Amer SD8n User Manual

8-port nway 10/100mbps fast ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SD8n
8-Port NWay 10/100Mbps Fast Ethernet Switch
User's Guide
Version 1.0
P/N: ATSD8-9904 Rev.A
This User's Guide contains important information regarding the
installation of your 10/100Mbps Switch. Please read it completely
before attempting to install your Network switch.
For future reference, record the serial number
of your network switch in the space below:
SERIAL Number
The serial number is located on the bottom of the switch.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD8n and is the answer not in the manual?

Questions and answers

Related Manuals for Amer SD8n

Summary of Contents for Amer SD8n

  • Page 1 SD8n 8-Port NWay 10/100Mbps Fast Ethernet Switch User’s Guide Version 1.0 P/N: ATSD8-9904 Rev.A This User's Guide contains important information regarding the installation of your 10/100Mbps Switch. Please read it completely before attempting to install your Network switch. For future reference, record the serial number...
  • Page 2 Amer.com 7259 Bryan Dairy Road, Largo, FL 33777. © Amer.com, 1999. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from Amer.com, as stipulated by the United States Copyright Act of 1976.

  • Page 3: Limited Lifetime Warranty

    Power Supplies, AC Adapters & Fans, after the 1 year a cost for replacement is applied to all products requiring such parts. Amer.com is not responsible for any type of data loss on hard drive or other storage devices.
  • Page 4 Warranty Service can be obtained during the warranty period by shipping, freight prepaid, or delivering the product to Amer.com in either the original package or a similar package providing an equal degree of protection. Amer.com will perform the required service and return the unit to the user (freight prepaid), if applicable, via the same mode (i.e.

  • Page 5: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated commercial environment.

  • Page 6: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE ............III ................URPOSE ..............ERMS SAGE ’ ........VERVIEW OF THIS UIDE INTRODUCTION ..............1 ..........1 THERNET ECHNOLOGY ............. 2 WITCHING ECHNOLOGY ................4 EATURES UNPACKING AND SETUP ..........6 ................7 NPACKING ..................
  • Page 7 A. Using straight cable............. 15 B. Using crossover cable..........15 ) ......... 15 WITCH TO WITCH OTHER DEVICES A. Using straight cable............. 16 B. Using crossover cable..........16 & D ..........16 PEED UPLEX TECHNICAL SPECIFICATIONS ........19 RJ-45 PIN SPECIFICATION ..........21...

  • Page 8: About This Guide

    100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible desktop package. Purpose This manual discusses how to install your SD8n Fast Ethernet 8-port 10/100M NWay Switch. Terms/Usage In this guide, the term “Switch” (first letter upper case) refers to your SD8n Fast Ethernet 8-port 10/100M NWay Switch, and ”switch”...

  • Page 9: Overview Of This User's Guide

    Overview of this User’s Guide Chapter 1, Introduction. Describes the Switch and its features. Chapter 2, Unpacking and Setup. Helps you get started with the basic installation of the Switch. Chapter 3, Identifying External Components. Describes the front panel, rear panel and LED indicators of the Switch.

  • Page 10: Introduction

    NTRODUCTION This chapter describes the features of the Switch and some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. A number of high-speed LAN technologies have been proposed to provide greater bandwidth and improve client/server response times.

  • Page 11: Switching Technology

    other 10Mbps Ethernet environments, it provides a straightforward upgrade and takes advantage of the existing investment in hardware, software, and personnel training. Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the address level Ethernet...
  • Page 12 For Fast Ethernet networks, a switch is an effective way of eliminating problems of chaining hubs beyond the “two-repeater limit.” A switch can be used to split parts of the network into different collision domains, making it possible to expand your Fast Ethernet network beyond the 205-meter network diameter limit for 100BASE-TX networks.

  • Page 13: Features

    Features The Switches were designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously. The Switches with their small, compact size were specifically designed for small to middle range workgroups.
  • Page 14 workgroups can connect to the Switches now, and change adapters and hubs anytime later without needing to change the Switches or reconfigure the network. The Switches combine dynamic memory allocation with store-and-forward switching to ensure that the buffer is effectively allocated for each port, while controlling the data flow between the transmit and receive nodes to guarantee against all possible packet loss.

  • Page 15: Unpacking And Setup

    Flow control for any port. This minimizes dropped packets by sending out collision signals when the port’s receiving buffer is full. Note that flow control is only available in half duplex mode. Data forwarding rate per port is at wire-speed for 100Mbps speed.

