Page 2: Lamp Installation
Getting Started S e c t i o n 1 Inspection Every X-Treme™ projector was thoroughly tested and shipped in perfect condition. Carefully unpack the projector and remove the bag with components from the carton. Inspect equipment for shipping damage. - Page 3 CH1: Color, CH2: Gobo 1; CH3: Pan; CH4: Tilt DMX-512 Addressing You must select the proper DMX-512 address for each X-Treme™ projector. Below Is a chart of standard addressing for use with the X-Treme/C™ ,X-Treme/19C™ controllers. Projector Projector DIP switch setting...
- Page 4 Inverts the Tilt motion. Useful when projector are mounted “head to head”, to allow the mirrors to move In unison. Function #5: “On” X-Treme™ automatically runs through all the features one at a time. So you can see every gobo and color and pan/tilt motion. Used when testing operation of unit.
