LED-HC 50
TABLE OF CONTENTS
LED HANDY CON 50
1. Safety Instructions
2. Technical Specifications
3. Function
4. Installation
5. DMX512 Address setting
6. How to control the fixture
7. DMX 512 Connection
8. Troubleshooting
9. Fixture Cleaning
LED-HC50
User Manual
Please read the instructions carefully before use
1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED-HC50 and is the answer not in the manual?

Questions and answers

Summary of Contents for VISIO LED-HC50

  • Page 1 LED HANDY CON 50 1. Safety Instructions 2. Technical Specifications 3. Function 4. Installation 5. DMX512 Address setting 6. How to control the fixture 7. DMX 512 Connection 8. Troubleshooting 9. Fixture Cleaning LED-HC50 User Manual Please read the instructions carefully before use...

  • Page 2: Safety Introductions

    LED-HC 50 LED-HC 50 1. Safety Introductions 2.Technical Specifications A compact LED controller for all kinds of DC 24V passive RGB Fixtures. Come with switch power supply inside Built-in programs under Master/Slave mode triggered by music. Please read the instructions carefully which includes 4 different ways of DMX addressing important information about the installation, operation and WARNING...

  • Page 3: Installation

    LED-HC 50 LED-HC 50 4. Installation When you set the address by DMX controller and dip-switch at the same time, the order of the DMX controller will be invalid. 1. Ensure that mains power supply is off before installing or wiring the LED fixture 2.

  • Page 4: How To Control The Fixture

    LED-HC 50 LED-HC 50 C. Remote DMX address setting by CA-T DMX TESTER 6. How to control the fixture The fixture can be set the DMX address remotely by CA-T DMX TESTER. Please There are three ways to control the fixture refer to the CA-T user manual to set the DMX address to the fixture.

  • Page 5: Dmx512 Connection

    LED-HC 50 LED-HC 50 7. DMX512 Connection The DMX 512 is widely used in intelligent lighting control, with a maximum of 512 channels. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable.

  • Page 6: Troubleshooting

    LED-HC 50 LED-HC 50 8. Troubleshooting 9. Fixture Cleaning Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: The cleaning of internal must be carried out periodically. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or A.

  • Page 7: Ec Declaration Of Conformity

    LED-HC 50 EC Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002;...
