- Page 1 DMP-300 Digital Media Player Users Guide Version: V1.8 Date: 10 Oct 2009 Doc Number: DMP020 AVIONICS INNOVATIONS, INC. 2450 Montecito Road Ramona, CA 92065 Phone (760) 788-2602 Fax (760) 789-7098 www.avionicsinnovations.com...
- Page 2 Added “Disable Chime” option in Cardprep V1.6 14-Feb-05 Strengthened warning re other brands of CF - Added CardPrep support for importing playlists V1.7 20-Oct-06 - Updated all screen shots V1.8 10-Oct-09 Added DMP-300 Model Name DMP-300 USERS GUIDE PAGE 2 OF 24 P/N DMP020 V1.8...
- Page 3 Remote PAUSE/PLAY Button..............9 Jog Mode: Track Select and Volume Control With External Switches ..10 Track Select....................10 Volume Control...................11 Creating MP3 Files ...................11 Preparing a Memory Card with CardPrep............12 Installing DMP-300 CardPrep..............12 DMP-300 USERS GUIDE PAGE 3 OF 24 P/N DMP020 V1.8...
-
Page 4: Table Of Contents
To Copy all Files and Settings to the Card: ..........21 To Save or Open a Card File..............22 To Import a DMP-100 Card File ..............22 Notes on GPS Triggering................22 Notes on Interrupting and Restoring Audio Tracks ........23 DMP-300 USERS GUIDE PAGE 4 OF 24 P/N DMP020 V1.8... -
Page 5: Speech Files
The DMP-300 Digital Media Player is a self-contained unit which stores and replays pre- recorded audio tracks. The audio tracks are encoded in “Motion Picture Expert Group (MPEG) Level 3” format, commonly referred to as “MP3”. Audio files are stored in a removable CompactFlash™... - Page 6 When a speech file is selected, it will be played once in each language currently enabled on the DMP-300. Language selections may be changed from the front panel at any time by selecting CHOOSE LANGUAGES (this option is not available unless the card contains speech tracks in more than one language.) The selected languages are retained when the...
- Page 7 CardPrep, the language selection will be whatever was in effect when the unit was last turned off. The DMP-300 uses only a single rotary knob with a push-button action for all front panel functions. Rotate the knob fully CCW until “CHOOSE LANGUAGES” is displayed.
- Page 8 The display indicates that playback is in progress. This display can either be elapsed playback time, or can be cycling user prompts. Please see the DMP-300 Installation Manual for more information. When playback is complete, the audio stops and the display points to the NEXT speech file, as if the knob had been turned CW once.
- Page 9 The DMP-300 can receive position data from a variety of panel-mount GPS receivers via an RS-232 or RS-422 serial data link. If a GPS is connected to the DMP-300, then either speech or music may be triggered automatically when the aircraft is within a specified distance of a certain latitude and longitude (lat/lon).
- Page 10 “Jog Mode” causes the Trigger 6 and Trigger 7 inputs to be used instead to step forward or back through the DMP-300 menus and lists. When Jog Mode is enabled in CardPrep, it is active whenever the resulting memory card is used. Inserting a card which does not have Jog Mode enabled will cause Triggers 6 and 7 to function as normal remote trigger inputs.
- Page 11 When Jog Mode is enabled on a card, Triggers 1 and 2 are also redefined to control the volume on the DMP-300. Each activation of Trigger 1 simulates a push-and-turn counterclockwise, i.e. a decrement of volume. In a similar way, each activation of Trigger 2 simulates an increment of volume.
-
Page 12: Running Cardprep
The DMP-300 CardPrep software may be distributed on either the CompactFlash™ card included with the DMP-300, on a CD-ROM or downloaded from the Avionics Innovations website at www.avionicsinnovations.com. To install the software, simply run SETUP.EXE and follow the prompts. CardPrep displays a simple menu bar across the top, and five different selection tabs. -
Page 13: To Add Music Files
4. Click on the up and down arrows next to each box to move a highlighted selection within the box. This allows you to control the order in which speech tracks or languages are displayed on the DMP-300. Music files may be added either individually, like speech files, or in groups. You can add all the MP3 files in a particular folder, or you can add MP3 files contained in a playlist. -
Page 14: Adding A Folder Of Music Files
Add Folder to be a convenient way to include an entire CD onto the DMP300 memory card. Simply Browse to the root folder of your music library (C:\My Documents\My Music\iTunes\iTunes Music, for example) and navigate to the folder containing the entire DMP-300 USERS GUIDE PAGE 14 OF 24 P/N DMP020 V1.8... -
Page 15: Adding An Exported Playlist Of Music Files
“.txt” so the playlists can be read by CardPrep. (In iTunes, right-click the playlist, select “Export Song List…”, and change the “Save as type:” box to “Text files”.) DMP-300 USERS GUIDE PAGE 15 OF 24 P/N DMP020 V1.8... -
Page 16: To Select Triggers Or Attributes
For example, an aerial tour may desire speech tracks to be played at each point of interest on the outbound flight, but not on the return flight. These waypoints would be DMP-300 USERS GUIDE PAGE 16 OF 24 P/N DMP020 V1.8... -
Page 17: Endless Looping
The actual volume level of the LOUD setting is selected in Setup Mode. Please refer to the “DMP-300 Installation Guide”, AI document number DMP010, for information on entering Setup Mode and changing this setting. Note that the internal chime sound is always played at the LOUD volume level. -
Page 18: To Select Setup Items
Custom Card Titles ♦ Up to two lines of 16 characters each can be displayed on the DMP-300 after the initial screen on power up. This can be used to identify the card, to greet the operator, to provide special instructions, etc. -
Page 19: Selecting Internal Or External Chime
Changing System Prompts ♦ Most of the text displayed by the DMP-300 in normal operation is actually stored on the memory card and can be changed via CardPrep. This was intended to allow for translation of the system prompts into languages other than English. - Page 20 As with all the other configuration settings in this section, any changes made here will only apply to this card. Inserting a different card will cause the unit to reload the configuration and clear the changes. DMP-300 USERS GUIDE PAGE 20 OF 24 P/N DMP020 V1.8...
-
Page 21: To Copy All Files And Settings To The Card
DO NOT USE THIS if you have added or deleted any audio tracks – the resulting card will cause unpredictable behavior. CardPrep will check the version of the embedded DMP-300 firmware contained on your card. If the CardPrep installation contains a newer version, click on Update Firmware only to update the card. -
Page 22: To Save Or Open A Card File
Click on File in the menu bar at the top of the window, and then Import… to select the DMP-100 card file. All the audio tracks, triggers and other settings will be brought into DMP-300 CardPrep. Click on File and then Save As… to save the information as a DMP-300 card file. -
Page 23: Notes On Interrupting And Restoring Audio Tracks
If a new audio track is selected (either manually or via any trigger) while another track is playing, the DMP-300 can resume playing the interrupted track after the new one finishes. This will only occur, however, for the most recently interrupted track. Any previously interrupted tracks will not resume, and must be manually restarted if desired. - Page 24 Mix will then choose a random music track, which will start at its beginning. The final situation is that after all triggered audio tracks are completed; the DMP-300 will always be playing some kind of music. In many applications, this is exactly the desired effect.
