Pro Plus is in after you’ve pressed a button to initiate an action, but before you’ve ended the action. The mode is the name of the button that you’ve pressed; e.g.
  • Page 11 Display while in Play mode (the length of the recorded material), which will be less than the total length available for recording. If the MoreLoops parameter is greater than one (see MoreLoops in the Reference section), then the Echoplex will hold several different loops. In this case, one loop will be active at any given time, and we’ll call this the current loop.
  • Page 12 It is possible for the user to force a Rounded action to end without Rounding. This is referred to as an UnRounded operation. For example, an UnRounded Multiply is a Multiply that is forced to end without reaching the end of the cycle. iii-4 Echoplex Digital Pro Plus User’s Manual...

  • Page 13: Section I - User Guide

    User Guide S E R U I D E N T R O D U C T I O N This section will help you get started using the Echoplex and provide instruction on using some of the Echoplex’s most common features. For greater detail and complete information about all Echoplex features, please consult Section II, the Reference Guide.
  • Page 14 I-ii Echoplex Digital Pro Plus User’s Manual...

  • Page 15: Chapter 1 Quick Start

    Quick Start ongratulations! You’re in for more fun than you can possibly imagine, playing music with the Echoplex Digital Pro Plus. This is the spiritual successor to the original Echoplex, a device made by Maestro in the 1960s that relied on tape loops to create effects. It was used extensively by the Jimi Hendrix, the Doors, and many others.
  • Page 16 5. Connect the Echoplex’s Audio Output jack to an amplifier, mixer, or preamp to let you hear what’s happening! These are all the basic connections. See Chapter 2 for information on additional possibilities. 1-2 Echoplex Digital Pro Plus User’s Manual...

  • Page 17: Level Adjustment

    Tu r n i t O n Use the power switch at the right of the Echoplex Digital Pro to turn it on. The display will briefly show the software version number and then switch to the standard display (see the section titled “The Display” in Chapter 2).

  • Page 18: Start Looping

    (see Appendix A, Memory for more details). Your maximum recording time is displayed when you first power on the Echoplex Digital Pro Plus. If you exceed this time during recording, your loop won’t be kept (with the default settings. See Overflow in the Reference chapter for other options).
  • Page 19 M u t e If you get sick of listening to your loop, you can silence it without erasing it by pressing the Mute button. The light under the Mute button on the front panel will turn red. Press the Mute button a second time to hear your loop again.
  • Page 20 Parameter editing. The parameter we wish to change is called InsertMode. This parameter determines what function the Insert button will do. We are going to set it to become the Reverse button. 1-6 Echoplex Digital Pro Plus User’s Manual...
  • Page 21 1. In the Parameter Matrix printed on the front panel of the Echoplex, locate the InsertMode parameter. You should see it in the row labeled Switches, under the Insert button. 2. Press the Parameter button. You are now in the Parameter Editing Mode.
  • Page 22 • • loop Feedback Input Output LOOPTIME MULTIPLE LOOP Level Indicator Lights Display Level Control Knobs : The Echoplex Digital Pro Plus front panel, left half IGURE Buttons Status Indicator Lights Parameters Record Overdub Multiply Ins/Rev Undo NextLoop Mute Loops...

  • Page 23: Chapter 2 Front, Back And Underfoot

    Front, Back and Underfoot In this chapter we’ll discuss the physical elements of the interface: the front panel, optional EFC-7 footpedal, and back panel. R O N T A N E L The front panel of the Echoplex Digital Pro contains a Power Switch, Knobs that set critical levels, two multicolored Level Indicator Lights to monitor levels, a 6-character Display that shows timing and other information, and a row of eight multi-function Buttons for setting...
  • Page 24 The Multiple display on the right will show how many loops are currently setup with the MoreLoops parameter. The following illustration shows the display immediately after bootup. 2-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 25 Current number of loops Number of the Total LoopTime IGURE (set with MoreLoops ) current loop per Loop The startup display shows the time available and number of loops setup. • LOOPTIME LOOP MULTIPLE ISPLAY A typical display in Play Mode looks like this: Flashes to indicate Number of the Current Cycle...
  • Page 26 ODE AND THE NDICATOR IGHTS The row of 8 buttons on the right side of the Echoplex Digital Pro Plus control most operations. The leftmost button, labeled Parameters alters the meaning of the other buttons. When none of the Row Indicator...
  • Page 27 instance, when the Loops light is on, the Record button no longer performs the Record function; instead, it finds a convenient phone booth and changes into the MoreLoops button, able to increase the number of loops with a single push. When we refer to this in the text, we’ll utilize both button names;...

  • Page 28: The Back Panel

    A u d i o C o n n e c t i o n s The Echoplex Digital Pro can accept a wide range of audio signals as input, and it outputs a line-level signal that can be attenuated by the 2-6 Echoplex Digital Pro Plus User’s Manual...
  • Page 29 This connector doesn’t work with all pedals, but it will work with many, including the popular Boss FV-50L. Call Gibson if you are in doubt about whether a particular pedal will work (or test it, if it’s convenient).
  • Page 30 Vo l t a g e S e l e c t o r S w i t c h The Echoplex Digital Pro Plus can operate on US-style 115V power, Japanese-style 100V power, and on European-style 230V power. All that’s required is that the Voltage Selector Switch be set properly and the proper power cord be attached to the Power Input Jack.

  • Page 31: Stereo Operation

    T E R E O P E R A T I O N You can use a pair of Echoplex Digital Pro Pluses to loop stereo signals. A BrotherSync connection will ensure that the two halves of the signal maintain their phase relationships through loops of any length. A MIDI connection provides simultaneous control over the process.
  • Page 32 2-10 Echoplex Digital Pro Plus User’s Manual...

  • Page 33: Chapter 3 Midi

    MIDI There are a number of different ways that MIDI interacts with the Echoplex Digital Pro. The MIDI chapter in the Reference guide contains extensive details on all MIDI features. The MIDI functions available are: You can virtually control all front-panel buttons with NoteOn or Continuous Control messages (see the ControlSource and VirtualButtons entries in the Reference chapter).
  • Page 34 Parameters can be directly edited using MIDI SysEx. Parameters and Presets can be uploaded and downloaded for saving on a computer or other storage device, also using MIDI SysEx commands. (see the SysEx chapter in the Reference section.) 3-2 Echoplex Digital Pro Plus User’s Manual...

  • Page 35: Section Ii - Reference Guide

    Reference Guide E F E R E N C E U I D E N T R O D U C T I O N This section is a comprehensive reference for the Echoplex Digital Pro Plus. You can find any function or button name, any knob, and any jack by looking for its name in the upper outside corners of these pages.

  • Page 36: Key To The Diagrams

    The button abbreviations are: Record button Overdub button Multiply button Insert button Mute button Undo button NextLoop button The arrows have the following meanings: Press and release the button in one motion. II-ii Echoplex Digital Pro Plus User’s Manual...
  • Page 37 Press the button and hold it down Release the button Reference II-iii...
  • Page 38 II-iv Echoplex Digital Pro Plus User’s Manual...

  • Page 39: Chapter 4 Parameters

    Parameters Reference - Parameters 4-1...

  • Page 40: 8Ths/Cycle

    1. Set 8ths/Cycle=8. This means that each cycle will be eight eighth-notes (one measure) long. 2. Set Sync=In. 3. Connect the MIDI Out port of a clock source to the Echoplex Digital Pro’s MIDI In port using a standard MIDI cable. 4-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 41 8ths/Cycle Continued 4. Make sure that your clock source is set to transmit MIDI Clocks (this setting is usually found under a “MIDI” or “Sync” menu or function key). 5. Reset the current loop by holding down the Record button for several seconds.
  • Page 42 Try changing 8ths/Cycle with Sync = Out and a sequencer slaving to the clock. You control the sequencer's tempo in relation to your loop! 4-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 43 8ths/Cycle Continued M I D I C L O C K I M I T S There is a limit to how fast the Echoplex will transmit MIDI clocks—the equivalent of about 400 beats per minute. If you create a loop that’s 1/2 a second long with 8ths/Cycle=16, then that 1/2 second will represent 2 measures, or 8 beats.

  • Page 44: Autorecord

    2. Record a short loop in loop 1 3. Press the NextLoop button 4. Start playing right away—you’ll be recording 5. Press Record or NextLoop to end recording in Loop 2 See Also: MoreLoops, SwitchQuant, LoopTrig, NextLoop 4-6 Echoplex Digital Pro Plus User’s Manual...

  • Page 45: Channel

    Channel Default: 1 Parameter Row: MIDI Determines the MIDI channel for all MIDI functions. Values: 1-16 This sets the MIDI channel for controlling Echoplex operations with an external MIDI controller or sequencer. See also: Source #, ControlSource, MIDI Control Chapter Reference - Parameters 4-7...

  • Page 46: Controlsource

    Suppose, for instance, that you want to create a short sequence to change the SamplerStyle to One. If you start from the normal playing 4-8 Echoplex Digital Pro Plus User’s Manual...
  • Page 47 ControlSource Default: Notes Continued state, and also have SamplerStyle set to its default value of Run, it takes 4 pushes of the Parameters button and two pushes of the NextLoop (SamplerStyle) button to accomplish this. So you record exactly those button pushes into a sequence.

  • Page 48: Feedbkcont

    Feedback Jack on the back panel. See the explanation of the Feedback Knob in this chapter for the most detailed explanation of feedback. See also: Channel, Feedback, Feedback Knob, Feedback Jack 4-10 Echoplex Digital Pro Plus User’s Manual...

  • Page 49: Insertmode

    InsertMode Default: Rehearse Parameter Row: Switches Affects the behavior of the Insert button Values: Rehearse (rhr), Replace (rPL), Substitute (Sub), HalfSpeed (h.SP), Reverse (rEV), Insert (InS), Sustain (SUS) InsertMode redefines the function of the Insert button so that different functions can be available from the front panel according to your needs. All of these functions are also available independently by MIDI.
  • Page 50 U B S T I T U T E When InsertMode=Substitute, the Insert button becomes the Substitute button during Play mode. Substitute has some similarity to the Replace function. However, with Substitute the original loop playback continues 4-12 Echoplex Digital Pro Plus User’s Manual...
  • Page 51 InsertMode Continued while you are playing the new material. On the next repetition, only the new audio will remain in the loop and the old portion will be removed. See Substitute in the Functions section for more details. N S E R T O D E A L F P E E D...
  • Page 52 Cycle point it is ended immediately and the loop time is redefined. See SUS Commands in the Functions section for more details. See also: Insert, Record, HalfSpeed, Reverse, Replace, Substitute, SUS Commands 4-14 Echoplex Digital Pro Plus User’s Manual...

