Deltronic Security CN-1231 Owner's Manual

9v dc carbon monoxide (co) alarm with alarm relay ouput with relay base
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

9V DC CARBON MONOXIDE (CO) ALARM
WITH ALARM RELAY OUPUT
CAUTION : READ THESE INSTRUCTIONS CAREFULLY BEFORE OP-
ERATING OR SERVICING. PLEASE LEAVE A COPY TO THE END USER.
IMPORTANT !
THIS IS NOT A SMOKE ALARM! This CO alarm is designed to detect car-
bon monoxide from ANY source of combustion. It is NOT designed to detect
smoke, fire, or any other gas.
WARNING ! This product is intended for use in ordinary indoor locations of
family living units. Do not expose to rain or moisture. The detector will not
protect against risk of carbon monoxide poisoning when the battery is flat.
Do cover the alarm when decorating. REMEMBER to uncover the unit when
decoration is finished (excessive fumes from paints, solvents, cleaning agents,
etc. may damage or deteriorate sensor). The CO alarm shall not be seen as a
substitute for proper servicing of fuel-burning appliances, or the sweeping of
chimneys.
WARNING ! THIS ALARM CONFORMES TO BSEN50291:2001 MAY
NOT PROTECT INDIVIDUALS FROM THE ACUTE EFFECTS OF CAR-
BON MONOXIDE EXPOSURE. IT WILL NOT FULLY SAFEGUARD INDI-
VIDUALS WITH SPECIFIC MEDICAL CONDITIONS. IF IN ANY DOUBT,
CONSULT A MEDICAL PRACTITIONER.
© Copyright 2008 Deltronic Security AB
CN-1231 with Relay Base
OWNER'S MANUAL
CARBON
MONOXIDE
ALARM
Alarm Fault Power

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CN-1231 and is the answer not in the manual?

Questions and answers

Summary of Contents for Deltronic Security CN-1231

  • Page 1 WARNING ! THIS ALARM CONFORMES TO BSEN50291:2001 MAY NOT PROTECT INDIVIDUALS FROM THE ACUTE EFFECTS OF CAR- BON MONOXIDE EXPOSURE. IT WILL NOT FULLY SAFEGUARD INDI- VIDUALS WITH SPECIFIC MEDICAL CONDITIONS. IF IN ANY DOUBT, CONSULT A MEDICAL PRACTITIONER. © Copyright 2008 Deltronic Security AB...
  • Page 2 NEVER IGNORE THE CO ALARM CO is called the “silent killer” because it is an invisible, odorless, tasteless gas produced when fossil fuels do not burn completely, or are exposed to heat (usu- ally fire). These fuels include: Wood, coal, charcoal, oil, natural gas, gasoline, kerosene, and propane.

  • Page 3: Installation

    INSTALLATION: CAUTION: DO NOT INSTALL THE ALARM IN NEW OR RENOVATED BUILDINGS UNTIL ALL WORK IS COMPLETED, INCLUDING PAINT- ING AND FINAL CLEANING (EXCESSIVE FUMES FROM PAINTS; SOL- VENTS, MAY CAUSE DAMAGE AND DIRT OR DEBRIS MAY BLOCK THE GAS ENTRY). The CO Alarm is designed for easy installation.
  • Page 4 each separate sleeping area. • If more than one sleeping area or the bedroom doors are closed during the night, you may need more than one CO alarm • For added protection, install at least one CO alarm in each level of the home and at the top of the basement stairs.

  • Page 5: Additional Features

    OPERATING AND TESTING CO ALARM When the battery is installed, Green LED will flash once indicating the alarm is powered and wait for about 1 minute to stabilize the sensor before testing the unit. To test the unit, press and hold the button until the repeating series of 4 beeps sound with Red LED flashes.
  • Page 6 Relay output – The relay wich the CO alarm is mounted on is equipped with a latching relay output for connection with external equipment (N.O. and/or N.C.). Interlink function - This alarm can be interlinked with up to 11 other alarms (12 in all) using the interlink terminal located next to the relay terminal on the relay base.

  • Page 7: Technical Information

    Call the Fire department immediately outside your home or premises/apartment. Do a head count to check all persons are accounted for. Do not re-enter the premises nor move away from the open door/windows until the emergency service responders have arrived, the premises have been aired out, and your alarm remain in its normal condition.
  • Page 8 ALARM SIGNAL & LED INDICATION Note : ■■■ represents “beep, beep, beep” Green Yellow Detector Alarmsignal Operation Power indication Alarm signal Fault signal Flash once per Normal Operation minute ¤ ■■■■ -1s -■■■■ Alarm Condition 4 beeps + flash ¤ -1s -■■■■...

  • Page 9: Maintenance

    MAINTENANCE • Do not allow water or dust to contaminate the alarm. • Test it at least once a week by using the test button. • A vacuum cleaner hoes and vacuuming the openings on the alarm. • Use a damp cloth to wipe the outside of the alarm.
