Kingwin KWI-S2 User Manual

Usb 2.0 to dual sata adapter w/ one touch back up

Advertisement

Quick Links

USB 2.0 to Dual SATA
Adapter

User Manual

w/ One Touch Back Up
www.kingwin.com
KWI-S2

Advertisement

loading
Need help?

Need help?

Do you have a question about the KWI-S2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kingwin KWI-S2

  • Page 1: User Manual

    USB 2.0 to Dual SATA Adapter User Manual w/ One Touch Back Up www.kingwin.com KWI-S2...
  • Page 2 Connect to Dual 2.5” or 3.5” SATA Hard Drive to USB 2.0  Support SATA types of drives.  SATA II & USB 2.0 compatible. Installation:  2.5” or 3.5” SATA Hard Drive Plug USB 2.0 cable into KWI-S2 Connect KWI-S2 into 2.5” or 3.5” SATA Hard Drive...
  • Page 3 2. Carefully take the HDD out from KWI-S2 The HDD can reach temperatures over 50ºC. It will not burn the fingers but should be handled with care. 3. Kingwin is not responsible for any data loss or hard drive damage in the process of using the KWI-S2.
  • Page 4 HDD Formatting Guide • You may format your external HDD through USB 2.0 connection. • Please make sure your external HDD is turned on and well connected to the PC before formatting the HDD. 1. Right-click “My Computer” icon and select the ”Manage” column. 2.
  • Page 5 3. Right-click on the “Unallocated” block and selects “New Partition”. 4. The “New Partition Wizard” will appear. Please follow the instruction of the wizard to complete.
  • Page 6 5. When new partition is completed, the external HDD will be recognized as a “New Volume”.
  • Page 7 6. Double-click “My Computer”. You will see the new volume appears on your PC. How To Backup Files with PCClone First connect a hard drive to the KWI-S2 device. Refer to the manual included on how to connect your hard drive.
  • Page 8 3. Select the folders and files you would like to back up. 4. Now press the “OTB” button twice or click on the backup icon to start the backup process.
  • Page 9 5. Once the backup process has finished your files will be safely stored on the hard drive connected. Please note that the files are saved on the hard drive in a folder named Fnet. This folder is hidden and to see it you must change your folder options to show hidden files. How to Restore Your Files with PCClone Select the Folders and files you want to be restored.
  • Page 10 1. Click on the restore icon and then click ok. 2. Once the restore has finished your files will be copied to its original location.