  • Page 53: Loop/Delay (Interfacemode)

    Loop/Delay (InterfaceMode) Default: Loop Parameter Row: Timing Switch between loop and digital delay applications. Values always available: Loop (LOP), Delay (dEL), Expert (EXP), Stutter (Stu) Values also available with a pedal inserted: Out (Out), Input (In), Replace (rPL), Flip (FLI) The Loop/Delay parameter determines how feedback, Loop Input Volume, and Loop Output Volume are controlled during various states.
  • Page 54 Output Volume are set in various states. Table 4.x: LoopMode State Feedback Loop Loop Input Output (Pedal/NoPedal) Playing Pedal/Knob 100% Overdubbing Pedal/Knob 100% 100% Substituting 100% 100% Recording 100% Multiplying Pedal/Knob 100% 100% Inserting 100% Replacing 100% Mute 100% 4-16 Echoplex Digital Pro Plus User’s Manual...
  • Page 55 Loop/Delay (InterfaceMode) Continued = d E L ) E L AY O D E O O P E L AY DelayMode operation is like a traditional delay, and is useful for people familiar with that style of looping. In a traditional delay, the input to the delay line is always open and Feedback is always being applied.
  • Page 56 When there is no pedal connected to the Feedback Pedal Jack, the Feedback during play is always set to maximum (100%). The following table shows how Feedback, Loop Input Volume, and Loop Output Volume are set in various states. 4-18 Echoplex Digital Pro Plus User’s Manual...
  • Page 57 Loop/Delay (InterfaceMode) Continued Table 4.x: ExpertMode State Feedback Loop Loop Input Output (Pedal/NoPedal) Playing Pedal/100% 100% Overdubbing Knob 100% 100% Substituting 100% 100% Recording 100% Multiplying Knob/100% 100% 100% Inserting 100% Replacing 100% Mute 100% SamplePlay 100% Pedal = S t u ) T U T T E R O D E O O P...
  • Page 58 Substitute gains more advanced control in StutterMode. If you have a Pedal inserted in the Feedback Pedal Jack for Feedback control, the pedal controls the Feedback during normal use and the knob setting is 4-20 Echoplex Digital Pro Plus User’s Manual...
  • Page 59 Loop/Delay (InterfaceMode) Continued not used. However, during Substitute the FeedBack Knob becomes active for Feedback control. This lets you have two different Feedback settings between normal playing and Substituting. If you do not have a pedal inserted, Substitute operates the way it normally does in LoopMode and has Feedback set to 0 while active.
  • Page 60 Feedback Pedal Jack. InputMode behaves just like LoopMode except that the pedal controls the Loop Input Volume in the states where the input is open. Feedback is only controlled by the 4-22 Echoplex Digital Pro Plus User’s Manual...
  • Page 61 Loop/Delay (InterfaceMode) Continued front panel FeedBack Knob. InputMode does not exist without a Pedal connected. The following table shows how Feedback, Loop Input Volume, and Loop Output Volume are set in various states. Table 4.x: InputMode State Feedback Loop Loop Input Output (Pedal/NoPedal)
  • Page 62 Output Volume are set in various states. Table 4.x: ReplaceMode State Feedback Loop Loop Input Output Playing Pedal Pedal Overdubbing Pedal 100% Pedal Substituting Knob 100% 100% Recording 100% Multiplying Pedal 100% Pedal Inserting 100% Replacing 100% Mute 100% 4-24 Echoplex Digital Pro Plus User’s Manual...
  • Page 63 Loop/Delay (InterfaceMode) Continued = F L I ) L I P O D E O O P E L AY FlipMode is an unusual and interesting InterfaceMode, in that the pedal controls both Loop Input Volume and Feedback simultaneously. The interesting thing is that Feedback on the pedal is reversed! When the pedal is all the way in the toe-up position, the Loop Input level is zero and the feedback is at 100%.
  • Page 64 State Feedback Loop Loop Input Output (reversed) Playing Pedal Pedal 100% Overdubbing Knob Pedal 100% Substituting Pedal 100% Recording Pedal Multiplying Pedal Pedal 100% Inserting Pedal Pedal 100% Replacing 100% Mute Pedal Pedal 4-26 Echoplex Digital Pro Plus User’s Manual...
  • Page 65 Loop/Delay (InterfaceMode) Continued S I N G T H E N T E R F A C E O D E S W I T H A T E R E O C H O P L E X E T U P Many of the InterfaceModes require a pedal connected to the Feedback Pedal Jack in order to be available at all, and use that pedal as a key part of their functionality.
  • Page 66 InterfaceModes that use the pedal for those will not work very well this way for Stereo. See also: Feedback Knob, Feedback Pedal Jack, Overdub, Substitute, Replace, Record, Multiply, Insert, Mute, Undo, LoopCopy 4-28 Echoplex Digital Pro Plus User’s Manual...

  • Page 67: Loopcopy

    LoopCopy Default = off Parameter Row: Loops Copies the current loop into the next, in several ways Values: Off, Timing, Sound When LoopCopy is set to Sound (Snd) or Timing (ti) , The Echoplex will do a copy function anytime you switch into a reset loop. O P Y T H E U D I O T O A O O P...
  • Page 68 Another way to perform copies is to use Multiply, Insert, or Overdub as alternate endings to a NextLoop press when SwitchQuant=On . See the discussion under the SwitchQuant heading in this chapter for a full explanation and examples. See also: NextLoop, SwitchQuant, AutoRecord 4-30 Echoplex Digital Pro Plus User’s Manual...

  • Page 69: Looptrig

    LoopTrig Default: 84 Parameter Row: Loops Determines which MIDI note numbers will trigger loops. Values: 0-127 When multiple loops are set up using the MoreLoops parameter, incoming MIDI NoteOn messages can trigger any loop’s playback. This function is called LoopTriggering, and is described in more detail in the functions section.

  • Page 70: Moreloops

    Multiply. This is called a GeneralReset. Both types of Reset are also available as DirectMIDI commands. See Also: LoopCopy, NextLoop, AutoRecord, LoopTrig, SamplerStyle, Velocity, Multiply, SwitchQuant 4-32 Echoplex Digital Pro Plus User’s Manual...

  • Page 71: Mutemode

    MuteMode Default: Continuous Parameter Row: Switches Determines how sound is restarted after it is muted. Values: Continuous (Cnt), Start (StA) MuteMode determines where loop playback starts the second time you press the Mute button to UnMute a loop. Whichever approach you choose, the Undo button takes the opposite viewpoint, so you’ll always have both ways to end a Mute readily available.

  • Page 72: Overdubmode

    Echoplex. You will always know the state of Overdub by whether you are pressing it or not. See Also: Overdub 4-34 Echoplex Digital Pro Plus User’s Manual...

  • Page 73: Overflow

    Overflow Default: Stop Parameter Row: Switches Determines how Record handles memory overflows. Values: Stop(StP), Play (PLY) An overflow occurs when you attempt to use more memory than you have during Record operations. When Overflow=Stop, exceeding the memory capacity of your unit will cause the Record operation to be immediately cancelled, and will reset (erase) the current loop.

  • Page 74: Quantize

    This is meaningful if you have used Multiply or Insert to add cycles to the loop. When you press a function in the middle of the loop, it will wait until the Loop StartPoint to execute. 4-36 Echoplex Digital Pro Plus User’s Manual...
  • Page 75 Quantize Continued UANTIZE YCLE When Quantize=Cycle , the Echoplex waits until the current Cycle completes before executing the function. This is more meaningful if you have used Multiply or Insert to add cycles to the loop, otherwise the Cycle and the overall Loop are the same. UANTIZE YCLE When Quantize=8th, functions are Quantized to the next Sub-Cycle as...
  • Page 76 If you like, you can think of this as “double-clicking” the function. See also: Multiply, Insert, Mute, Reverse, Substitute, HalfSpeed, SyncRecord, 8ths/Cycle, LoopDivide, LoopTime Display. 4-38 Echoplex Digital Pro Plus User’s Manual...

  • Page 77: Presets

    Presets Presets Editor Parameter Row: Switches Enters the Preset Editor. Pressing the Presets in the Parameter Matrix puts you into the Preset Editor. More information is available in the Presets section. See also: Parameter Presets, Preset Editor Reference - Parameters 4-39...

  • Page 78: Recordmode

    If you are using MIDI, both Reset and GeneralReset are available independently as DirectMIDI commands. So with MIDI, reset is not a problem. 4-40 Echoplex Digital Pro Plus User’s Manual...
  • Page 79 RecordMode Continued Also note that if you are using MIDI there is a DirectMIDI command for independent sustain action Record. This command is called SUSRecord and is located at Source# + 14. ECORD RecordMode=Safe is just like RecordMode=Toggle except that after a Record the Feedback is always set to 100%.

  • Page 80: Reserved

    Now Presets Parameter Row: Switches This is now called Presets on current Echoplexes, and it accesses the Preset Editor. If you have an older Echoplex with a “Reserved” parameter, see the Preset section. 4-42 Echoplex Digital Pro Plus User’s Manual...

  • Page 81: Roundmode

    RoundMode Default: Off Parameter Row: Switches Determines whether certain material will be recorded. Values: Off (OFF), Round (rnd) During Multiply and Insert operations, which always are active for an exact number of cycles (unless ended with the Record button), this parameter determines whether new material played after the second press of the button but before the end of the current cycle will be recorded.

  • Page 82: Samplerstyle

    ‘B’ or ‘C’ section to drop in for one repetition before returning to the main loop. With SamplerStyle=One you can do this with one press on NextLoop and let the Echoplex take care of everything for you. 4-44 Echoplex Digital Pro Plus User’s Manual...
  • Page 83 SamplerStyle Continued (Att) TTACK When SamplerStyle=Attack, a MIDI note will cause the loop will trigger from the beginning play as long as the triggering note is held down; i.e., until a NoteOff or a different triggering note is received. This type of action with SamplerStyle=Attack only makes sense when loops are triggered by MIDI.
  • Page 84 Similarly, if you press any additional function during the quantizing period, it does not switch back to the previous loop. The Echoplex assumes you want to elaborate on the B part. See also: LoopTrig, Velocity, NextLoop, SwitchQuant 4-46 Echoplex Digital Pro Plus User’s Manual...

  • Page 85: Source

    Source # Default: 36 Parameter Row: MIDI Determines the starting note number, or controller number, for MIDI control of Echoplex operations. Values: 0-99 The Source# parameter determines the base note or controller number from which all the other MIDI commands are referenced. All buttons and functions are assigned to notes or controllers based on this parameter value.

