DVD Stereo System

Operating Instructions

SC-VK61D
Model No.
AUDIO / VIDEO
GC GS GCS EE
Region number supported by
this player
Region numbers are allocated to DVD players and
software according to where they are sold.
For the Middle East, South Africa,
Saudi Arabia and Kuwait
The region number of this player is "2".
The player will play DVD-Video marked
with labels containing "2" or "ALL".
Example:
2
For Southeast Asia
The region number of this player is "3".
The player will play DVD-Video marked
with labels containing "3" or "ALL".
Example:
For Russia and Ukraine
The region number of this player is "5".
The player will play DVD-Video marked
with labels containing "5" or "ALL".
Example:
5
Before connecting, operating or adjusting this
product, please read these instructions completely.
Please keep this manual for future reference.
RQT7705-3L
2
3
5
2
3
5
2
3
5
