Summary of Contents for SecurityMan FlashDVR
- Page 1 FlashDVR User’s Manual Waterproof Digital Video Recorder with LED Flashlight...
- Page 2 SecurityMan. The content of this manual is furnished for informational use only, is subject to change without responsibility or liability for any errors or inaccuracies that may appear in this book.
- Page 4 DO NOT use this product for any illegal activities. SecurityMan® shall not be responsible for any consequences of illegal conducts made by users.
- Page 5 Warning • Turn off the camera when it is not in use. • Do not shake or stricken the product. • Do not put in fire or heating place. • Do not use metal objects to connect the polarities of the battery. •...
-
Page 6: Table Of Contents
Table of Contents Introduction Features Package Contents Product Basic Charging Time/Date Setup Installation Operation Power on DVR & Flashlight Use Recording Video Day Time Recording Night Time Recording Underwater Recording FlashDVR Characteristics USB Connection & PC Playback MPC Installation Guide Product Specifications... -
Page 7: Introduction
Introduction Thank you for purchasing the FlashDVR. SecurityMan FlashDVR is a smart flashlight with built-in color camera for video recording and 4GB memory of storage. It is a portable flashlight DVR recorder ideal for daytime recording, night time recording, and under water recording (submergible up to 33ft). Easy access to recorded video files with USB interface to any personal computer to view, edit, and playback footages. -
Page 8: Package Contents
Package Contents 1 x Flashlight DVR (GETTIME. 1 x USB cable exe, User’s Manual inside) 1 x Lanyard 1 x Hat-bracket 1 x User’s Manual 1 x Bike-bracket 1 x Plectrum 1 x Power adapter/charger 1 x Adhesive(3M) User’s Manual... -
Page 9: Product Basic
Product Basics Light Indicator Window Flashlight Button Record/Stop button LED lighting Microphone Camera lens Waterproof plug Main ON/OFF/LOCK Switch Mini USB Port Waterproof plug... -
Page 10: Charging
A/C adapter, plug the adapter end into an electrical outlet and then plug the mini USB to the back (remove Waterproof Plug) of FlashDVR and a solid red light will appear in the Indicator Light Window to indicate charging. To charge using... -
Page 11: Time/Date Setup
Time & Date Setup Before using FlashDVR, test by recording a video file clip. Then plug the DVR into a personal computer to playback (see USB connection & PC Playback page 17). Check the Time/Date stamp of the recorded video file to be current up to date. -
Page 12: Installation
3. Double click on the GETTIME.exe file in the root directory of the FlashDVR to complete Time/Date setup. Note. The system will automatically generate a temporary GETTIME.txt file in the Mobile Disk directory of Flashlight DVR. Please also be noted that a PDF copy of the FlashDVR user’s manual is included in the root directory of Flash... - Page 13 To connect the lanyard to FlashDVR, simply hook the lanyard to the Waterproof Plug of flashlight DVR and adjust the size by press+hold the leverage ball then...
-
Page 14: Operation
Operation Power ON DVR & Flashlight Use Remove the Waterproof Plug from the back of the FlashDVR to get to the Main LOCK/ON/OFF Switch. Slide the main switch to the ON position (default OFF, Fig-1 below) to turn on the FlashDVR. Press the Flashlight button once to turn ON the LED flashlight (Fig-2 below). -
Page 15: Recording Video
Underwater Recording page 15 for detail. Note: For smooth, stable playback footage; it is best to ensure the FlashDVR is stable during recording as non-sturdy recording will result in un-stable playback the footages. -
Page 16: Underwater Recording
There are several preparation steps to prepare before submerging FlashDVR underwater for recording. To record underwater, please follow these steps: 1. Remove the waterproof plug from the back of FlashDVR by turning it counter clockwise. 2. Switch the Main LOCK/ON/OFF Switch to the ON position. Turn ON the flashlight if it is dark or leave the flashlight turn OFF if there is enough lighting in the environment. -
Page 17: Flashdvr Characteristics
WARNING 1: Before submerging FlashDVR: Microphone port must be plugged in with the mic waterproof plug. The rear Waterproof Plug must be secure and tight. WARNING 2: After underwater recording; switching from LOCK mode back to ON mode must be precise; and cannot be over switch to OFF mode as recorded data will be lost. Take your time and extra precaution when switching from LOCK to ON. -
Page 18: Usb Connection & Pc Playback
USB connection & PC Playback When the internal memory is full or rechargeable battery is weak, open the waterproof plug and plug FlashDVR to a computer via USB cable. Leave the FlashDVR connected to the computer to recharge the battery. To empty the internal memory for more recording, go to the root of the Removable Disk of the FlashDVR to DCIM folder and into the 100DSCIM folder. -
Page 19: Mpc Installation Guide
MPC Installation Guide To install the Media Player Classic, visit http://mpc-hc.sourceforge.net/ to download the latest freeware MPC available and then double click on “MPC- HomeCinema.1.3.1249.0(xxx).exe” to start the installation process as shown below. Click “Ok” at the Setup window as shown below. At the Welcome window, click on Next to proceed. - Page 20 Select “I accept the agreement” and then click on Next to proceed with installation.
- Page 21 Click Next for the next 3 winows as shown below.
- Page 22 Be sure to check the “Create a desktop icon” as shown in the second window below. Then click on “Install” and then click on “Finish” to complete the installation process as show below.
- Page 24 To open MPC player for playback, click on the “Media Player Clasic - Home Cinema” shortcut on the desktop as shown below. Please reference MPC player help menu for tutorial. In case “Save Image” and “Save Thumbnails” does not allow image to be save, click on View >...
-
Page 26: Product Specifications
Product Specifications Image Sensor 1/5” Color CMOS Video Resolution 640x480 (VGA) Audio Microphone built-in Storage Medium 4GB Built-in Memory Waterproof IP68 (10m max underwater) Power Supply 5V 1.5A, positive inside Power Consumption 440mA Rechargeable Battery 3.7V / 1800mAh Li-Battery LED Power Dimensions (WxDXH) 119x38x46mm LED Light Color Temperature...