  • Page 86: Switchquant

    When NextLoop is pressed the Echoplex immediately switches to the next loop with no quantizing. For example, if you are currently on loop 2, pressing NextLoop will instantly put you in loop 3. 4-48 Echoplex Digital Pro Plus User’s Manual...
  • Page 87 SwitchQuant Continued ONFIRM WITCH UANT When NextLoop is pressed the Echoplex goes into the quantize period but then waits indefinitely with the current loop playing until a confirming action is made. During this waiting period you may continue to press NextLoop to select different loops without actually switching to them.
  • Page 88 During the quantize period the LoopTime Display changes to show the destination loop. It will be displayed as “L 1”, “L 2”, etc. This is the 4-50 Echoplex Digital Pro Plus User’s Manual...
  • Page 89 SwitchQuant Continued loop you will go to when the quantize period ends. If you continue pressing NextLoop during this time, you will see the destination increment. U T T O N S C T I V E U R I N G T H E U A N T I Z E E R I O D N e x t L o o p...
  • Page 90 To see this in action, take the following steps: 1. Set MoreLoops to 2 or more 2. Turn SwitchQuant On 3. Record something a few seconds long into Loop 1, then end recording. 4-52 Echoplex Digital Pro Plus User’s Manual...
  • Page 91 SwitchQuant Continued 4. Near the beginning of the loop, press NextLoop, then press Multiply. 5. When your current loop ends, you will be switched immediately into Loop 2, and you will be in Multiply mode. You won’t hear the transition as it will sound like your current loop continues to play.
  • Page 92 Overdub is on automatically upon entering the new loop, so new material can be immediately added while the copy occurs. 4-54 Echoplex Digital Pro Plus User’s Manual...
  • Page 93 SwitchQuant Continued If the destination loop has material in it already, pressing Overdub during the quantize period will turn Overdub on when you switch to the new loop. R e c o r d Pressing Record during the quantize period will cause the Echoplex to begin recording immediately as soon as it enters the next loop.
  • Page 94 5. In the middle of your current loop, press Overdub. 6. The Echoplex will show “ooo” to indicate it is quantizing the Overdub. 7. When the loop restarts, Overdub will come on. See also: NextLoop, Quantize, LoopCopy, AutoRecord 4-56 Echoplex Digital Pro Plus User’s Manual...

  • Page 95: Sync

    Sync Default: Out Parameter Row: Timing Synchronizes the Echoplex Digital Pro with another Echoplex Digital Pro, a MIDI sequencer, a pulse trigger device, or a sound source. Values: Off (OFF), Out, OutUserStart (OuS), In (OFF) No synchronization signals are received or sent. MIDI: MIDI clocks are sent out the MIDI Out port when a loop is recorded or a Tempo is preset.
  • Page 96 If you are also using MIDI Clock from another device, note that if a MIDI clock is received at the MIDI In Port, BrotherSync input is ignored See also: 8ths/Cycle, MIDI, The Synchronization Section, BrotherSync, BeatSync, ControlSource 4-58 Echoplex Digital Pro Plus User’s Manual...

  • Page 97: Threshold

    Threshold Default: 0 Parameter Row: Timing Tells the Echoplex to wait until you play before starting to record. Values: 0-8 When a non-zero value for the Threshold parameter is set, the Record function waits until a large enough audio signal appears at the Input jack before it actually starts recording.

  • Page 98: Velocity

    NoteOn messages: velocity 127 will play back a loop at full volume, while velocity 1 will play it back so quietly that it may be inaudible. See also: LoopTrig, LoopTriggering, SamplerStyle 4-60 Echoplex Digital Pro Plus User’s Manual...

  • Page 99: Volumecont

    VolumeCont Default: 7 Parameter Row: MIDI Determines which Continuous Controller will control the output level. Values: 1-99 Incoming MIDI Continuous Controller messages can be used to control the Loop output level of the Echoplex Digital Pro. Only messages that are on the MIDI channel specified by the Channel parameter will be recognized.
  • Page 100 4-62 Echoplex Digital Pro Plus User’s Manual...

  • Page 101: Chapter 5 Functions

    Functions Reference - Functions 5-1...

  • Page 102: Dump

    MIDI is never fast, unfortunately. Transmission time will be 10 to 15 times the length of the current loop. 5. You can cancel the dump at any time by pressing any button. 5-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 103 Dump Continued Example 4.8: Responding to a Sample Dump Request 1. Record a loop. 2. Connect a MIDI cable from the MIDI Out port on the Echoplex Digital Pro to the MIDI In port on your sequencer, and connect a second cable from the MIDI In port on the Echoplex Digital Pro to the MIDI Out port on your sampler.

  • Page 104: Feedback

    LoopTime Display so you can easily see where you are setting it. The value range is displayed as 0 - 127, with 0 being 0% and 127 being 100%. This value range corresponds to MIDI continuous controller values. 5-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 105 Feedback Continued E E D B A C K O N T R O L I S O N T I N U O U S Feedback is a continuously variable control. You can change it freely right in the middle of a loop, and you will hear that change in the levels on the next repetition.
  • Page 106 When it has changed to something you like, you set the Feedback up to maximum so the level does not reduce with each repeat anymore. 5-6 Echoplex Digital Pro Plus User’s Manual...
  • Page 107 Feedback Continued This technique gives a nice evolving effect to the loop, and is a very powerful and expressive tool. By actively controlling the feedback, you can control how quickly this evolution occurs. See Also: FeedBkCont, Feedback Knob, Feedback Jack, LoopTime Display, Record, Overdub, Undo Reference - Functions 5-7...

  • Page 108: Generalreset

    Recording can begin in Sync. The following example illustrates how to do a GeneralReset from the front panel. See Also: Reset, Record, Multiply, MIDI Command List, Global/Local MIDI Clock, TempoSelect 5-8 Echoplex Digital Pro Plus User’s Manual...

  • Page 109: Halfspeed

    HalfSpeed Immediate Action Play Mode Play back the loop a half normal speed. HalfSpeed switches the playback speed of the loop to half the normal speed, making it an octave lower and twice as long. HalfSpeed is an InsertMode option, making it available from the front panel on the Insert Button.

  • Page 110: Insert

    In contrast, if RoundMode=Off, then a section of silence (marked "A" in the figure) is inserted to fill out the time from the Insert press to the end of the insertion cycle. 5-10 Echoplex Digital Pro Plus User’s Manual...
  • Page 111 Insert Continued Cycle 1 Cycle 2 Cycle 3 Cycle 4 IGURE Basic operation of the Existing Loop Insert button. InsertMode=Insert or 1 cycle Rehearse Quantize=Off New Performance Button Actions Results when RoundMode=rnd Results when RoundMode=Off Time Example 4.10: The Effect of Quantization When Quantize=On, a press of the Insert button will cause insertion to start at the beginning of the next cycle.
  • Page 112 If you end an Insert operation by pressing Undo, the loop will be returned to its state before you pressed Insert. See the Undo heading in this chapter for more information. 5-12 Echoplex Digital Pro Plus User’s Manual...
  • Page 113 Insert Continued ECORD Ending an Insert operation with the Record button causes the insert to end immediately, without waiting for the end of the current insertion cycle. Since the loop can’t contain fractional cycles, the entire new loop will be considered a single cycle. This is called an Unrounded Insert. Figure 4.3 illustrates this behavior.
  • Page 114 This is accomplished by holding down Insert as you play the new material, instead of pressing and releasing it, as shown in Figure 4-4. The Replace will continue as long as you hold Insert down. 5-14 Echoplex Digital Pro Plus User’s Manual...
  • Page 115 Insert Continued Existing Loop IGURE Replacing with a long press of the Insert button. InsertMode=Insert. New Performance Button Actions Resulting Loop Time N S E R T O D E E H E A R S E When InsertMode=Rehearse, the behavior of the Insert button as a way to end recording changes.
  • Page 116 H.SP briefly. Press HalfSpeed again and the loop returns to FullSpeed. The LED turns green and F.SP is displayed for a moment. See HalfSpeed in the Functions section for more details. 5-16 Echoplex Digital Pro Plus User’s Manual...
  • Page 117 Insert Continued N S E R T O D E E V E R S E When InsertMode=Reverse, the Insert button performs the same function as the Reverse button on the front panel, but more conveniently. See Reverse in the Functions section for more details. N S E R T O D E U S T A I N...

  • Page 118: Load

    “MIDI” is lit, and then press the NextLoop (Load) button to wait for the dump. The display will show moving dashes to indicate a wait state, along with the numbers 00 that indicate that no bytes have been received. 5-18 Echoplex Digital Pro Plus User’s Manual...
  • Page 119 Load Continued 4. Start a dump on your sequencer or sampler. As the dump progresses, the numbers in the display on the Echoplex Digital Pro will change. 5. You can cancel the Load at any time by pressing any button. Example 4.12: Loading a Sample with Handshaking, Echoplex Initiates Handshaking allows the transmission to occur faster and more reliably.

  • Page 120: Loopdivide

    Or you can press Reverse and have it precisely aligned to the nearest quarter note, which feels almost immediate but keeps your loop in tempo as you switch in and out of Reverse. See also: Quantize, 8th/Cycle 5-20 Echoplex Digital Pro Plus User’s Manual...

  • Page 121: Looptriggering

    LoopTriggering Immediate MIDI Action Play Mode Switch to any loop using MIDI commands. When multiple loops are set up using the MoreLoops parameter, incoming MIDI NoteOn messages can trigger any loop’s playback. This function is called LoopTriggering. The LoopTrig parameter sets the value of the MIDI note number that will trigger Loop 1.

  • Page 122: Loopwindowing

    LoopWindowing can give a variety of interesting effects, depending on the size of the Window and how much material is in the memory to Window through. You can even resize the Window on the fly, to capture different sized chunks of memory! 5-22 Echoplex Digital Pro Plus User’s Manual...
  • Page 123 LoopWindowing Continued R E A T I N G T H E O O P I N D O W The LoopWindow is created by either Re-Multiplying a loop or doing an Unrounded Multiply. Both of these are standard techniques that are are quite useful in many cases.
  • Page 124 O O P I N D O W You can define new LoopWindow sizes at any time by doing more Re- Multiplies or Unrounded Multiplies, and then move the new LoopWindow over the loop. 5-24 Echoplex Digital Pro Plus User’s Manual...
  • Page 125 LoopWindowing Continued Once you have a LoopWindow defined, you can do any other loop function on it that you like. For example, you can Overdub new material onto it. Pressing Undo after that will first remove the new overdubs, and then begin jumping backwards through memory of the larger loop. See also: Undo, Multiply Reference - Functions 5-25...

