Dear customers, congratulations. You have once again made a wise and sensible purchase. By choosing our Washing machine you not only found the best in advanced technology, but above all you have found a faithful, untiring and reliable friend. Your machine is strong, reliable and long lasting. All those qualities which have made the our trademark famous the world over.
Installation Unpacking Remove the package and check that the machine is levelling and undamaged. positioning If you have any doubts, do not use the machine and call on a qualified technician. Keep all packing parts (plastic bag, foam rubber, screws etc.) out of the reach of children since they could be dangerous.
Page 6
Installation Connect the plug to a socket provided with efficient Electric earthing. Or use the spare earthing wire supplied connectio together with the machine and the earthing terminal located on the left-upper corner of the back of your machine (Warning: this appliance must be earthed as a safety measure according to the law).
Page 7
Installation Connection of Connect the drain hose to a drain duct (with the Drain Hose internal diameter of at least 4 cm.) or place it for drainage into a sink or a tub, ensuring that there are no kinks or bends. The free end must be at a height of between 80 and 100 cm.
Close up 1400 1400 1200 1200 HM1400TX HM1400TX HM1200TX HM1200TX...
Page 9
Close up A Programme selector lcwob. By turning this dial (clockwise only) you can select from eighteen wash programmes the one most suited for your washing. 1~7 cotton cycle A~F synthetic cycle I~V wool cycle B Programme selector Knob. With this dial you can set the wash temperature that you desire.For synthetic and wool, the thermostat works below 60C and 40C respectively.
Page 10
2 Wash detergent 3 Softeners, conditioners, perfumes Fig.8 H Door Lock Light Remember that only when the washer doesn't work,we can open the door. After the washing program finish,after 3 minutes, when the self-lock meter turn off, we can open the door.
Page 11
In order to get the excellent results that you would The weight is right expect from your washing machine, it is important to load the washer choose the quantity of each type of fabric that you want to wash. This table will help: Colour fast fabrics...
Page 12
Using instructions:Your machine offers the best results when... The correct A perfect wash depends above all on choosing the programme has most suitable programme. We would therefore been chosen advise you to divide up your washing into separate loads of more or less the same types of fabric. This will make it easier to select the best programme.
Using instructions:Your machine offers the best results when... The detergent The 3 compartments marked 1, 2, 3 (Fig.9) should be has been put used as follows: in properly 1 Pre-wash detergent 2 Wash detergent 3 Conditioner, starch, scents Remember that it is important to use the right amount of soap powder or liquid for the type of laundry you are washing;...
Page 14
Using instructions:Your machine offers the best results when... The following table will guide you: Compart.1 Laundry prewash Normally 1/2 measuring soiled When using concentrated detergents, remember to keep to the manufacturer's instructions using only the measuring cups supplied with the packet. Use more detergent in the case of very hard water ( more than 21.F), but remember to maintain the proportion between the prewash and wash cycles.
Page 15
Using instructions:Your machine offers the best results when... You can now start washing. We would advise you, The cycle is started especially the first few times, to check that the programme that you have set is really the one you want and that the fabric selection is correct.
4. If it is long time no use, you'd better cut off the power, switch off the tap, and open the door to avoid unpleasant smell. 5. Your washer is equipped with a self-cleaning pump. It is therefore not necessary to carry out cleaning and Fig.8 maintenance operations.
Solution to Problems Even though your washing machine has been carefully designed and constructed, something could still go a miss with your machine. Before rushing to phone one of our service centres, however, please check that the operations listed below have been carried out.
Solution to Problems The machine Check that: vibrates too the transit bolts have been removed (see much when installation manual); spinning the machine is level; the washing load is according to the instructions given in this booklet. The machine Check that: stops operating there is a sudden power failure or water stop.
Warning: 1. If the supply cord is damaged, it must be replaced, these are available from an authorised service agent. 2. The appliance must be placed so that the plug is accessible. 3. The appliance is to be connected to the water mains using new hose-sets, old hose-sets should not be reused.