  • Page 16: Unpacking

    Unpacking Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items: One 8-port 10/100M NWay Fast Ethernet Switch One external power adapter This User’s Guide If any item is found missing or damaged, please contact your dealer for replacement.
  • Page 17 Make sure that there is proper heat dissipation and adequate ventilation around the Switch. Do not place heavy objects on the Switch.

  • Page 18: Identifying External Components

    DENTIFYING XTERNAL OMPONENTS This section identifies major external components of the hub. Both the front and rear panels are shown, followed by a description of each panel feature. The indicator panel is described in detail in the next chapter. Front Panel The figure below shows the front panel of the switch.
  • Page 19 8-port Fast Ethernet 10/100M NWay Switch DC Power Jack: Power is supplied through an external AC power adapter. Check the technical specification section for information about the AC power input voltage. Since the switch does not include a power switch, plugging its power adapter into a power outlet will immediately power it on.
  • Page 20 Uplink Jack(s) (MDI-II): Use this jack to connect stations to the hub. This is MDI-II (Medium- dependent Interface, straight-wired) jack, which means you can connect the hub to a device with a MDI-X port using an ordinary straight-through cable, making a crossover cable unnecessary.

  • Page 21: Led Indicators

    LED Indicators Power Indicator (PWR) This indicator lights green when the hub is receiving power, otherwise, it is off. Full/Half Duplex, 10/100M Collision (FDX10/100 , COLL 10/100 (green) (amber) This LED indicator lights green when a respective port is in full duplex (FDX) mode. Otherwise, it is OFF for half duplex (HDX) operation.

  • Page 22: Connecting The Switch

    ONNECTING WITCH This chapter describes how to connect the Switch to your Fast Ethernet network. In each of the following figures, the 8-port 10/100M NWay Fast Ethernet Switch is shown. PC to Switch A PC can be connected to the Switch via a two-pair Category 3, 4, 5 UTP/STP straight cable (Cat.5 must be used for 100Mbps).

  • Page 23: Hub To Switch

    speed. The FDX 10/100, COLL 10/100 LED indicator depends upon LAN card capabilities for full- duplex or half-duplex. Hub to Switch A hub (10 or 100BASE-TX) can be connected to the Switch via a two-pair Category 3, 4, 5 UTP/STP straight cable (Cat.5 must be used for 100Mbps).

  • Page 24: Hub Without Uplink (Mdi-Ii) Port

    should light up as the following: FDX 10/100, COLL 10/100 LED indicator is OFF. 100LINK/ACT, 10LINK/ACT LED indicator is lit green. Hub without Uplink (MDI-II) port If a hub is not equipped with an uplink (MDI-II) port, connection can be made using either straight cable or crossover cable.

  • Page 25: Using Straight Cable

    Category 3, 4, 5 UTP/STP straight or crossover cable (Cat.5 must be used for 100Mbps). A. Using straight cable When using straight cable, this is done from the uplink (MDI-II) port of the Switch (Switch A) to any of the 10Mbps or 100Mbps (MDI-X) ports of the other switch (switch B) or other devices.
  • Page 26 transmission mode twisted-pair connection: If the attached device does not support auto- negotiation or has auto-negotiation disabled, an auto-sensing process is initiated to select the speed and set the duplex mode to half-duplex.
  • Page 27 ECHNICAL PECIFICATIONS General Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100 Base-TX Fast Ethernet ANSI/IEEE Std 802.3 NWay auto-negotiation Protocol CSMA/CD Data Ethernet: 10Mbps (half duplex), 20Mbps (full Transfer duplex) Rate Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) Topology Star General Network...

  • Page 28: Technical Specifications

    Physical and Environmental DC inputs DC12V/1.5A Power 18 watt. (max.) Consumption Temperature Operating: 0 ~ 50 C, Storage: -10 ~ 70 C Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90% Dimensions 171 x 98 x 29 mm (W x H x D) EMI: FCC Class B, CE Mark B, VCCI-II Performance...

  • Page 29: Pin Specification

    RJ-45 P PECIFICATION When connecting your 8-port 10/100M NWay Fast Ethernet Switch to another switch, a bridge or a hub, a modified crossover cable is necessary. Please review these products for matching cable pin assignment. The following diagram and tables show the standard RJ-45 receptacle/connector and their pin assignments for the switch-to-network adapter card connection, and the straight / crossover cable for the Switch-to-...
  • Page 30 The standard RJ-45 receptacle/connector The following shows straight cable and crossover cable connection: Straight cable for Switch (uplink MDI-II port) to switch/Hub or other devices connection Crossover cable for Switch (MDI-X port) to switch/hub or other network devices (MDI-X port) connection...