  • Page 126: Multiincrease

    If you like, you can tap them in very quickly right from the beginning. Or, if you have had Multiply going for a while, using MultiIncrease simply adds to the number of multiples you already have. 5-26 Echoplex Digital Pro Plus User’s Manual...
  • Page 127 MultiIncrease Continued If you are tapping the Cycles in quickly, it is helpful to remember that the first tap of Multiply is just starting the Multiply. The second tap is where you start counting the total number of Cycles you will get. This can throw you off when you count the Multiply taps quickly, because you need to tap one extra time than the number of Cycles you want.

  • Page 128: Multiply

    (measured from the first press of Multiply) is recorded. In contrast, if RoundMode is Off, then the overdubbing of the new performance stops immediately, although it still rounds off so the entire copy of the original cycle is included in the loop. 5-28 Echoplex Digital Pro Plus User’s Manual...
  • Page 129 Multiply Continued Cycle 1 Cycle 2 Cycle 3 Cycle 4 IGURE Existing Loop Basic operation of the Multiply button. Quantize=Off 1 cycle 1 cycle 1 cycle New Performance Button Actions Results when RoundMode=rnd Results when RoundMode=Off Time U A N T I Z E D U L T I P L I C A T I O N When Quantize=On, a press of the Multiply button will cause multiplication to start at the beginning of the next cycle.
  • Page 130 9 cycles, since 1 second is used to store the existing loop. It is useful to pay attention to this so you know how far you can go with Multiply. 5-30 Echoplex Digital Pro Plus User’s Manual...
  • Page 131 Multiply Continued L T E R N A T E N D I N G S The simplest way to end a Multiply operation is to press the Multiply button a second time. You’ll get the results illustrated in the examples above.
  • Page 132 Multiply, except that the audible sound will shut off as soon as the Multiply ends. Once you’re in Mute mode, you can restart the sound with the Mute button or with the Alternate Endings listed for the Mute entry later in this chapter. 5-32 Echoplex Digital Pro Plus User’s Manual...
  • Page 133 Multiply Continued If you end a Multiply operation by pressing Undo, the loop will be returned to its state before you pressed Multiply. EVERSE Ending a multiplication with Reverse is exactly like ending it with Multiply, except that you immediately toggle Overdub mode after the Multiply rounds off.
  • Page 134 Cycle 2 New Loop Time Example 4.14: Adding Cycles Here’s an example that shows how to use Multiply to change a 2-cycle loop to a 3-cycle loop. Follow along in Figure 4.9 . 5-34 Echoplex Digital Pro Plus User’s Manual...
  • Page 135 Multiply Continued 1. Record a single tap or note into a short loop to provide a pulse. Make it slow enough so that you can carry out the following steps without the need for practice. 2. Set Quantize=On. 3. Press Multiply right after you hear a pulse. Count "One-Two" together with the pulses, and hit Multiply again immediately after the word "Two."...
  • Page 136 The Reverse starts it Rounding with the Reverse command armed, and the Record executes it immediately and redefines the new loop at that length. This Rounding action also applies for using Insert. 5-36 Echoplex Digital Pro Plus User’s Manual...
  • Page 137 Multiply Continued O N G R E S S Pressing and holding down the Multiply button has the same effect as a pair of press-and-releases, regardless of the state of Quantize. E S E T T I N G O O P S When the number of loops (the value of MoreLoops ) is more than one, the Multiply button can be used to reset all the loops at once.

  • Page 138: Mute

    5-38 Echoplex Digital Pro Plus User’s Manual...
  • Page 139 Mute Continued M u t e M o d e = C o n t i n u o u s When the MuteMode=Continuous, the loop continues counting even when it is silenced by pressing Mute. Then, when you press Mute a second time to allow audio output again, the loop will become audible wherever it happens to be at that time.
  • Page 140 During this operation, the loop will continue running even when silenced, regardless of the setting of MuteMode —releasing the button will not start the loop at the beginning, except by coincidence. See Also: MuteMode 5-40 Echoplex Digital Pro Plus User’s Manual...

  • Page 141: Nextloop

    NextLoop Immediate Action Play Mode Moves to the next loop. NextLoop is primarily used when multiple loops are set up with the MoreLoops parameter. Pressing NextLoop will switch you to the next loop. The setting of SwitchQuant will affect when this happens—see the discussion of SwitchQuant for a detailed explanation.
  • Page 142 NextLoop Continued See also: MoreLoops, SwitchQuant, AutoRecord, LoopTrig, LoopCopy, SamplerStyle 5-42 Echoplex Digital Pro Plus User’s Manual...

  • Page 143: Overdub

    Overdub Immediate Action Play Mode Lets you add layers of sound. Overdub is the basic magic wand of the Echoplex Digital Pro. It allows you to add layer after layer of sound to any existing loop. As you play, the level of the sound in the existing loop is subtly lowered to prevent a gradual accumulation of signal that would overload the system.
  • Page 144 Pressing and holding down the Overdub button for longer than half a second has the same effect as a pair of short press-and-releases . In other words, overdubbing will start when you press and hold the button and end when you release it. 5-44 Echoplex Digital Pro Plus User’s Manual...
  • Page 145 Overdub Continued Overdub can be held on in a sustain fashion with a long press while simultaneously pressing other buttons to execute other functions. This is true whether Overdub is activated from the front panel buttons, from the foot pedal, or with a momentary switch in the Overdub Jack. For example, you can keep Overdub long-pressed and then press Reverse simultaneously to go in and out of Reverse while Overdubbing.

  • Page 146: Previousloop

    SUSNextLoop, you have a convenient way to go forward and backwards through your loops. PreviousLoop is only available through MIDI, and is located at Source#+20. See Also: NextLoop, MoreLoops, MIDI Command List, SUSNextLoop, Receiving MIDI Commands. 5-46 Echoplex Digital Pro Plus User’s Manual...

  • Page 147: Record

    Record Immediate Action Play Mode Records a new cycle. This is where it all starts. This button lets you record your first layer in a loop or erase (reset) the current loop. You press it once to start recording, and press it a second time to end recording and start looping. A step-by-step example is given in the Quick Start.
  • Page 148 VERDUB Ending a recording with the Overdub button ends the recording immediately and toggles Overdub mode. It’s the equivalent of ending the Record by pressing Record a second time, and then pressing 5-48 Echoplex Digital Pro Plus User’s Manual...
  • Page 149 Record Continued Overdub immediately. If Overdub was on before the Record this action will turn it off. If Overdub was off it will now be on. If you have the MoreLoops parameter set greater than one, ending a recording with NextLoop immediately ends the recording and puts you immediately into the next loop.
  • Page 150 When a non-zero value for the Threshold parameter is set, the Record function waits until a large enough audio signal appears at the Input jack before it actually starts recording. When Threshold=0, this waiting is disabled and Recording begins immediately. 5-50 Echoplex Digital Pro Plus User’s Manual...
  • Page 151 Record Continued Y N C H R O N I Z E D E C O R D I N G When a sync signal is being received by the Echoplex, and Sync=In, the Echoplex will Record loops in sync with the external device’s tempo. Sync signals can be in the form of MIDI Clock, BrotherSync from another Echoplex, or pulses at the BeatSync input.
  • Page 152 This is useful to let you start recording immediately without waiting for an entire sync period to occur. See Also: RecordMode, Overflow, Threshold, Sync, SyncRecord, Quantize, Reset 5-52 Echoplex Digital Pro Plus User’s Manual...

  • Page 153: Rehearse

    Rehearse Immediate Action Play Mode Rehearse a part before committing it to the loop. When InsertMode=Rehearse, pressing Insert at the end of a recording puts you in Rehearse mode. To use Rehearse, begin by tapping the Record button to start recording a loop.

  • Page 154: Replace

    Record, the Record ends as if you’d pressed the Record button and the Replace function immediately begins. IGURE Existing Loop Replacing with the Insert button. InsertMode=Replace. New Performance Button Actions Resulting Loop Time 5-54 Echoplex Digital Pro Plus User’s Manual...

  • Page 155: Reset

    Reset Immediate Action Play Mode Resets the Current Loop. To Reset the current loop, press and hold down the Record button for about half a second. Reset erases the contents of the current loop. This is also called a Long-Press Record. The loop will then be in the Reset State, and ready for a new recording.

  • Page 156: Retrigger

    Undo to retrigger a loop, but without silence from having to mute first. This is only available when you have one loop set up in MoreLoops, since the NextLoop button obviously changes loops otherwise. 5-56 Echoplex Digital Pro Plus User’s Manual...
  • Page 157 Retrigger Continued MIDI R ETRIGGER OMMAND The Retrigger command can be executed directly from MIDI. The Retrigger DirectMIDI command is located at Source# + 37. So if you have Source#=36 and ControlSource=Notes , the Retrigger command will be at MIDI Note# 73. MIDI SUS M ETRIGGER Another way to execute Retrigger with MIDI is the SUS Mute-Retrigger...

  • Page 158: Reverse

    Reverse button.The NoteOn message presses the button, and the NoteOff message releases the button. If you do a short-press tap 5-58 Echoplex Digital Pro Plus User’s Manual...
  • Page 159 Reverse Continued of the ReverseButton, you go into Reverse, and then into Forward when you tap it again. If you do a long-press of the ReverseButton, it will become SUS action and stay in Reverse as long as you hold the button, and then go back to Forward when you release it.
  • Page 160 Reverse happened. This means any overdubs you do while Reversing can be Undone. However, it is not possible to Undo past a Reverse, since memory really does get used in 5-60 Echoplex Digital Pro Plus User’s Manual...
  • Page 161 Reverse Continued the other direction and overdubs made prior to Reverse get destroyed by overdubs made after the Reverse. Record-Undo is also possible in Reverse. So if you press Record by mistake while in Reverse, pressing Undo returns you to where you were. As a consequence, starting Record does not automatically force you to be Forward, but leaves the loop in Reverse.

  • Page 162: Sampleplay

    SamplerStyle=One , the loops will be triggered in SamplePlay. When the NoteOn message corresponding to a loop is received, the loop will trigger from its StartPoint, play once, and go to Mute. Repeatedly 5-62 Echoplex Digital Pro Plus User’s Manual...
  • Page 163 SamplePlay Continued playing the same note will retrigger the loop. The LoopTrig parameter determines which NoteOn messages correspond to a given loop. MIDI S AMPLE OMMAND The DirectMIDI command SamplePlay will trigger the current loop and play it once, exactly as if you had pressed Mute-Insert. The MIDI location for SamplePlay is Source# + 36 .

