Avalon RF AX610CP User Manual

2.35ghz-2.5ghz 10dbi rhcp

AX610CP

2.35GHz-2.5GHz 10dbi RHCP

Antenna

User's Manual

AV030522/1-000

REV. A - 27 May 2003

Prepared by Steve Jones

Edited by Eli Weinstein

http://www.avalonrf.com/

Avalon RF, Inc. • 344 Coogan Way • El Cajon, CA 92020

Phone: (619) 401-1969 • Fax: (619) 401-1971 • Email:

sales@avalonrf.com

Table of Contents

Need help?

Do you have a question about the AX610CP and is the answer not in the manual?

Page 1 User’s Manual AV030522/1-000 REV. A - 27 May 2003 Prepared by Steve Jones Edited by Eli Weinstein http://www.avalonrf.com/ Avalon RF, Inc. • 344 Coogan Way • El Cajon, CA 92020 Phone: (619) 401-1969 • Fax: (619) 401-1971 • Email: sales@avalonrf.com...
Page 2: Specifications
AVALON RF, INC. Page 1 AX610CP User’s Manual General. The AX610CP is a 2.4GHz right hand circular polarized antenna with a gain of 10dbi for demanding indoor or outdoor applications. Specifications Electrical Gain: 10dbi Horizontal radiation pattern See Figure A below...
Page 3 Page 2 AX610CP User’s Manual Mechanical a) Size 4.63” x 3.91” x 0.88” (see Figure C) 118mm x 99mm x 22mm b) Weight <6 oz. <150 gram c) Shipping weight <16 oz. <456 gram Figure C – AX610CP Mechanical Drawings...
Page 4: Environmental Conditions
AVALON RF, INC. Page 3 AX610CP User’s Manual Environmental Conditions. The AX610CP Series is designed to meet the following environmental conditions: 2.3.1 Operating temperature -2° to 122° F -55° to 85° C 2.3.2 Storage temperature -13° to 150° F -55° to 90° C 2.3.3 Vibration...
Page 5: Ordering Information
AVALON RF, INC. Page 4 AX610CP User’s Manual Ordering Information. AX610CP 2.35GHz-2.5GHz RHCP antenna Standard Accessories None Optional features Option LH - LHCP...