  • Page 164: Startpoint

    Quantized activities occur on multiples of cycles, counted from the logical starting point. It’s easier to relate to the display if the logical starting point makes musical sense. See also: Quantize, Mute, MuteMode 5-64 Echoplex Digital Pro Plus User’s Manual...

  • Page 165: Substitute

    Substitute Immediate Action Play Mode Replaces a section of the current loop, beginning in the next repetition. When InsertMode=Sub , the Insert button becomes the Substitute button. Substitute has some similarity to the Replace function. With Replace the original loop playback is cut while the replace is done. So while you are playing something new to replace what was there, you don’t hear the old loop.
  • Page 166 Substitute. If you have Quantize on you will not have this problem, since the long press can happen completely during the ooo waiting phase. When the Cycle point comes Substitute is started directly. 5-66 Echoplex Digital Pro Plus User’s Manual...
  • Page 167 Substitute Continued U B S T I T U T E F O R E H E A R S I N G Substitute can be used in similar fashion to the Rehearse function. As long as Substitute is active, all playing is repeated once. This can be useful to find the groove to start a loop.
  • Page 168 Pedal as it is otherwise. See the section on the Loop/Delay parameter for more details on the InterfaceModes . See also: Replace, Insert, Multiply, Rehearse, InsertMode, Loop/Delay 5-68 Echoplex Digital Pro Plus User’s Manual...

  • Page 169: Sus Commands

    SUS Commands Immediate Action Play Mode Changes Multiply and Insert into Real-Time Granular Loop commands. One of the values on the InsertMode parameter is called SUS. This is short for Sustain. InsertMode=Sustain changes the way in which the Insert and Multiply buttons work.
  • Page 170 With Quantize = 8th a short press of Multiply will change the loop length to one Cycle divided by the value of 8th/Cycle. See also: Multiply, Insert, RecordMode, OverdubMode, Quantize, SUS MIDI Commands, MIDI Command List 5-70 Echoplex Digital Pro Plus User’s Manual...

  • Page 171: Susnextloop

    SUSNextLoop Sustain Action Play Mode Jump to the Next Loop and back. SUSNextLoop is an interesting special case of the SUS MIDI Commands described in the MIDI section. SUSNextLoop is only available as a MIDI command, and is located at Source# + 20 . With SUSNextLoop, pressing it puts you into the Next Loop and releasing it returns you to the previous loop.

  • Page 172: Undo

    Undo will take away one layer of Feedback reduction, so your loop fades back up to the original. If you combine this with Overdub you can get very creative results, where you 5-72 Echoplex Digital Pro Plus User’s Manual...
  • Page 173 Undo Continued evolve your loop in one direction with Overdub and Feedback, Undo it back a ways, and then evolve it in a different direction. Operation of Undo depends on memory availability. The Echoplex monitors this for you. When Undo is possible, you will see the Undo LED is green.
  • Page 174 40-80 of memory with a complete loop, the result of the Overdub. The Echoplex then alters its playback loop so that the new recording is heard, even though the original recording also resides in memory. 5-74 Echoplex Digital Pro Plus User’s Manual...
  • Page 175 Undo Continued 1 loop 4.11 IGURE 40 seconds Basic operation of Overdub when memory is Existing Loop ample. New Performance Button Actions Audible Results Empty Memory After Overdub Playback loop If, instead of completing the Overdub normally, you press the Undo button to terminate it, the Echoplex simply resets the playback loop to play back the first 40 seconds and marks the memory area that it was using for the Overdub as available for the next operation.
  • Page 176 20 seconds of the Overdub followed by the final 20 seconds of the original loop. It’s an interesting effect, but it may not be what you were shooting for. 5-76 Echoplex Digital Pro Plus User’s Manual...
  • Page 177 Undo Continued U n d o i n g M u l t i p l e L a y e r s When you leave Overdub on for a long time, recording moves to a new area of memory each time you pass the loop’s start point. If your loop is short compared to the amount of memory available, then a number of Overdub cycles can pass before overwriting of memory starts to occur.
  • Page 178 All of this occurs behind the scenes, and is certainly not necessary to understand in order to use the Echoplex. It is presented here for those who wish to understand a bit more about how it all works. See also: Record, Overdub, Feedback 5-78 Echoplex Digital Pro Plus User’s Manual...

  • Page 179: Chapter 6 Synchronization

    Synchronization Reference - Synchronization 6-1...

  • Page 180: Autostartpoint

    Then when you bring FeedBack up again the StartPoint of the Loop and the external sequencer will be very close together and syncing resumes easily. See also: StartPoint, Global/Local MIDI Clock 6-2 Echoplex Digital Pro Plus User’s Manual...

  • Page 181: Beatsync

    BeatSync Synchronization Back Panel Accepts and transmits a pulse that can synchronize to external devices or trigger loop playback. Good for producing stuttering effects. The BeatSync jack accepts a 1/4" mono phone plug. When Sync=Out , a pulse that is the equivalent of a switch closure will be sent out this jack at the start of every cycle.
  • Page 182 7. Press Record again to stop recording. The display will show "ooo," and recording will continue until the next tap (or audio pulse) comes. Example 4.x: Synchronizing an External Device to the Echoplex with Pulse Triggers 6-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 183 BeatSync Continued 1. Many older devices can us a pulse trigger for synchronizing, triggering, or other interesting effects. If you have one, try connecting the BeatSync jack of your Echoplex to its trigger input so the Echoplex can control it. 2.
  • Page 184 BeatSync Continued 7. This can also be done with guitars, bass, drum machines, audio outputs of metronomes, etc. Any audio source that can give a sufficient pulse will work. See also: BrotherSync, Sync 6-6 Echoplex Digital Pro Plus User’s Manual...

  • Page 185: Brothersync

    BrotherSync Synchronization Back Panel Synchronizes multiple Echoplexes at the sample level, while allowing any one of them to define the basic cycle length for the group. Especially useful for stereo recording, multi-track looping, and jamming with multiple Echoplex users. The BrotherSync jack accepts a 1/4" stereo (TRS) phone plug. BrotherSync provides the tightest possible synchronization among multiple Echoplexes.
  • Page 186 It can also sync to audio pulses, like a kick drum. It is not intended for synchronizing to other Echoplexes and only operates in one direction at a time. See also: BeatSync 6-8 Echoplex Digital Pro Plus User’s Manual...

  • Page 187: Global/Local Midi Clock

    Global/Local MIDI Clock Synchronization Clock mechanism that allows synchronization magic in the Echoplex. The Echoplex uses a Global/Local MIDIclock system that allows the slaved unit to lock up with an external sequencer without drifting, even if the loop start point on the Echoplex is moved by one of the following de- aligning functions: StartPoint Sample Triggering...
  • Page 188 From the front panel the cross-function Mute-Multiply offers some of those functions, depending on the Sync parameter and Sync events coming in to the Echoplex. See Also: ReAlign, MuteReAlign, QuantMIDIStartSong, StartPoint, Retrigger, SamplePlay, NextLoop 6-10 Echoplex Digital Pro Plus User’s Manual...

  • Page 189: Midi Sync Indicators

    MIDI Sync Indicators Synchronization Play Mode MIDI output indicators help you track key synchronization points. The MIDI Sync Indicators are MIDI notes are transmitted out at various synchronization points related to the current loop. These are shown at the top of the MIDI Command List in the MIDI section. MIDI notes are sent to indicate each Loop StartPoint, Global MIDI StartPoint, Cycle StartPoint, and 8th Note.

  • Page 190: Mutequantmidistartsong

    Sync parameter setting. This allows you to always have a way to send a StartSong message in sync with the loop StartPoint, even if the Echoplex is not the clock master. See Also: ReAlign, MuteReAlign, QuantMIDIStartSong, Source#, StartPoint 6-12 Echoplex Digital Pro Plus User’s Manual...

  • Page 191: Quantmidistartsong

    QuantMIDIStartSong Synchronization Send a StartSong at the next Loop StartPoint QuantMIDIStartSong is a MIDI command for “Send a MIDI StartSong at next loop StartPoint.” This is a DirectMIDI command only. The MIDI location for QuantMIDIStartSong is Source# + 40. When QuantMIDIStartSong is executed, the Echoplex sends a MIDI StartSong message at the next StartPoint of the loop.

  • Page 192: Quantstartpoint

    The QuantStartPoint function is also available as a DirectMIDI command. The MIDI location for QuantStartPoint is Source# + 43. See Also: ReAlign, Global/Local MIDI Clock, Source#, StartPoint 6-14 Echoplex Digital Pro Plus User’s Manual...

  • Page 193: Realign

    ReAlign Synchronization Play Mode Puts your loop back in alignment with an external device. L I G N U N C T I O N ReAlign allows the loop to be aligned again with an external loop or sequencer that it was in sync with, after it has been brought out of alignment by the use of functions like Reverse, Triggering, HalfSpeed, SamplePlay, etc.
  • Page 194 If no MIDI clock is present and a MIDI StartSong is received, followed by MIDI clock, the loop triggers immediately from the start and continues playing in sync. Local StartPoint No reaction to Local StartPoint 6-16 Echoplex Digital Pro Plus User’s Manual...
  • Page 195 ReAlign Continued M u t e - M u l t i p l y w i t h S y n c = O u t : Sync Event Function Description BeatSync No response to BeatSync. BrotherSync MuteReAlign The loop is triggered out of Mute to play from the start and continue playing.
  • Page 196 StartPoint. The display will show “St.S.” When it reaches the StartPoint a MIDI StartSong message is sent out the MIDI port to start up the sequencer and the Loop comes out of Mute. 6-18 Echoplex Digital Pro Plus User’s Manual...
  • Page 197 ReAlign Continued This is similarly useful for when the Echoplex is the clock master and we need to restart the sequencer. In this case, both the loop and the sequencer can be muted and brought back on together. MuteQuantMIDIStartSong works the same as the Mute-Multiply combination from the front panel when Sync is set to OuS, but provides a more direct access since it only requires a single command instead of the two button combination.
  • Page 198 BrotherSync coming in from the other Echoplex. Then they will both have their StartPoints in the same spot and be sending BrotherSync pulses at the same time, so there will not be any confusion for the third unit. Of 6-20 Echoplex Digital Pro Plus User’s Manual...
  • Page 199 ReAlign Continued course this means ReAlign can no longer be used on the second machine to put it back in the original alignment with the first. See also: Mute, Global/Local MIDI Clock, Sync, BrotherSync, BeatSync, StartPoint Reference - Synchronization 6-21...

  • Page 200: Songpositionpointer And Continue

    When the next Global StartPoint occurs, the Echoplex will automatically trigger the loop at the beginning so that it is back in sync with the sequencer. See also: ReAlign, Global/Local MIDI Clock, Sync, StartPoint, StartSong, StopSong, and Continue 6-22 Echoplex Digital Pro Plus User’s Manual...

  • Page 201: Startsong, Stopsong, Continue

    StartSong, StopSong, Continue Synchronization The Echoplex can send and receive MIDI StartSong, StopSong, and Continue messages in various ways. MIDI includes three important messages for controlling synchronized devices. These are called StartSong, StopSong, and Continue and are part of the “System Real Time” commands in MIDI. These commands are commonly used with devices like sequencers, drum machines, recording equipment and software, arpeggiators, and loopers.
  • Page 202 MIDI Out Port by the MIDIpipe function. MIDI clock, StartSong, StopSong and Continue messages are neither sent or received. They are piped through from the MIDI In Port to the MIDI Out Port by the MIDIpipe function. 6-24 Echoplex Digital Pro Plus User’s Manual...
  • Page 203 StartSong, StopSong, Continue Continued The exception is for one situation where we send StopSong in both Sync=Out and Sync=OuS cases: When the MIDI Clock is stopped at Reset we send a StopSong. This avoids the case of the sequencer or drum machine waking up in the middle of a pattern when the MIDI Clock happens to get restarted again.
  • Page 204 Mute-Multiply ReAlign StopSong is sent at: Reset GeneralReset Start Record StartSong is sent at: Undo in Reset QuantMIDIStartSong (only at next loop start) MuteQuantMIDIStartSong (only at next loop start) StopSong is sent at: never 6-26 Echoplex Digital Pro Plus User’s Manual...
  • Page 205 StartSong, StopSong, Continue Continued O M M A N D I N G A T A R T O N G W H E N Y N C StartSong can be sent in Reset with a press of Undo. This can be useful if you have another source of sync upstream of the Echoplex, but have stopped something downstream from it.

  • Page 206: Stopsync

    StopSync also disables Tempo, so if you have used TempoSelect to set a Tempo you can temporarily escape from it and then return to it later. See also: Sync, TempoSelect 6-28 Echoplex Digital Pro Plus User’s Manual...

  • Page 207: Syncstartpoint

    SyncStartPoint Synchronization Play Mode Define a new Global StartPoint and send a StartSong. Pressing Undo in Reset when Sync=In defines a new Global StartPoint for Sync just like switching on a MIDI clock or sending a MIDI StartSong to the Echoplex does.

  • Page 208: Syncrecord

    Record, counts the Cycles on the green multiple display, and rounds off at the end to fit the loop time defined by the sync. SyncRecord gives you freedom from quantization so you can begin recording anytime you 6-30 Echoplex Digital Pro Plus User’s Manual...
  • Page 209 SyncRecord Continued like, while still allowing tight synchronization to an external clock source. With SyncRecord, you only need to have received the first sync event to begin Recording in sync. As you are Recording, the Echoplex will continue watching the sync to determine what the right cycle times are. When you press Record again to end, the Echoplex will automatically round off to the right point so that your loop is exactly the correct length to match the sync.

  • Page 210: Temposelect

    TempoSelect requires that the Sync Parameter be set to Out or OuS . When you have Sync=Out or OuS , the Undo LED will be green in reset to indicate the TempoSelect function is available. 6-32 Echoplex Digital Pro Plus User’s Manual...
  • Page 211 TempoSelect Continued To select the Tempo, first press the Undo button in Reset. This will put you into the TempoSelect State. From there you will see the display change and you will have several different commands available from the front panel. E M P O E L E C T I S P L AY...
  • Page 212 Since the MIDI clock is being sent out during this time, any device following the clock will be slowly changing in tempo as it follows the fine tuning. A long press of Undo clears the Tempo and exits from Tempo Select. 6-34 Echoplex Digital Pro Plus User’s Manual...
  • Page 213 TempoSelect Continued I F F E R E N C E S E T W E E N Y N C A N D Y N C TempoSelect behaves slightly differently depending on whether the Sync parameter is set to Out or OuS. With Sync=Out , MIDI StartSong messages are sent when you start Recording or when you Set the tempo with Undo.
  • Page 214 2. Start up the Sequencer as you begin Recording your Loop The second option for starting the sequencer is to trigger it immediately as you start Recording. You can do this by pressing Record directly 6-36 Echoplex Digital Pro Plus User’s Manual...
  • Page 215 TempoSelect Continued when the Undo LED is still red, right after you have dialed in the tempo. A MIDI StartSong message is sent, and the sequencer will start at the same instant as you start recording your loop. In this case the press of Record is the SetTempo moment.
  • Page 216 If there is no tempo saved in the current preset, it defaults to 120 BPM. From then on, as soon as the Feedback Knob is moved, the new value is activated. See also: Sync, SyncRecord, 8ths/cycle, Presets 6-38 Echoplex Digital Pro Plus User’s Manual...

  • Page 217: Chapter 7 Midi Control

    MIDI Control Reference - MIDI Control 7-1...

  • Page 218: Directmidi

    DirectMIDI commands. These use the NoteOn message to start their function and the NoteOff message to end it, similar to the way SUS commands work from the front panel. See also: MIDI In, MIDI Out, Channel, ControlSource, Source#, MIDI VirtualButtons 7-2 Echoplex Digital Pro Plus User’s Manual...

  • Page 219: Midi Command List

    MIDI Command List Immediate Action Play Mode Complete list of MIDI Commands available for controlling the Echoplex through MIDI. In the tables below, the Offset is the number that should be added to Source# to get the listed command. For example, the midi command for the Record button is an offset of 2.

  • Page 220: Midi Command List

    Sustain Action Rounded Insert SUSMute Sustain Action Mute ShortUndo Immediately execute the ShortUndo function (Undo to end) SUSNextLoop Sustain Action NextLoop (NoteOn = NextLoop, NoteOff = PreviousLoop) SUSReplace Sustain Action Replace SUSSubstitute Sustain Action Substitute 7-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 221 MIDI Command List Continued SUSToggleReverse Sustain Action Reverse SUSToggleSpeed Sustain Action HalfSpeed Reset Immediately reset current loop GeneralReset Immediately reset all loops Exit Parameters Exit Parameter editing and return to Play state SUSUnroundedMultiply Sustain Action Unrounded Multiply SUSUnroundedInsert Sustain Action Unrounded Insert SUSMute-Retrigger Sustain Action Mute-Retrigger (NoteOn = Mute, NoteOff=Retrig.) LongUndo...
  • Page 222 Echoplex. There are 15 Preset locations available, corresponding to MIDI Program Change 1 - 15. See also: MIDI In, MIDI Out, Channel, ControlSource, Source#, MIDI VirtualButtons, DirectMIDI, MIDI Sync Indicators, Transmitting MIDI, Receiving MIDI, LoopTriggering, LoopTrig, Presets 7-6 Echoplex Digital Pro Plus User’s Manual...

  • Page 223: Midi Datawheel

    MIDI DataWheel Immediate Action Parameter Editing Mode MIDI DataWheel can be used for editing parameters. The Feedback Knob value is transmitted by the MIDI continuous controller DataWheel (Continuous Controller #6) when in Parameter Editing Mode and TempoSelect. Likewise, the Echoplex receives the DataWheel control for changing the parameter values from MIDI.

  • Page 224: Midipipe

    MIDI StartSong, StopSong, and Continue messages are piped in all cases, so an upstream MIDI controller at the beginning of the MIDI chain can send commands to a downstream sequencer that is receiving 7-8 Echoplex Digital Pro Plus User’s Manual...
  • Page 225 MIDIpipe Continued clock from the Echoplex. When the Echoplex is piping StartSong, StopSong, and Continue messages it intelligently checks whether it has already sent the message itself within the last 10ms, and does not pipe if it has. This prevents multiple Echoplexes in parallel from stacking up the StartSong messages when they are all Recording simultaneously.

  • Page 226: Midi Virtualbuttons

    See the Source# section in the Parameters chapter for the command list and specific note or controllers needed for each VirtualButton. See also: MIDI In, MIDI Out, Channel, ControlSource, Source#, DirectMIDI 7-10 Echoplex Digital Pro Plus User’s Manual...

  • Page 227: Receiving Midi Commands

    Receiving MIDI Commands Immediate Action Play Mode Use a MIDI controller to command the Echoplex. Receiving MIDI commands is similar to transmitting. There are two primary types of MIDI commands, VirtualButtons and DirectMIDI. They are described in more detail in the under their own headings in this section.

  • Page 228: Sysex

    Port to the MIDI Out Port. Make certain you have set the Echoplex device ID to something. If the Device ID is left at 0, SysEx will not be received. See also: SysEx Chapter, MIDI Pipe 7-12 Echoplex Digital Pro Plus User’s Manual...

  • Page 229: Sus Midi Commands

    SUS MIDI Commands Immediate Action Play Mode MIDI Commands that execute functions with Sustain Pedal action. The concept of Sustain action, or “SUS” commands available for the front panel buttons is greatly expanded through DirectMIDI. Every Play Mode function has a SUS version separately available through MIDI, allowing each to be accessed at any time through a MIDI controller using NoteOn and NoteOff messages.
  • Page 230 Note that only sending the NoteOff component of SUSNextLoop gives you the command PreviousLoop. See also: MIDI Command List, DirectMIDI, MIDI VirtualButtons, SUS Commands, SUSNextLoop, PreviousLoop 7-14 Echoplex Digital Pro Plus User’s Manual...

  • Page 231: Transmitting Midi Commands

    Transmitting MIDI Commands Immediate Action Play Mode MIDI Commands are transmitted with each button press. When ControlSource is set to Notes, each press of an Echoplex button will send that button’s specific NoteOn message out the MIDI Out Port. The NoteOn message is sent when the button is pressed, and the corresponding NoteOff message is sent when the button is released.
  • Page 232 7-16 Echoplex Digital Pro Plus User’s Manual...

  • Page 233: Chapter 8 Parameter Presets

    Parameter Presets Reference - Parameter Presets 8-1...
  • Page 234 MIDI SysEx Note that When InsertMode=HalfSpeed, HalfSpeed takes precedence over the Preset control on the Insert button while in Reset. So only the Mute button is available for changing Presets in that case. 8-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 235 Parameter Presets Continued A R A M E T E R S S AV E D I N R E S E T S Some Parameters are considered Global and are not stored in Presets. Those will be noted shortly. The following Parameters are saved in Presets: Loop/Delay Quantize...
  • Page 236 If you changed the Preset while playing and you really did want the MoreLoops to change and have everything Reset, you will need to Reset the current loop and then reload that Preset. 8-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 237 Parameter Presets Continued N D E R S T A N D I N G T H E L AY I N G T A T E “ P ” R E S E T Preset 0 is the Preset used and edited while playing. These are the Parameters active while you use the Echoplex.
  • Page 238 Presets work, we save them from that mistake. In any case, there is no point in loading Presets if you haven’t saved any, so we don’t clutter the interface with it. 8-6 Echoplex Digital Pro Plus User’s Manual...
  • Page 239 Parameter Presets Continued M I D I E L E C T I N G R E S E T S W I T H R O G R A M H A N G E Selecting presets with MIDI is very straight forward. MIDI Program Change messages 1 –...

  • Page 240: Preset Editor

    Sets selected Preset and Preset 0 to factory default Multiply long press saves the playing state settings (Preset 0) to Overdub the Preset displayed Record loads the Preset displayed to the playing state setting (Preset 0) for use. 8-8 Echoplex Digital Pro Plus User’s Manual...
  • Page 241 Preset Editor Continued R E S E T D I T O R I S P L AY The Display shows the Preset number as “Pr #”. No dot after “Pr” indicates that this Preset is the last one that has been loaded into the Playing state Preset 0.
  • Page 242 8-10 Echoplex Digital Pro Plus User’s Manual...

  • Page 243: Chapter 9 User Interface

    User Interface Reference - User Interface 9-1...

  • Page 244: Datawheel

    Note this only works from the actual Feedback Knob on the front panel. A pedal connected to the Feedback Pedal Jack does not have this function. DataWheel works with: 8th/Cycle MIDI channel Source # LoopTrig # VolumeCont FeedBkCont MoreLoops 9-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 245 DataWheel Continued V O I D I N G O N F L I C T S W I T H E E D B A C K Since the DataWheel is the Feedback Knob in Play Mode, the Echoplex makes some effort to avoid conflicts between Feedback settings and DataWheel settings.

  • Page 246: Feedbk Indicator

    When this light is dark, it is measuring very little (or no) signal. When it is green, the signal is healthy. Orange indicators are fine too, with the signal at a good level. Levels that cause the indicator lights to glow red will cause distortion. 9-4 Echoplex Digital Pro Plus User’s Manual...

  • Page 247: Feedback Pedal Jack

    Feedback Pedal Jack Back Panel Plug a volume pedal into this jack to control feedback levels with your foot. This jack lets you use a passive volume pedal (one with no power supply or battery) to control the Feedback parameter. Use a standard guitar cord to connect a volume control’s "Amplifier"...

  • Page 248: Feedback Knob

    Feedback to 0, for instance, the current loop will play out to its end before you hear the volume drop to 0. Setting the Feedback to an intermediate level is a good way to create a smooth fadeout. See also: Feedback 9-6 Echoplex Digital Pro Plus User’s Manual...

  • Page 249: Footpedal Jack

    Footpedal Jack Back Panel A place to plug in a cord to connect to the EFC-7 footpedal. Use a standard guitar cord, with 1/4" mono phone plugs on each end, to connect this jack to the optional EFC-7 footpedal. You can also attach an ordinary momentary footswitch to this jack, and it will function just like the Record button.

  • Page 250: Input Indicator

    Input Indicator red. Set the Input Level Knob so that the loudest levels cause the Input Indicator Light to turn orange, but never red. See also: Quick Start, Input Knob, Input Jack 9-8 Echoplex Digital Pro Plus User’s Manual...

  • Page 251: Input Jack

    Input Jack Back Panel Plug in your instrument, mixer send, or microphone. This back-panel jack accepts 1/4” phone plugs carrying the audio signal to be recorded or delayed. It is a high-impedance input designed to accept a wide range of audio levels, including high-impedance microphone outputs, signals from electric guitars and basses (with either passive or active electronics), and line-level signals from electronic instruments and mixers.

  • Page 252: Input Knob

    Input Knob Front Panel Controls the master input volume level. Set this so that the loudest levels cause the Input Indicator Light to turn orange, but never red. See also: Input Indicator Light 9-10 Echoplex Digital Pro Plus User’s Manual...

  • Page 253: Loop Display

    Loop Display Front Panel Indicates the current Loop. The Loop Display shows the current Loop selected. This is mainly meaningful when more than one loop has been set up using the MoreLoops parameter. The Echoplex can have its memory divided into as many as 16 different loops.

  • Page 254: Loops Led

    The Loops Row consists of the Parameters related to multiple loops. These are MoreLoops, AutoRecord, LoopCopy, SwitchQuant, LoopTrig, Velocity, and SamplerStyle. The Loops LED is not used in Play Mode. See also: Parameter Button, Multiple Display, Parameter Matrix 9-12 Echoplex Digital Pro Plus User’s Manual...

  • Page 255: Looptime Display

    LoopTime Display Front Panel Displays length of the current loop. Alternately shows other information depending on context. T A N D A R D O O P I M E I S P L AY When you are in a Record, Multiply, or Insert operation, the LoopTime Display will keep track of how much time you’ve recorded so far.
  • Page 256 StartPoint sent cS.P QuantStartPoint Pr.E Preset Editor Preset Change received Load Preset Save Preset Revert Preset to default These become especially useful with the DirectMIDI commands that can directly access many of these functions. 9-14 Echoplex Digital Pro Plus User’s Manual...
  • Page 257 LoopTime Display Continued EMORY ISPLAY The size of the memory is only shown for a short time after startup and after GeneralReset. To see it again, just do a Short-Press Multiply in Reset and it will appear briefly on the LoopTime Display. ARAMETER DITING ISPLAY...
  • Page 258 It displays it as “P n ”, where n is the preset number. See the Preset section for more details. See also: Record, Multiply, Insert, Sync, Feedback, FeedBkCont, VolumeCont, Parameter Button, Quantize, SwitchQuantize, NextLoop, Presets 9-16 Echoplex Digital Pro Plus User’s Manual...

  • Page 259: Midi Led

    MIDI LED Front Panel Indicates the MIDI Row of the Parameter Matrix is selected; Indicates Loop StartPoint during Play Mode. A R A M E T E R D I T I N G O D E The MIDI LED is illuminated when the MIDI Row of the Parameter Matrix has been selected for editing with the Parameter Button.

  • Page 260: Midi Ports

    Each of these actions generates a new MIDI message, which is transmitted out the MIDI Out port of the slave. See Chapter 3 for a summary of the many MIDI functions of the Echoplex Digital Pro. 9-18 Echoplex Digital Pro Plus User’s Manual...

  • Page 261: Mix Knob

    Mix Knob Front Panel Controls the mix between the input and the loop. This controls the mix between the input signal and the loop. If you are using the Echoplex Digital Pro in an effects loop, then you will probably want to set this so that the input and loop are evenly balanced, or so that the input is a little louder than the loop (this will facilitate soloing over the loop).

  • Page 262: Multiple Display

    In the Parameter Editing Mode, the Multiple Display shows the current row selected in the Parameter Matrix. In the Preset Editor, the Multiple Display shows the current Preset being edited. See also: Multiply, Insert, Parameter Button, Presets. 9-20 Echoplex Digital Pro Plus User’s Manual...

  • Page 263: Output Jack

    Output Jack Back Panel Audio output. Connect it to your amplifier or preamp. This line-level output jack accepts standard 1/4” mono phone plugs. The output is a mix of the input and the current loop, with relative volumes determined by the position of the Mix knob, and overall volume determined by the Output knob.

  • Page 264: Output Knob

    Output Knob Front Panel Controls the overall output volume. 9-22 Echoplex Digital Pro Plus User’s Manual...

  • Page 265: Overdub Jack

    Overdub Jack Back Panel A normally-open footswitch plugged into this jack can trigger Overdub operations. This jack is provided for those who want to use their own footswitches to control Overdub operations. Some may prefer piano-style pedals to the Overdub button on the supplied footpedal. Reference - User Interface 9-23...

  • Page 266: Parameter Button

    Play Mode, which is convenient for when you are not looking directly at the Echoplex. Your new Parameter setting will be saved, even if you turn off the power. 9-24 Echoplex Digital Pro Plus User’s Manual...
  • Page 267 Parameter Button Continued M I D I R E S S I N G A R A M E T E R W I T H The Parameter Button can be virtually pressed with a MIDI command. The MIDI VirtualButton command for the Parameter Button is located at Source# + 0 .

  • Page 268: Smartbuttons

    Echoplex will start Record. OUBLE LICK ULTIPLY If you have a loop playing and you double-click the NoteOn trigger for the current loop, you will do a Multiply. 9-26 Echoplex Digital Pro Plus User’s Manual...
  • Page 269 SmartButtons Continued OUBLE LICK ECORD AND ULTIPLY If Record or Multiply is running and you press the same NoteOn message again, we end the Record or Multiply and do nothing else. In this way you can start Recording or Multiplying by double- clicking the NoteOn for the loop, and then end it with another press of the same NoteOn message.

  • Page 270: Switches Led

    During Play Mode the Switches LED is part of the Visual Tempo Guide. It blinks at each Cycle StartPoint. This is helpful for you to get a visual indication of the tempo of your loop. See also: Parameter Button, Multiple Display, Parameter Matrix, Visual Tempo Guide 9-28 Echoplex Digital Pro Plus User’s Manual...

  • Page 271: Timing Led

    Timing LED Front Panel Indicates the Timing Row of the Parameter Matrix is selected; Indicates 8th notes during Play Mode. A R A M E T E R D I T I N G O D E The Timing LED is illuminated when the Timing Row of the Parameter Matrix has been selected for editing with the Parameter Button.

  • Page 272: Visual Tempo Guide

    Sync came late, the Echoplex jumps a little. faint: This means the external sequencer was a little slow. AutoUndo executed (loop was not changed in last pass) Loop Display Dot 9-30 Echoplex Digital Pro Plus User’s Manual...
  • Page 273 Visual Tempo Guide Continued The following figure shows the location of each Visual Tempo Guide LED. Flashes to indicate Number of the Current Cycle Time display Loop StartPoint current loop (from Multiply or Insert) Flashes to indicate Cycle StartPoint Loops MIDI •...
  • Page 274 Echoplex. By watching the frequency and intensity of this LED you can quickly speed or slow the tempo of the sequencer to match the loop in the Echoplex, at which point the dot stops blinking. This technique 9-32 Echoplex Digital Pro Plus User’s Manual...
  • Page 275 Visual Tempo Guide Continued allows you to start a loop without the sequencer, then start the sequencer and tune its tempo to match. Reference - User Interface 9-33...
  • Page 276 9-34 Echoplex Digital Pro Plus User’s Manual...

  • Page 277: Chapter 10 Midi Sample Dump

    MIDI Sample Dump Reference - MIDI Sample Dump 10-1...

  • Page 278: Introduction

    The minimal MIDI patch is to connect the MIDI Out Port of the sending unit to the MIDI In Port of the receiving unit. MIDI In MIDI Out MIDI In MIDI Out Unit A (sender) Unit B (receiver) Figure x.1: MIDI Dump open loop connection 10-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 279 Introduction MIDI Sample Dump Continued Unit A sends a header first, containing general information about the sample to be sent. Then it divides the sound data into packets and sends one packet at a time. Unit A (sender) Unit B (receiver) Dump Header Data #1 Data #2...
  • Page 280 Unit A (sender) Unit B (receiver) Dump Header Data #1 Data #2 NAK! Data #2 Data #8265 Figure x.5: MIDI Dump closed loop allows packet checking 10-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 281 Introduction MIDI Sample Dump Continued W h o s t a r t s s e n d i n g ? The previous section showed the case where the sample dump was initiated from the sending unit A. This is not always possible or easy. Some samplers don’t even have a sample dump button or menu command.
  • Page 282 127, all device IDs are accepted. If you set the sending unit to 127, all receiving units should therefore accept your SYSEX data. This is called broadcasting. See the following sections for information on how device IDs are used in the Echoplex. 10-6 Echoplex Digital Pro Plus User’s Manual...
  • Page 283 Introduction MIDI Sample Dump Continued C H O P L E X A M P L E U M P C o n n e c t i o n s The Echoplex allows you to transfer the sound data through open loop connections (one cable) and closed loop connections (two cables).
  • Page 284 The device ID of the Echoplex can be changed while in Upload-mode. Press Multiply to see the device ID. Press it again to start incrementing the value. The longer you press, the faster the value will be incremented. Broadcasting (device id=127) is implemented. 10-8 Echoplex Digital Pro Plus User’s Manual...

  • Page 285: Sample Dump User Guide

    Sample Dump User Guide MIDI Sample Dump E N D I N G A U M P U M P U T T O N The Dump button in the MIDI (P3) parameters of the Echoplex is used to send a dump to another device. You see a 'd' blinking, indicating that data is dumped.
  • Page 286 Id is shown in the green display. VERDUB Changes current sample number. The default is the current loop number. Range from 0 to 999. Sn is shown in the green display NSERT Reserved. Reserved. 10-10 Echoplex Digital Pro Plus User’s Manual...
  • Page 287 Sample Dump User Guide MIDI Sample Dump Continued Send the current loop. The receiving unit will store it as the current sample number. PLOAD Request a dump from the other unit. The current sample number will be sent by the other unit and stored in the current loop. This works only in a closed loop (2 MIDI cables).
  • Page 288 Wait until the entire loop is sent (A shows 'P3' again) (B shows '-' again) Press Parameters on B to exit Upload-Mode (B shows 'P3' again) Echoplex B has now uploaded the loop. 10-12 Echoplex Digital Pro Plus User’s Manual...
  • Page 289 Sample Dump User Guide MIDI Sample Dump Continued A => E CHOPLEX CHOPLEX CLOSED LOOP INITIATES Set MIDI ControlSource to “Off” to avoid MIDI loops Connect MIDI-Out of Echoplex A with MIDI-In of Echoplex B. Connect MIDI-Out of Echoplex B with MIDI-In of Echoplex A. Press Parameters on both units, until they are both in the MIDI parameter mode.
  • Page 290 Here are a few estimates for the open loop (no acknowledges): Sample Length Transmission Time 0.1 sec 50 sec 1.0 sec 8 min 20 sec 10.0 sec 1 hour 24 min 100.0 sec 13 hours 54 min 10-14 Echoplex Digital Pro Plus User’s Manual...
  • Page 291 Sample Dump User Guide MIDI Sample Dump Continued And here the closed loop (with acknowledges): Sample Length Transmission Time 0.1 sec 5.5 sec 1.0 sec 55 sec 10.0 sec 9 min 10 sec 100.0 sec 1 hour 32 min Reference - MIDI Sample Dump 10-15...

  • Page 292: Other Device Implementations

    Select another MIDI parameter "Source #" for one of them, so they send on another octave. ® O U N D E S I G N E R SoundDesigner subtracts 2 from the device ID number. 10-16 Echoplex Digital Pro Plus User’s Manual...
  • Page 293 Other Device Implementations MIDI Sample Dump Continued -> E OUND ESIGNER CHOPLEX SoundDesigner and the Echoplex do not agree on how to calculate the checksum. The Echoplex sends a NAK (=Not Acknowledge) after every data-package. Luckily SoundDesigner ignores all handshake messages and the Echoplex stores it anyway so you will end up with the correct sample in your Echoplex.
  • Page 294 Select the right sample number and send a Request (Undo-button). You can also start the dump from the K2000™. The function is well hidden in the sample editor. Press <Dump>. The Echoplex will ignore 10-18 Echoplex Digital Pro Plus User’s Manual...
  • Page 295 Other Device Implementations MIDI Sample Dump Continued the sample number you send and store it in the loop number you defined in the Echoplex Upload-mode (Record-button). E - M U 6 4 ™ The device ID of the E-MU™ is set to 127 and cannot be changed. It therefore will always accept all samples, independent of your Device ID.

  • Page 296: Sample Dump Trouble Shooting

    (e.g. notes, ignored) nothing received D i s p l a y f o r s e n t m e s s a g e s data sent (dump data packet) 10-20 Echoplex Digital Pro Plus User’s Manual...

  • Page 297: Sample Dump Trouble Shooting

    Sample Dump Trouble Shooting MIDI Sample Dump Continued dump request sent Cancel sent Header sent E r r o r v a l u e s In case of an error (display 'E') the red display shows an error number. These mean the following: overrun (data was sent too fast) buffer overflow (too much data too fast)
  • Page 298 10-22 Echoplex Digital Pro Plus User’s Manual...

  • Page 299: Chapter 11 Midi Sysex

    MIDI SysEx Reference - MIDI SysEx 11-1...

  • Page 300: Midi Sysex Detailed Reference

    The format of the data bytes of the following commands depends on this version number. 3) COMMANDS ----------- 3.1) COMMANDS VERSION 1 ----------------------- Overview: 00 01 30 0B dev vers cmd {data} F7 11-2 Echoplex Digital Pro Plus User’s Manual...
  • Page 301 MIDI SysEx Detailed Reference MIDI SysEx Continued INFO_REQUEST 00 01 30 0B dev vers 0 240 00 01 48 11 dev vers 0 247 INFO_DATA 00 01 30 0B dev vers 1 vers (mem_1 mem_2 mem_3) 240 00 01 48 11 dev vers 1 vers (mem_1 mem_2 mem_3) 247 GLOBAL_PARAM_REQUEST 00 01 30 0B dev vers 10 from length pset 240 00 01 48 11 dev vers 16 from length pset 247...
  • Page 302 The global parameters are accessed by indexes. The indexes in version 1 are: VGPrmPrevParamSet VGPrmParamSet VGPrmMIDIChannel VGPrmMIDIReceiveCommand VGPrmMIDIFirstKey VGPrmMIDIVolCtrlr VGPrmMIDIFBCtrlr VGPrmMIDIFirstLoop VGPrmMIDIDevID VGPrmMIDISampleNumHi VGPrmMIDISampleNumLo The local parameters are accessed by indexes. The indexes in version 1 are: 11-4 Echoplex Digital Pro Plus User’s Manual...
  • Page 303 MIDI SysEx Detailed Reference MIDI SysEx Continued Loop/Delay (4 bits) Timing Quantize (2 bits) 8th/Cycle (7 bit) SyncMode (3 bit) TrigThreshold (4 bits) RecordMode (2 bit) OverdubMode (1 bit) RoundMode (1 bit) InsertMode (4 bits) MuteMode (1 bit) Overflow (1 bit) MoreLoops (4 bits) (real NLoops-1)
  • Page 304 0-8 RecordMode (2 bits): Toggle Sustain Safe OverdubMode (1 bit): Toggle Sustain RoundMode (1 bit): Round InsertMode (4 bits): InsertOnly Rehearse Replace Substitute Reverse Half Speed h.SP Sustain MuteMode (1 bit): Continuous Start 11-6 Echoplex Digital Pro Plus User’s Manual...
  • Page 305 MIDI SysEx Detailed Reference MIDI SysEx Continued Overflow (1 bit): Play Stop MoreLoops (4 bits): number of loops number of loops ..number of loops AutoRecord (1 bit): Next LoopCopy (2 bits): Timing Sound SwitchQuant (3 bits): Confirm CycleQuantize ConfirmCycle...
  • Page 306 | value | param value(s) |_______|______|_____________________________________________ If there are less values than defined by 'from' and 'length', then these parameters will be reset to their default value. 3.1.2.3) COMMAND: LOCAL_PARAM_REQUEST = $12 = 18 11-8 Echoplex Digital Pro Plus User’s Manual...
  • Page 307 MIDI SysEx Detailed Reference MIDI SysEx Continued ---------------------------------------------------- Reads a range of local param values and returns them as a LOCAL_PARAM_DATA command. 00 01 30 0B dev vers 12 from length pset F7 240 00 01 48 11 dev vers 18 from length pset 247 _____________________________________________________________ |byte# | bits | description...
  • Page 308 The checksum calculation is the same as in the MIDI Sample Dump. All bytes AFTER the SYSEX (=$F0) are XORed. This checksum is then transmitted as the last data byte before SYSEXEND (=$F7). 5) COMMUNICATION EXAMPLES ------------------------- 11-10 Echoplex Digital Pro Plus User’s Manual...
  • Page 309 MIDI SysEx Detailed Reference MIDI SysEx Continued UNIT A (version 1) UNIT B (version 2) InfoRequest( version 1) --------> <-------- Info( version 2) // in format vers 1 LocalData( version 1, 4, 4) --------> // stores l_param[4] LocalData( version 1, 4, 127) -------->...
  • Page 310 11-12 Echoplex Digital Pro Plus User’s Manual...

Table of Contents
